KETELESE T3F Instruction Manual

22-channel frs two way radio
Hide thumbs

Advertisement

Table of Contents

Instruction Manual
22-Channel FRS Two Way Radio
KETELESE T3F
Main Features
●
Frequency: 462.5500～462.7250MHz, 467.5500 ~ 467.7250
MHz
● High/Low TX Power configured to designated channels
● 22 channels
● 121 codes (38 CTCSS & 83 CDCSS)
● Group function
● 3 VOX levels
● 10 Call tones
● Monitor
● Scan
● Key lock function
● 1100mAh Li Polymer Battery
● Flashlight
● NOAA & Weather Alert

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T3F and is the answer not in the manual?

Questions and answers

Related Manuals for KETELESE T3F

Summary of Contents for KETELESE T3F

  • Page 1 Instruction Manual 22-Channel FRS Two Way Radio KETELESE T3F Main Features ● Frequency: 462.5500～462.7250MHz, 467.5500 ~ 467.7250 ● High/Low TX Power configured to designated channels ● 22 channels ● 121 codes (38 CTCSS & 83 CDCSS) ● Group function ● 3 VOX levels ●...
  • Page 2 Overview LCD display Earphone & Charger Jack Push-To-Talk (PTT) key Up / Monitor key Down / Scan key Power / Volume Knob Group key Menu / WX key Call Tone /Key-Lock key Microphone Speaker Antenna Flashlight LED Flashlight key GROUP Button – Enable the radio transmitting on GROUP-channel which is different from the PTT-channel.

  • Page 3: Lcd Display Icons

    Press key to choose the LCD Display Icons Press the MENU key 1 time, menu function. enter into the menu selecting mode. (Press and hold the MON key Press and hold the WX key for 3s, to enter into the MON mode. ) enter into the WX mode.

  • Page 4: General Operations

    GENERAL OPERATIONS 4. Do not charge or charge battery in hazardous location. Install / Removing Battery door and Belt Clip 5. Do not short-circuit the terminals. Installing Battery Door ● Put the battery door flat on the radio, then use flathead screwdriver to hit the battery door screw just like the image shows on the right.

  • Page 5: Charging Batteries

    Notes: CHARGING BATTERIES 1. When charging, the temperature should be between When the “Battery level is low, that is the icon need to charge the battery with the enclosed type-C Y-cable. 5℃ ~40 ℃,otherwise it may cause the leakage or even damage the battery.
  • Page 6 ● When you press the PTT key, you can’t listen to other radios. GENERAL OPERATIONS Make sure you do not press PTT key for listening. TRANSMITTING RANGE ● Adjust volume control if necessary. ● The talk range depends on the environmental and terrain. It will reach (up to about 5km) in wide open spaces, without GROUP FUNCTION ( Dual Channel Standby and Either of Dual Channels Transmitting)
  • Page 7 9. MONITOR FUNCTION SELECT MAIN CHANNEL ● Press and hold the key for 3 seconds to have the unit To select the main channel ● Press the sound signal or noise, whichever occurs on the main channel. key 1 time, Main channel number will flash. ●...

  • Page 8: Roger Beep

    ● Press the 4. GROUP CTCSS/CODE FUNCTION key 7 times, LCD displays the icon. ● Press To set GROUP CTCSS/CDCSS code to turn the Roger beep on or off. ● Press the ● Press the GROUP or PTT key to confirm and revert back to key 4 times, GROUP CTCSS/CDCSS code will flash.
  • Page 9 Setting the WX Alert The radio can be set to respond to NOAA Weather Radio emergency messages. A special alarm tone sounds an alert and turns on the WX to give you immediate weather and emergency information. ● In WX mode, press 2 times and the icon shows.
  • Page 10 GMRS Channel Configuration Chart Default Frequency Default Associated TX Power Frequency CH. No. CH. No. Associated TX Power Option (MHz) Code No. Option (MHz) Code No. 462.5625 High 462.5750 High 462.5875 High 462.6000 High 462.6125 High 462.6250 High 462.6375 High 462.6500 High 462.6625...
  • Page 11 CTCSS Code Frequency Chart Code Freq. Code Freq. Code Freq. Freq. Code Freq. Freq. Code Freq. Code Freq. (Hz) (Hz) (Hz) (Hz) (Hz) (Hz) (Hz) (Hz) 67.0 88.5 110.9 141.3 179.9 233.6 71.9 91.5 114.8 146.2 186.2 241.8 74.4 94.8 118.8 151.4 192.8...

  • Page 12: Safety And General Information

    Medical Devices https://apps.fcc.gov/oetcf/eas/reports/GenericSearch.cfm If you use a personal medical device, such as a pacemaker or search for FCC ID: 2A4CJ-T3F to gain further information hearing aid, consult the manufacturer of your device to include SAR Values. determine if it is adequately shielded from RF energy. Your physician may be able to assist you in obtaining this information.

  • Page 13: Electromagnetic Interference/Compatibility

    FCC allowable limits, always adhere to the following CAUTION guidelines: During transmissions, your KETELESE radio generates RF energy that can possibly cause inference with other devices or DO NOT operate the radio without a proper antenna systems.
