- Page 1 Repeaters for NOTI•FIRE•NET® RPT – W/WF/F Instruction Manual Document 50256 Rev: E 08/05/2019 ECN: 18-0305...
- Page 2 Fire Alarm & Emergency Communication System Limitations While a life safety system may lower insurance rates, it is not a substitute for life and property insurance! An automatic fire alarm system—typically made up of smoke Heat detectors do not sense particles of combustion and alarm detectors, heat detectors, manual pull stations, audible warning only when heat on their sensors increases at a predetermined rate devices, and a fire alarm control panel (FACP) with remote notifica-...
-
Page 3: Installation Precautions
HARSH™, NIS™, and NOTI•FIRE•NET™ are all trademarks; and Acclimate® Plus™, eVance®, FlashScan®, FAAST Fire Alarm Aspiration Sensing Technology®, Honeywell®, Intelligent FAAST®, NOTIFIER®, ONYX®, ONYXWorks®, SWIFT®, VeriFire®, and VIEW® are all registered trademarks of Honeywell International Inc. Microsoft® and Windows® are registered trademarks of the Microsoft Corporation. Chrome™ and Google™ are trademarks of Google Inc. Firefox® is a registered trademark of The Mozilla Foundation. -
Page 4: Software Downloads
• Your suggestion for how to correct/improve documentation Send email messages to: FireSystems.TechPubs@honeywell.com Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services. Repeaters for NOTI•FIRE•NET® — P/N 50256:E 08/05/2019... -
Page 5: Table Of Contents
Table of Contents 1.1: General..........................................6 1.2: Related Documentation .....................................7 1.3: UL 864 9th and 10th Edition .....................................7 1.4: RPT Mounting ........................................8 1.5: RPT Configuration......................................13 1.6: RPT Connections ......................................14 1.6.1: Mixing Wire and Fiber on One Network..............................16 1.7: Powering the RPT......................................17 1.8: Network Wiring Requirements ..................................18 1.8.1: Limit on Circuit Segment Length .................................18 1.8.2: Limit on System Path Length ................................21... -
Page 6: General
General 1.1 General Repeaters (RPTs) are used to boost the data signal between network nodes, extending the data communication distance in NOTI•FIRE•NET™ systems (refer to Figure 1.1). There are three types of RPTs available: the RPT-W, RPT-F, and RPT-WF. The RPT- W is a Repeater (RPT) which supports twisted-pair wire only;... -
Page 7: Related Documentation
Related Documentation 1.2 Related Documentation To obtain a complete understanding of specific features of RPTs or to become familiar with functions in general, make use of the docu- mentation noted in Table 1.2. Compatible Conventional Devices (Non-addressable) Document Number Device Compatibility Document 15378 Fire Alarm Control Panel (FACP) and Intelligent Annunciators Document Number... -
Page 8: Rpt Mounting
RPT Mounting 1.4 RPT Mounting RPTs may be mounted to a CHS-4L, CHS-M2, CHS-M3, or CHS2-M2 chassis or remotely in an ABS-8RB annunciator surface mount backbox with blank face plate. The RPT-W may also be mounted on a CHS-4 or CHS-4N chassis or on a BMP-1 for dress panel mount- ing. - Page 9 RPT Mounting CHS-M2 The RPT will fit in the third and fourth (outermost) layers of the CHS-M2. The recommended mounting location is the third layer. This mounting option can only be done if there are other option boards mounted in the first two layers. Screw (4) 4-40 standoffs onto the option board in the second layer.
- Page 10 RPT Mounting CHS2-M2 The RPT can be mounted in the fourth position of the CHS2-M2. Be sure to mount the chassis to the backbox before mounting the RPT. Align the RPT over the PEMs on the back of the chassis. Secure with (4) 4-40 screws provided with the board or, if attaching a second option board, with stand-offs provided with the second board.
- Page 11 RPT Mounting CHS-4N CHS-4N installation is for the RPT-W only. Screw (2) 6-32 standoffs onto PEM studs in chassis. Screw (2) 4-40 screws into top holes of RPT-W and attach (2) 4-40 standoffs. These standoffs will not attach to the CHS-4N, but are used to balance the board. Place tab on bottom of board into slot. Screw board into 6- 32 standoffs with (2) 6-32 screws.
