GardenMeister Green Diamond 200 Assembly Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Handleiding
Green Diamond 200
GM805200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Green Diamond 200 and is the answer not in the manual?

Questions and answers

Related Manuals for GardenMeister Green Diamond 200

Summary of Contents for GardenMeister Green Diamond 200

  • Page 1 Handleiding Green Diamond 200 GM805200...
  • Page 2 Assembly Instructions Assembly Instructions MODEL: GM36002 PRODUCT SIZE(LxWxH):390x343x290cm MODEL: GM36002 PLEASE READ CAREFULLY BEFORE ASSEMBLY PRODUCT SIZE(LxWxH):390x343x290cm PLEASE READ CAREFULLY BEFORE ASSEMBLY...
  • Page 3 Assembly and Maintenance Advice Assembly and Maintenance Advice 1. For safety purposes, we strongly recommend that the product will be assembled by at least two people. 1. For safety purposes, we strongly recommend that the product will be assembled by at least two 2.
  • Page 4 Functions and Features: Functions and Features: 1. Compared with traditional greenhouses, this exciting new product features many significant 1. Compared with traditional greenhouses, this exciting new product features many significant improvements. The hollow box profile aluminium framing is much stronger than other improvements.
  • Page 5 3. Base anchor brackets are included as standard with expanding bolts to ensure a secure 3. Base anchor brackets are included as standard with expanding bolts to ensure a secure fixing into concrete or paving. Alternatively, you can use the brackets to fix into a timber base with wood fixing into concrete or paving.
  • Page 6 ALU. Box No.1 PART PART L01A L08A...
  • Page 7 ALU. Box No.2 PART PART L23C L23D L23A M8X150 L23B L23E L23N L02A L02G L02K...
  • Page 8 ALU. Box No.3 PART L03A L02C L02D L02E L24A L24B L24F L24G L25A L25B L25C L25D L25E...
  • Page 9 ALU. Box No.4 PART PART PART PART M6X12 L11A M4X10 L11B M8X35 L11D L11E L12A L12C D335 4X16D L12D L12K 4X50 L12E M4.2X25 Free Tool Free Tool L12F 4X16 Free Tool Free Tool L19A L19B L11F L11G L16A L16B L18A L18B L18C L18D...
  • Page 10 PC. Box PART N0.1 PART 192M J147 Rubber for walls only Rubber for walls & roof (Provided for glass only) (Provided for glass only) PART 123M J147 Rubber for walls only Rubber for walls only (Provided for glass only) (Provided for glass only) PART N0.2...
  • Page 11 PART Roof Vents Assembly x 2PCS L11F L11G L19A L19B Roof Vents Assembly x 2PCS Frames L19A Panels L19A L11G L19B L11F L11F L11G...
  • Page 12 L19A L19A L19B L19A L19B L19A Push down the button on After connector A37 has been Push down the button on After connector A37 has been fitted connector A37 before fitted, use the hole in the connector A37 before inserting it use the hole in the profile to tighten inserting it into the end of the profile to tighten the...
  • Page 13 L11G L11F L11F L11G First the glazing panel Y10 should be loosely retained by the bar capping profiles First the glazing panel Y10 should be loosely retained by the bar capping profiles L11F and L11G. Next tap the bar capping gently into position with a rubber mallet. L11F and L11G.
  • Page 14 Fix the A01 vent arms using Z04 screws. Fix the A01 vent arms using Z04 screws.
  • Page 15 Fill the gap with silicone sealant on 4 sides to avoid any leaking. Fill the gap with silicone sealant on 4 sides to avoid any leaking.

  • Page 16: Table Of Contents

    PART PART PART L16A Door Assembly L16B M8X35 Door Assembly L18A 4X50 L18B M4X10 L18C L18D L11H L11J Right door Right Door Left door Left Door...
  • Page 17 Left Door Put L16A into L17 and L18D and put L16B into L18A and L18B, Put L16A into L17 and L18D and put L16B into L18A and L18B, then assemble Left Door then assemble the door frames using connector A37, as shown in the the door frames using connector A37, as shown in the sketches below.
  • Page 18 L11H L11J L11H L11H L11J L11H First the glazing panels should be loosely retained by the bar capping profiles L11H and L11J. First the glazing panels should be loosely retained by the bar capping profiles L11H and L11J. Next tap the bar capping gently into position with a rubber mallet, Next tap the bar capping gently into position with a rubber mallet,...

