- Page 1 INSTRUCTION MANUAL FOR INSTALLING ROLLING LADDER HARDWARE QG.200-300-500-700 SERIES HARDWARE 24 River Road • Bogota, NJ, 07603 • 1.800.631.8375 • www.outwater.com...
-
Page 2: Step 1: Track Installation
End Caps. FIGURE 1A FIGURE 1B IF NOT USING A SPLICE KIT TO CONNECT MULTIPLE TRACKS, OR INSTALLING END CAPS, SKIP TO PAGE 4 FOR TRACK INSTALLATION. Outwater Industries, Inc. assumes no liability for improper installation. Page 2... - Page 3 Secure the end cap to the track using the supplied 1/4”-20 KD bolt and a 4mm Allen wrench (see Figure 3C). End result is Figure 3D. FIGURE 3A FIGURE 3B FIGURE 3C FIGURE 3D Outwater Industries, Inc. assumes no liability for improper installation. Page 3...
- Page 4 Use an accurate leveling device to ensure that the horizontal locations of the bracket and track are properly aligned. (Figure 6) FIGURE 6 Outwater Industries, Inc. assumes no liability for improper installation. Page 4...
-
Page 5: Surface Preparation
Slide two plywood spacers under the ladder side rails (Figures 5-6 next page). (Only use two spacer for this operation. Additional spacers can result in uneven side rails). FIGURE 3 FIGURE 4 Outwater Industries, Inc. assumes no liability for improper installation. Page 5... - Page 6 Begin fastening, pushing the side rail down in the tight contact with the plywood spacers. (Figure 11) Completely fasten each step (both sides) before moving onto the next step. (Figure 12) FIGURE 11 FIGURE 12 Outwater Industries, Inc. assumes no liability for improper installation. Page 6...
- Page 7 Using a Vix bit or similar self-centering drill guide, drill a pilot hole into the edge of the ladder for the (2)#10 x 3/4” flat-head, Phillips-drive screws. Secure each Upper Hardware Assembly to the top of the ladder (Figures 17-18). FIGURE 16 FIGURE 17 FIGURE 18 Outwater Industries, Inc. assumes no liability for improper installation. Page 7...
- Page 8 Install both the bottom roller guides using the included screws and KD bolts and acorn nuts. FIGURE 22 FIGURE 23 Outwater Industries, Inc. assumes no liability for improper installation. Page 8...
- Page 9 To increase sensitivity (need less weight to engage braking mechanism), turn screw counterclockwise. (Be careful not to loosen too much to prevent the spring from falling out). FIGURE 24 FIGURE 25 Outwater Industries, Inc. assumes no liability for improper installation. Page 9...
-
Page 10: Dimensional Specifications
Swivel Top Guides Rolling Hook Top Guides HORIZONTAL RAIL BRACKETS Standard Brake Wheel Contemporary Brake Wheel For Roller and Swivel Top Guides For Hook and Rolling Hook Top Guides Non-Skid Foot Outwater Industries, Inc. assumes no liability for improper installation. Page 10... - Page 11 For 8’ , 9’ 10’ Standard Ladders CURVED RAIL RADIUS DIMENSIONS Hook top hardware cannot be used with curved rails. Rail Diameter = 1” Approximate distance from wall (ladder in climbing position) Outwater Industries, Inc. assumes no liability for improper installation. Page 11...
- Page 12 REV. 08.20.24...
