MADE IN
THE UK
Goal Posts
Installation Guide
Please check off all your parts against the CAD drawing you have been supplied. Check for both
quality and quantity. Any discrepancies or quality issues need to be reported within 24 hours
from receipt of delivery.
Profiles
Goal Post
End Plate
Cover Trims
Bracket
Fixings - Nuts, Bolts, Self Drillers
1
Advertisement
Related Manuals for Milwood Group Goal Posts
Summary of Contents for Milwood Group Goal Posts
- Page 1 MADE IN THE UK Goal Posts Installation Guide Please check off all your parts against the CAD drawing you have been supplied. Check for both quality and quantity. Any discrepancies or quality issues need to be reported within 24 hours from receipt of delivery.
-
Page 2: Tools Required
Goal Posts Tools Required Impact Driver Spirit Level Rubber Mallett Drill Digging Equipment Socket Set Step Ladders Masonry Drill Bits Chop saw Masonry Drill with aluminium blade, recommended 60 to 80 tooth YOU NEED YOUR CAD DRAWING AVAILABLE TO PROCEED WITH YOUR INSTALLATION... - Page 3 Goal Posts Installation Instructions Posts need to be concreted in ground. We recommend using a 600x600x600mm hole with C4 concrete. Please note that the goal post sections weigh 11kg per Meter. Please use suitable lifting techniques and manual handling methods.
- Page 4 Goal Posts Installation Instructions 2. Goal post cross member Slide bolts into the bolt channels for the goalpost uprights and install the angle brackets. Do not fully tighten the nuts at this time. Slide bolts into bolt channels on the cross member prior to lifting the cross member into position.
-
Page 5: Post Install
Goal Posts Installation Instructions 3. Place cover trims Gently tap the cover trims into place. You have now completed your 2 post goal post system. 3 Post install 4. Goal post cross member On a system that has 3 upright posts and a joint in the cross member the joint must be placed on top of an upright post. - Page 6 Goal Posts Installation Instructions Attach the cross member to the upright post as before but only use half of the post. Take the second cross member and locate onto joining plates and slide into position. No fixings are required. The 2 cross member sections will be secured in place when the wall plate is installed.