  • Page 19: L13

    Slide 2xS02 into L18D, positioned 100mm away from each edge. Slide 2xS17 into L18D, positioned 100mm away from each edge. Secure S17 using M06 bolts, then Secure S17 using M06 bolts, then rotate the wheels rotate the wheels to ensure free movement. to ensure free movement.

  • Page 20: Right Door

    Right Door Put L16A into L17 and L18D and put L16B into L18A and L18C, Put L16A into L17 and L18D and put L16B into L18A and L18C, then assemble then assemble the door frames using connector A37, as shown in the Right Door the door frames using connector A37, as shown in the sketches below.

  • Page 21: L11H

    Expansion bolts assembly L11H L11J L11H L11H L11J This size is the inner specification of the product, L11H First the glazing panels should be loosely retained by the bar capping profiles L11H and L11J. First the glazing panels should be loosely retained by the bar capping profiles L11H and L11J. Next tap the bar capping gently into position with a rubber mallet, Next tap the bar capping gently into position with a rubber mallet,...
  • Page 22 Slide 2xS02 into L18D, positioned 100mm away from each edge. Slide 2xS02 into L18D, positioned 100mm away from each edge. Secure S17 using M06 bolts, then rotate the wheels Secure S17 using M06 bolts, then rotate the wheels to ensure free movement. to ensure free movement.
  • Page 23 Expansion bolt Expansion bolt in concrete in concrete It is essential the dimensions a = b = c are the same to ensure the base is square It is essential the dimensions a = b = c are the same to ensure the base is square. Support at the corners only is inadequate.

