- Page 1 Enhanced operation S E R I E S Increased functionality Weather Responsive Solar Powered Watering Systems C18 | Q SERIES C36 | Q SERIES irrigatia.com/q Instructions may have been updated / improved, latest version can be found here: MORE SUN =...
-
Page 2: Safety Note
Introduction Thank you for purchasing one of our systems! Over the last decade Irrigatia has constantly been improving and developing its watering systems, with the latest version being the Q Series! • It’s quieter • It’s more efficient • It’s easier to mount / position •... - Page 3 What Comes in The Box and What it Does Controller It controls the system and houses the batteries and The pump starts every 3 hours during daylight and pump, whilst also having the solar panel mounted stops when the batteries fall to 3V. on it.
- Page 4 Inlet Filter Located within the water source, prevents debris Is located at the end of the inlet feed tube. from entering the system and blocking the pump and drippers. Water Level Sensor Checks that there is water to pump / feed into the on the Hand Control Module.
-
Page 5: Installing The Product
Tees Tees are used to connect the tube to produce the specific watering layout you require. The tube needs to be pushed completely on to avoid leakage. Syringe With a short piece of tube attached, this can be used flushing of the pump, should they ever become for the reverse flushing of drippers or the forward blocked. Installing the Product There are four stages to installing the product. - Page 6 Stage 2 – Initial Set Up and Initialisation These instructions detail how the controller needs Once this discharge / initialisation stage is to be installed, along with connection to the water completed, the system will be ready to have the source.
- Page 7 The solar panel can be easily rotated to suit the mounting position / orientation required. 1) R otate the solar panel 90º anticlockwise and gently lift 2cm. 2) R otate 180º anticlockwise and insert back into the controller housing. 3) R otate the solar panel 90º clockwise to lock it in the housing. 3-Batteries Remove the battery cassette from the base of the controller. Insert the three batteries, paying attention to orientation, into the cassette. Push the cassette back into the controller.
- Page 8 Drill a 5.5 mm hole near the top of the water source, or use any pre-made hole, above the waterline but low enough to use the lid normally. Thread one end of tube through the inlet hole and attach the filter to the end. If using the water sensor, a hole of at least 10 mm is required to thread through. Attach water level sensor and tube/filter together using the cable ties provided so that the middle sensor is 2cm above the filter and the bottom sensor is hanging below the filter. The top sensor can be adjusted to give the warning level needed. The tube should now be adjusted so that the filter hangs at least 10cm above the barrel bottom.
- Page 9 Stage 3 – Addition of Watering Network 1-Intialisation complete Initialisation is complete, when upon returning back For now, press the button on the hand control to the controller, you see just the green led flashing module, for 3 seconds, and turn the system OFF. and either 3h/2h/1h being displayed. The system is now ready to have a watering network added to it.
- Page 10 FLOWER & VEGETABLE BED WATERING KIT REQUIRED: C18Q: 1 set up (as shown) + 12m Seep Hose C36Q: 2 set ups MAX 2m (as shown + 24m Seep Hose) Water Inlet Using seep hose MAX 1m and drippers to water beds and plants in mixed garden GREENHOUSE WATERING...
- Page 11 Anti-Siphon Device Install the anti-siphon device if the first dripper is lower than the water source. It should be fitted to the water out tube between the pump and first dripper and must be higher than the water source. Its purpose is to prevent further dripping once the pump has stopped. It is a one-way valve which works by opening to allow air into the tube to break the siphon when the pump stops. Install if in any doubt, since it will not do any harm to how the overall system works.
- Page 12 Drippers cannot be installed more than 5m above the With 36 drippers installed, they should all be bottom of the water source. approximately level. With 18 drippers installed, there should be no more If a dripper is not currently needed it can be removed than 2m difference in height between the highest and the stopper inserted.
- Page 13 Stage 4 – System Operation With the batteries initialised and the watering network added, the system can now be operated. 1-Operating the System Pressing the button on the Hand Control Module for Red LED Flashes every 5 seconds for low priority 3 seconds will turn the system on, or off.
- Page 14 LCD Screen and Display Codes Displays the time to next watering (3-1 hours) and (3h/2h/1h), with a press of the button, it will show the set point (1-9) and error codes. the set point, with a further press of the button, the set point can then be changed. Default display is the duration to next watering Code Definition Pump Action Required 1d-9d Set point Day Watering Can run None 1n-9n Set point Night Watering Can run None...
- Page 15 Night Watering The system can water at “night”, technically just As per day use, the watering set point level is after “dusk”. adjusted by multiple presses of the button on the Hand Control Module, so 1n through to 9n, we Via the solar panel, because it essentially stops suggest that you start at 6n and adjust from there. charging due to the sun going down, it knows when “dusk” occurs each day.
- Page 16 More information can be found at: irrigatia.com/how-it-works C18 | Q SERIES C36 | Q SERIES For further information on this or any of the other products in our range, please visit: irrigatia.com Irrigatia Limited Norwoods, Long Drax, Selby, North Yorkshire, YO8 8TA United Kingdom Telephone: +44 (0) 333 301 0415 Irrigatia B.V. Neonweg 12 E, 3812 RH, Amersfoort, Netherlands...
