Summary of Contents for Milwood Group FX
- Page 1 Installation Manual for Umbrella Type FX...
-
Page 3: Service Information
Service Information In case of questions or reclamations please fill out the information below, so that you have access to it when needed. Umbrella Type/Size: Serial number:... - Page 4 Please note that the umbrella type FX has a maximum wind load of 40km/h. In windy and especially in gusty conditions, the umbrella must be closed! Unsupervised umbrellas must not be opened!
-
Page 5: Contents Of Shipment
Ground Fixing: The in-ground sleeve and the base plate need to be installed as detailed in the installation instructions enclosed with the goods. The installation must be carried out by a qualified engineer in accordance with local regulations. Handling the Umbrella: ›... - Page 6 Location of the In-Ground Sleeve, Mobile Base or Base Plate: Please be aware that the umbrella type FX has a side mast. Carefully select the precise location in which you intend to install the in-ground sleeve, mobile base or base plate for umbrella .
- Page 7 Installation of the Umbrella with Sleeve/Base Plate or Mobile Base with Hinge: (Picture a) › Loosen both fixing- and clamping screw on the upper sleeve just enough so that the mast can easily slide in. › Remove the sleeve screw that fixes the in-ground and upper sleeve together and flip the upper sleeve around by 90°.
- Page 8 Umbrella Type FX Open the umbrella › Remove the securing strap. › Open the umbrella using either the crank handle supplied or a portable electric drill and Allen key bit. Ensure that you open the umbrella far enough for all segments of the membrane to come under tension, while keeping an eye on the stop screw at the top of the telescope to avoid over-tensioning.
- Page 9 Closing the umbrella: › When closing the umbrella, keep an eye on the shear mechanism to avoid damage to the fabric! It must be ensured that the fabric does not come between the scissor mechanism and get stuck. Once the membrane fabric approaches the scissor mechanism, stop the closing process and pull the fabric out again, now you can continue the closing process until the umbrella...
- Page 12 We thank you for the trust you have placed in our products and wish you many years of joy with your umbrella.