  • Page 24: Base Set Up

    PART Base Set Up M8X60 3908.8mm 3761.7mm 1954.4mm 106.3 This shows the outer & inner dimensions of this product which helps build up the optional bases. This shows the outer & inner dimensions of this product which helps build up the optional bases.
  • Page 25 PART L08A L08A L08A L08A L08A L08A First lay out the aluminium profiles, connectors and anchor brackets approximately in place. First lay out the aluminium profiles, connectors and anchor brackets approximately in place. Make sure Make sure you pay you pay close attention close attention to the direction...
  • Page 26 PART L01A L01A L01A L01A L01A L01A L01A Make sure Make sure you pay you pay close attention close attention to the direction to the direction of the pins of the pins L01A L01A L08A L08A L08A Assemble L01A with connector A,insert connector A into L01A, tighten the bolt with Assembly L01A with connector A41,insert connector A41 into L01A, tight the bolt with the special the spanner (provided) when it's in the right position.
  • Page 27 PART M6X12 Make sure Make sure you pay you pay close attention close attention to the direction to the direction of the pins of the pins S05X3pcs L01A L01A Slide the S05 bolts (3PCS) into Assemble the L07 and L01A with connector B, insert connector B into L01A and L07, tighten the bolt with the channel of the L07 that is Assemble the L07 and L01A with connector B, insert...
  • Page 28 PART L23A L23B Please pay attention to the direction Please pay attention to the direction of the components. of the components. L23A L23B L01A L23B L23B L08A Tap the coverstrip L23B into L10, L08A and L07, and L23A into L01A gently with a rubber mallet. Tap the bar capping L23B into L10, L08A and L07, and L23A into L01A gently with a rubber mallet.
  • Page 29 PART L23C L23C L23C L23C L23C L23C L23C L08A L08A L23C L23C 50mm 50mm Tap the coverstrip L23C into L07 and L08A gently with a rubber mallet. Make sure you leave 50mm between the two L23C in the middle to allow installation of the wall framing later.
  • Page 30 PART L02A L02A L23C L23C L02A L08A Slide in Slide in Tight it up Put the connector A38 into the slot of L07, and L08A, Tighten up rotate the connector until it slots into the channel Put the connector A38 into the slot of L07, and L08A, as per the diagram on the left.
  • Page 31 PART L23A L02A L23A Tap the coverstrip L23A into Tap the coverstrip L23A into L02A gently with a rubber mallet. L02A gently with a rubber mallet.
  • Page 32 PART L23D L01A L23D L23D L23D L02A L01A L02A L02A L23D L01A L01A L01A L23D L02A L23D 50mm 50mm 50mm 50mm 50mm 50mm Tap the coverstrip L23D into L01A and L02A gently with a rubber mallet. Make sure you leave 50mm between the two L23D in the middle, Tap the coverstrip L23D into L01A and L02A gently with a rubber mallet.
  • Page 33 PART L02K Slide in Tighten up Slide in Tight it up L23D L02K L23D Assemble L02K. Put the connector A38 into the slot of L02A and L01A, rotate the connector until it slots into the channel as per the diagram above. Tighten the bolt in the connector A38 with the spanner.
  • Page 34 PART L23C L23C L02K L23C L23C Tap the coverstrip L23C into L02K gently with a rubber mallet. Tap the bar capping L23C into L02K gently with a rubber mallet.
  • Page 35 PART L23E L23N L23E L23N L23E L23E L23N L23E L23N/E L23E/N 50mm 50mm Tap the coverstrip L23E and L23N into L10 and L07 gently with a rubber mallet. Tap the coverstrip L23E and L23N into L10 and L07 gently with a rubber mallet. Make sure you leave 50mm between the two L23E and L23N in the middle, Make sure you leave 50mm between the two L23E and L23N in the middle, to allow the installation of the L02A in future steps.
  • Page 36 PART L02A L02A L02A L02A L23N/E L23E/N L02A Slide in Tighen up Slide in Tight it up Put the connector A38 into the slot of L10 and L07, rotate the connector until it slots into the channel Put the connector A38 into the slot of L10 and L07, as per the diagram on the left.
  • Page 37 PART L23A L23A L23A L02A L23A Tap the coverstrip L23A into L02A gently with a rubber mallet. Tap the coverstrip L23A into L02A gently with a rubber mallet.
  • Page 38 PART L23A L23D L23A L23D L23D L01A L01A L02A L02A L01A L01A L02A L23D L23A L23D L23D 50mm 50mm L23D L23D L23D Tap the coverstrip L23A and L23D into L01A and L02A gently with a rubber mallet. Tap the coverstrip L23A and L23D into L01A and L02A gently with a rubber mallet. Make sure you leave 50mm between the two L23D in the middle, Make sure you leave 50mm between the two L23D in the middle, to allow the installation of the L02G in future steps.
  • Page 39 PART L02G L02G L02G L23D L02G L23D Slide in Tighten up Slide in Tight it up Assemble L02G. Put the connector A38 into the slot of L02A and L01A, Assemble L02G. Put the connector A38 into the slot of L02A and L01A, rotate the connector until it slots into the channel as per the diagram above.
  • Page 40 PART L23E L23E L23E L23E L02G L23E L23E Tap the coverstrip L23E into L02G gently with a rubber mallet. Tap the coverstrip L23E into L02G gently with a rubber mallet...
  • Page 41 PART L03A L03A L03A M6X12 L03A S05/D33 D34 L03A Assemble the L03A with the connector B, L03A insert connector B into L03A, tighten Assemble the L03A with the connector B, the bolt with the spanner (provided) insert connector B into L03A, tighten the bolt with the spanner (provided) Remember to install the J17 in this step.
