- Page 1 OPERATING INSTRUCTIONS Product group: Controller Product type: Slimline Version: 20rev.7 SunDisc Solar Systems B.V. e-mail info@sun-disc.nl internet www.sun-disc.nl Dealer :...
- Page 2 8. The system will fill up after about 15 minutes and, if the pump is in manual mode, the SunDisc controller can be put into automatic mode by pressing the “pump” icon button a second time. While the pump is filling the system, we recommend that you check the panel field for possible leaks.
- Page 3 The VDH manual provides instructions as to how you can adjust the maximum temperature settings of the pool water. Upon delivery, the maximum operating temperature of the Slimline is set at 32°C, using the internal parameters. In other words, the system shuts down when it reaches this temperature.
- Page 4 25mm compression fittings on each collector. After 24 hrs the compression fittings can be reconnected. Thank you for choosing to purchase a SunDisc solar panel system, we hope you have endless hours of enjoyment and relaxation in your swimming pool.
- Page 5 The instructions below are designed to assist the installer in connecting the SunDisc Slimline controller Panel sensor connecting nipple (including temperature sensor): Secure the connecting nipple (tee) to the panel's return line in a way that allows it to be in the direct path of the sun's rays for most of the day or for the same portion of the day that the panels are able to collect energy from the sun.
- Page 6 Cable glands 2x M12 + 2x M16 pre-assembled Conductive paste Paste for heat conduction 326*000001 ( 1 box ) 3/4" 90-degree PP tee 5047000034 Cross-over 3/4" x 1/2" (PP reducer ring) 5027034012 25 mm Simplast 8030886525 SunDisc Solar Systems B.V. 20rev.7...