- Page 12 RPT Mounting ABS-8RB Mounting Before mounting the ABS-8RB, determine which knockouts are needed to wire the RPT. Remove knockouts. Mount the ABS-8RB. Place the RPT in the box and affix into PEM standoffs using (4) 4-40 screws. Draw appropriate wiring in through knockouts. 4-40 screws Repeaters for NOTI•FIRE•NET®...
-
Page 13: Rpt Configuration
RPT Configuration 1.5 RPT Configuration The RPT has switches which are used to configure the RPT for correct operation (refer to Figure 1.9). SW1 on the RPT-W and RPT-WF is used to set the threshold for Port A. SW2 on the RPT-W sets the Port B threshold. SW3 on the RPT-W is used to enable or disable ground fault detection feed-through for the data line. -
Page 14: Rpt Connections
RPT Connections 1.6 RPT Connections Please note that when using fiber-optic connections, cable originating at a transmit port must be terminated at a receive port. NOTI•FIRE•NET™ wiring is power-limited. Also, when using twisted-pair wiring, polarity need not be observed. Figures 1.10 and 1.11 depict wiring examples using wire and fiber-optic connections. - Page 15 RPT Connections To next node or RPT Fiber-Optic Cable • NCM-F • NCS-NCF See Section 1.8 for attenuation. Fiber-Optic Cable To next node or RPT Fiber-Optic Cable • MIB-F • MIB-WF (Port B only) • NAM-232F Figure 1.11 Connecting RPT-Fs Repeaters for NOTI•FIRE•NET®...
-
Page 16: 1: Mixing Wire And Fiber On One Network
RPT Connections 1.6.1 Mixing Wire and Fiber on One Network The RPT-WF may be used as an interface between wire and fiber in networks where it is necessary to mix twisted-pair wire and fiber- optic cable. Figure 1.12 depicts a wiring example of this. To next node or RPT Fiber-Optic Cable •... -
Page 17: Powering The Rpt
Powering the RPT 1.7 Powering the RPT To other devices Supervised Non-resettable 24VDC Compatible Regulated, Power-Limited Power Supply UL/ULC-Listed for Fire Protective Signalling Use Figure 1.13 RPT Power Repeaters for NOTI•FIRE•NET® — P/N 50256:E 08/05/2019... -
Page 18: Network Wiring Requirements
Network Wiring Requirements 1.8 Network Wiring Requirements When designing the wiring layout of a NOTI•FIRE•NET™ system, the following distance limitations must be considered: The length of each individual twisted pair or fiber optic network communication circuit segment is limited. The system path length is limited. NOTE: Noti•Fire•Net™... - Page 19 Network Wiring Requirements Permissible Single Twisted Pair Range Data Threshold: (In Feet) For Each Cable Segment Cable Manufacturer, Part All Nodes Manufacturer's Number, and Number of And/Or Point-to-Point Bus Configuration Specifications Gauges/Conductors Repeaters On A 3 to 7 2 Nodes/Repeaters Cable Segment Nodes/Repeaters ACE Wire 61401SLL,...
- Page 20 Network Wiring Requirements Permissible Single Twisted Pair Range Data Threshold: (In Feet) For Each Cable Segment Cable Manufacturer, Part All Nodes Manufacturer's Number, and Number of And/Or Point-to-Point Bus Configuration Specifications Gauges/Conductors Repeaters On A 3 to 7 2 Nodes/Repeaters Cable Segment Nodes/Repeaters PAIGE ELECTRIC...
-
Page 21: 2: Limit On System Path Length
Network Wiring Requirements Limit for Fiber Optic Circuits The attenuation of cabling between two nodes/repeaters (fiber optic circuits are point-to-point) is limited by cable choice. If the distance required for a circuit segment is greater than permitted, a Repeater module (RPT-F) must be inserted into the circuit at intervals less than, or equal to, the attenuation length restriction. - Page 22 Network Wiring Requirements Figure 1.16 shows the time-out threshold in the section where it might Overall distance Network’s Time-out be crossed by the values for an extremely large network that uses maxi- (in feet) Threshold mum system segment length between all segments. Plot your proposed 450,000 number of nodes/repeaters against your proposed total system path 400,000...
-
Page 23: Manufacturer Warranties And Limitation Of Liability
Manufacturer Warranties and Limitation of Liability Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free, under normal use and service, from defects in material and workmanship for a period of thirty six months (36) months from the date of manufacture (effective Jan. - Page 24 NOTIFIER 12 Clintonville Road Northford, CT 06472-1610 USA 203-484-7161 www.notifier.com...