  • Page 42 PART L03A L03A M6X12 Do the same for the remaining L03A profiles. Do the same for the remaining L03A profiles.
  • Page 43 PART Auto Cap Assembly Install the H31 cylinder through the central hole on D34 (Fig.1). Insert the split pin to secure it in place (Fig. 2 & 3). Install the H31 cylinder through the central hole on D34 (Fig.1). Insert the split pin to secure it in place (Fig. 2 & 3).
  • Page 44 PART L24A L24B L23C Roof frame instructions Roof frame instructions where the roof vents where the roof vents are to be installed. are to be installed. L24B L23C L24B L24B L03A L03A L24A L24A Tap the coverstrips L24A into L03A and L24B into L07 gently with a rubber mallet. Tap the coverstrips L24A into L03A and L24B into L07 gently with a rubber mallet.
  • Page 45 PART L02C L02C L25A 50mm L02E L02D L25A L25A L02E L25B L02E L25B L25A L25A L25B L02D L23C L25B L25B L02D L25A L25B L23C Roof frame on the window vent side Roof frame on the assembly window vent side assembly M6X12 L02E Tap the coverstrips L25A and L25B into L02E gently with a rubber mallet.
  • Page 46 PART L02D Put connector A38 into the slot of L07 rotate the connector until it slots the hole on L02D. Tight the bolt in into the channel as per the diagram on the left. Tighten the bolt in the connector A38 with the spanner.
  • Page 47 PART L25C L25D L25E L02C L25C L02E L25D L25C L02D L25D L02D L25E L25D L25D Tap the coverstrips L25C into L02C, L25D into L02D and L25E into L02E Tap the coverstrips L25C into L02C, L25D into L02D and L25E into L02E gently with a rubber mallet.
  • Page 48 PART L24F L24G L24G L24G L24F L24F L03A L03A L24G L24F&L24G L24F&L24G L24F L24G L24F Tap the coverstrips L24F into L03A and L24G into L03A gently with a rubber mallet. Do the same on the other side where the vent is to be installed. Tap the coverstrips L24F into L03A and L24G into L03A gently with a rubber mallet.
  • Page 49 PART M8X150 Then install the opener piston so that it pushes Insert screw S18 into the H32 spring and Insert screw S18 into the H32 spring and Then install the opener piston so that it pushes up the D35 slightly. You will need to ensure push it through the holes in D34 and push it through the holes in D34 and up the D35 slightly.
  • Page 50 PART Panel Assembly Panel Assembly L11B L11B L12C L11B L12C L12D L12D Install the panels and aluminum bar capping in order as shown above, tap the bar capping Install the panels and aluminum bar capping in order as shown above, tap the bar capping into the channels with a rubber hammer.
  • Page 51 Silicone sealant can help seal at these points to prevent any leaking. Silicone sealant can help seal at these points to prevent any leaking. NOTE: ENSURE A POLYCARBONATE SUITABLE SILICONE IS USED. NOTE: ENSURE A POLYCARBONATE SUITABLE SILICONE IS USED.
  • Page 52 PART L11B L11B L12C L11B L12C L12E L12D L12E L12D Install the panels and aluminum bar capping in order as shown above, tap the bar capping Install the panels and aluminum bar capping in order as shown above, tap the bar capping into the channels with a rubber hammer.
  • Page 53 Silicone sealant can help seal at these points to prevent any leaking. NOTE: ENSURE A POLYCARBONATE SUITABLE SILICONE IS USED. Silicone sealant can help seal at these points to prevent any leaking. NOTE: ENSURE A POLYCARBONATE SUITABLE SILICONE IS USED.
  • Page 54 PART Window x2pcs Window x2pcs M6X12 Slide the window vent along Slide the window vent along the groove in the L22 and fix the groove in the L22 and fix it in the correct position it in the correct position using Z04 screws.
  • Page 55 Witvrouwenbergweb 13B 5711CN, Someren Nederland...
  • Page 56 PART PART L11A L11D L12A L12K L11A L11A L12K L12K L12K L12A L12A L11D L11D L11D Install the panels Y6 and aluminum Install the panels Y6 and aluminum bar capping in order as shown above, bar capping in order as shown above, tap the bar capping into the channels tap the bar capping into the channels with a rubber hammer.
  • Page 57 PART PART L11A L11E L12A L12F L11A L11A L12F L12F L12A L12A L11E L11E Install the panels Y7 and aluminum Install the panels Y7 and aluminum bar capping in order as shown above, bar capping in order as shown above, tap the bar capping into the channels tap the bar capping into the channels with a rubber hammer.
  • Page 58 PART Use a screw S05 to pass through D96, and then Use a screw S05 to pass through D96, and then slide D96 (2pcs) into the channel of L14, slide D96 (2pcs) into the channel of L14, M6X12 use H33 & M07 to bolt them but not too tight. use H33 &...
  • Page 59 PART 4X16D Turn the H31 cylinder counter clockwise to Turn the H31 cylinder counter clockwise to adjust the gap between the D35 and L03A. adjust the gap between the D35 and L03A.
  • Page 60 PART M4.2X25 L01A L08A/L10 L03A L01A...
  • Page 61 PART 4X16 L03A You can use silicone sealant Drill a hole in L01A and L01B, Drill a hole in L01A and L01B, Fill some silicone sealant Fill some silicone sealant around the downpipe bends and L30 to avoid water leaking. approximately 2.5mm diameter approximately 3.2mm diameter around J17 and L30 to avoid...
