- Page 1 Operating and in- stallation instructions MiSet SRT 380f GB, IE...
-
Page 2: Table Of Contents
Contents Contents Information about the product ........20 Safety ..........3 Observing and storing other applicable documents ....20 Action-related warnings ....3 Validity of the instructions .... 20 Intended use ........3 Data plate ........20 General safety information..... 4 Serial number ...... -
Page 3: Safety
Safety 1 1 Safety generators from the same man- ufacturer. 1.1 Action-related warnings The control controls based on Classification of action-re- the installed system: lated warnings – Heating The action-related warnings – Domestic hot water genera- are classified in accordance tion with the severity of the pos- –... -
Page 4: General Safety Information
1 Safety – Decommissioning not be carried out by children unless they are supervised. ▶ Proceed in accordance with Any other use that is not spe- current technology. cified in these instructions, or Work and functions that must use beyond that specified in this only be carried out or set by the document, shall be considered competent person are marked... -
Page 5: Safety/Regulations
Safety 1 1.3.6 Danger caused by improper operation Improper operation may present a danger to you and others, and cause material damage. ▶ Carefully read the enclosed instructions and all other ap- plicable documents, particu- larly the "Safety" section and the warnings. -
Page 6: Product Description
2 Product description 2 Product description 2.5 What is the circulation? An additional water pipe is connected to 2.1 Which nomenclature is used? the domestic hot water pipe and forms a – Control: Instead of SRT 380f circuit with the domestic hot water cylin- –... -
Page 7: Preventing Malfunctions
Product description 2 rooms to the lower set-back temperature ure, the heat curve is then translated, as (2) that is set. shown in the figure. The heat curve is dis- placed according to the value of the tar- 2.7 Preventing malfunctions get room temperature along axis a which ▶... - Page 8 2 Product description Press once: You access the basic display. Press twice: You access the menu. 2.9.2 Symbols Battery state of charge Signal strength Time-controlled heating active Maintenance required Fault in the heating installation Contact the competent person Operating and installation instructions MiSet 0020299001_00...
-
Page 9: Operating And Display Functions
Product description 2 2.10 Operating and display functions Note The functions described in this section are not available for all system configura- tions. The product has two adjustment and display levels. The end user level contains information and setting options that you require as the end user. - Page 10 2 Product description MENU → CONTROL → Mode: Domestic hot water weekly planner: Up to three time periods can be set per day DHW temperature: °C: Applies within the time periods Domestic hot water mode is switched off outside of the time periods Circulation weekly planner: Up to three time periods can be set per The circulation pump pumps hot water to the draw-off points within the time periods...
- Page 11 Product description 2 MENU → SETTINGS → Screed drying Activate the Screed drying profile function for freshly laid screed in accordance with the construction regulations. The control regulates the flow temperature independently of the out- door temperature. Setting screed drying (→ Installation configuration menu item) →...
- Page 12 2 Product description MENU → SETTINGS → Installer level → Installation configuration → Control: Weath.- It is controlled via the outdoor temperature comp. as soon as an outdoor temperature sensor is connected. → Heat generator 1 → Status: → Current flow temperature: °C →...
- Page 13 Product description 2 MENU → SETTINGS → Installer level → Installation configuration → Normal The heating function is switched on. The con- trol regulates to the Set-back temperature: °C. Prerequisite: – Time-contr. is activated in the Heating → Mode: function. The behaviour can be adjusted separately for each heating circuit.
- Page 14 2 Product description MENU → SETTINGS → Installer level → Installation configuration → Anti-legio. day: Define the days on which you want the anti-legionella func- tion to run. On these days, the water temperature is in- creased to above 60 °C. The circulation pump is activated. The function ends after 120 minutes at the latest.
-
Page 15: Electrical Installation, Set-Up
-- Electrical installation, set-up 3 3.3 Polarity -- Electrical installation, When connecting the eBUS line, there is set-up no need to pay attention to the polarity. If the connection cables are switched over, Obstacles weaken the reception strength communication will not be adversely af- between the radio receiver unit and the fected. -
Page 16: Installing The Control
-- Electrical installation, set-up Condition: The heat generator does not have an option to connect it directly and/or is installed in the wet environment. X100 ▶ When opening the electronics box in the heat generator, proceed as de- scribed in the installation instructions ▶... - Page 17 -- Electrical installation, set-up 3 8. Set the time. 12. Press the wake-up/sleep button on ◁ the upper side of the unit if the display The installation assistant switches is off. to the Control reception strength function. Condition: The display is on, The display shows Ra- dio communication interrupted Condition: Wireless outdoor temperature sensor ▶...
-
Page 18: Start-Up
-- Start-up Fitting the control Installation configuration: The installa- tion assistant switches to the system con- figuration for the installer level, in which you can further optimise the heating in- stallation. Installation start: The installation assist- ant switches to the basic display and the heating installation works with the values you have set. - Page 19 Fault and maintenance messages 5 ▶ Dispose of used batteries in accordance with the instruc- tions in this manual. Warning. Risk of chemical burns caused by leaking batteries! Corrosive battery fluid may leak out of used batteries. ▶ Remove any used batteries from the product as soon as 2.
-
Page 20: Information About The Product
For contact details for our customer ser- Read the instructions vice department, you can write to the ad- dress that is provided on the back page, or you can visit www.glow-worm.co.uk. 6.4 Serial number 6.7 Recycling and disposal You can call up the serial numbers under MENU →... -
Page 21: Product Data In Accordance With Eu Ordinance No. 811/2013, 812/2013
Information about the product 6 6.9.2 Radio receiver unit ----- Packaging ----------------- ▶ Dispose of the packaging correctly. Rated voltage 9 to 24 V ▶ Observe all relevant regulations. Rated current < 50 mA Rated surge voltage 330 V 6.8 Product data in accordance 868.0 to Frequency band with EU Ordinance no. -
Page 22: Appendix
Appendix Appendix A Troubleshooting, maintenance message A.1 Troubleshooting Symptom Possible cause Measure Display remains dark The batteries are flat 1. Change all the batteries. (→ Page 18) 2. If the fault persists, inform the competent person. Software error 1. Press and hold the button on the top right of the control for longer than five seconds in order to force a restart. -
Page 23: Maintenance Messages
Appendix A.2 Maintenance messages Message Description Maintenance work Interval Water defi- The water pressure is Refer to the operat- See the operating ciency: Fol- too low in the heating ing instructions for the instructions for the low the in- installation. relevant heat gener- heat generator structions... -
Page 24: Maintenance Messages
Appendix B.3 Maintenance messages Message Description Maintenance work Interval Heat gen- The heat generator Refer to the operating See the operating or erator 1 requires maintenance or installation instruc- installation instructions requires work. tions for the relevant for the heat generator mainten- heat generator for in- ance... -
Page 25: Index
Index Index Lines, maximum length ......15 Lines, minimum cross-section ....15 Article number ........20 Lines, selecting........15 Attaching the unit mounting bracket, to the wall ........... 17 Maintenance........... 18 Attaching, control to the unit mounting bracket............ 17 Operating and display functions ....9 CE marking.......... - Page 28 Vaillant Group UK LTD Nottingham Road ‒ Belper ‒ Derbyshire DE56 1JQ Telephone 01773 824639 ‒ Technical helpline 0330 100 7679 After sales service 0330 100 3142 www.glow-worm.co.uk 0020299001_00 0020299001_00 ‒ 29.11.2019 © These instructions, or parts thereof, are protected by copyright and may be reproduced or distributed only with the manufacturer's written consent.
