Summary of Contents for Aiwa HS-PX517
- Page 1 HS-PX517 SERVICE MANUAL STEREO BASIC TAPE MECHANISM : 7ZM-1 P3NF CASSETTE PLAYER S/M Code No. 09-013-439-1N1...
-
Page 2: Specifications
SPECIFICATIONS Maximum output: 4 mW + 4 mW (EIAJ 16 ohms) Load impedance: 16 - 80 ohms Power source: DC 1.2 V using supplied rechargeable battery NB-5G, DC 1.5V using an R6 (AA) dry cell battery, AC house current using an optional AC adaptor Maximum outside dimensions: 79.1 (W) x 110 (H) x 20.8 (D) mm in.) -
Page 3: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST 1 / 1 REF. NO. PART NO. REF. NO. PART NO. DESCRIPTION KANRI DESCRIPTION KANRI C206 87-016-526-080 C-CAP,S 0.47-16 BK C207 87-016-460-080 C-CAP,S 0.22-16 B C208 87-016-460-080 C-CAP,S 0.22-16 B 87-A21-179-040 C-IC,TA2123AF 87-A20-818-040 C-IC,NJM2185AV C301 87-012-286-080 CAP, U 0.01-25 C302 87-A10-260-080... -
Page 4: Transistor Illustration
CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code Value of resistor Chip resistor Dimensions (mm) Symbol Wattage Type Tolerance Resistor Code Form 1/16W 1005 0.35 1/16W 1608 0.45 1/10W 2125 1.25 0.45 1/8W 3216 0.55 TRANSISTOR ILLUSTRATION 2SA1162 2SC2712 2SC3326... - Page 5 WIRING – 5 –...
- Page 6 SCHEMATIC DIAGRAM – 6 –...
- Page 7 IC BLOCK DIAGRAM – 7 –...
- Page 8 IC DESCRIPTION IC, ML63512A-A04TB Pin No. Pin Name Description AF IN Sound detection input terminal. SCLK Serial clock input terminal. (Not used) MUTE H : MUTE OFF L : MUTE ON SDATA Serial data output terminal. (Not used) F/R CONT H : REV Mode L : FWD Mode HI-SP-SW...
- Page 9 Pin No. Pin Name Description HI-SP L H : HI-SP L level L : HI-SP H level POWER ON H : POWER ON L : POWER OFF DSL 1 Output ON when in DSL 1 mode. (Not used) DSL ON Output ON when in DSL ON mode.
-
Page 10: Mechanical Exploded View
MECHANICAL EXPLODED VIEW 1 / 1 SH-CHAS, 7ZM-1 HS-PX517 AEINF (FileName:EXP.EPS) 13/3/10 AHK-5 – 10 –... -
Page 11: Mechanical Parts List
MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. REF. NO. PART NO. DESCRIPTION KANRI DESCRIPTION KANRI 8B-HK6-001-010 LID,CASS GLD AE ASSY 8B-HK6-012-010 WINDOW,CASS AE 8Z-HK4-228-110 SPR-P,LID 8A-HK5-206-110 HLDR,LID 8Z-HK4-210-110 NUT, B-BOX 8Z-HK4-206-210 HLDR,ARM ASSY 8A-HK5-207-010 LEVER,EJECT 8A-HK5-201-010 HLDR,BAT 8A-HJ2-207-010 BAT-CONTACT,(-) 8A-HK5-202-010... -
Page 12: Tape Mechanism Exploded View
TAPE MECHANISM EXPLODED VIEW 1 / 1 HEAD FLEX. C.B BRG, 7ZSIA – 12 –... -
Page 13: Tape Mechanism Parts List
TAPE MECHANISM PARTS LIST 1 / 1 REF. NO. PART NO. REF. NO. PART NO. DESCRIPTION KANRI DESCRIPTION KANRI 1 87-ZM1-230-010 HLDR,HEAD 2 87-ZM1-254-110 ARM ASSY,PINCH R 3 87-ZM1-287-010 SPR-T,PINCH BACK R 4 87-ZM1-285-010 SPR-T,PINCH R 5 87-ZM1-252-110 ARM ASSY,PINCH L 6 87-ZM1-286-010 SPR-T,PINCH BACK L 7 87-ZM1-284-010... - Page 14 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9630472 0251431 Printed in Singapore...
- Page 15 SERVICE MANUAL STEREO BASIC TAPE MECHANISM : 7ZM-1 P3NF CASSETTE PLAYER • This Service Manual contains information about the difference between HS-PX517<YH> and HS-PX517<AE>. If requiring other information, see Service Manual of HS-PX517<AE>, (S/M Code No. 09-013-439-1N1). S/M Code No. 09-014-439-1S1...
-
Page 16: Specifications
SPECIFICATIONS Maximum output: 4 mW + 4 mW (EIAJ 32 ohms) Power sources: DC 1.2 V using supplied rechargeable battery NB-5G, DC 1.5 V using an R6 (AA) dry cell battery, AC house current using an optional AC adaptor Maximum outside dimensions: 79.1 (W) x 110 (H) x 20.8 (D) mm in.) (excluding projecting parts and controls) - Page 17 ELECTRICAL MAIN PARTS LIST 1 / 1 REF. NO. PART NO. REF. NO. PART NO. DESCRIPTION KANRI DESCRIPTION KANRI C309 87-012-286-080 CAP, U 0.01-25 C310 87-010-805-080 CAP, S 1-16 C606 87-010-805-080 CAP, S 1-16 87-A21-179-040 C-IC,TA2123AF 87-A20-961-040 C-IC,MM1279XV C701 87-010-805-080 CAP, S 1-16 C702 87-010-805-080...
- Page 18 WIRING – 4 –...
- Page 19 SCHEMATIC DIAGRAM – 5 –...
- Page 20 MECHANICAL EXPLODED VIEW 1 / 1 SH-CHAS 7ZM-1 HS-PX517 YHS1SF (FileName:EXP.EPS) 13/3/25 BHK-6 – 6 –...
- Page 21 MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. REF. NO. PART NO. DESCRIPTION KANRI DESCRIPTION KANRI 8A-HK5-053-010 LID,CASS ASSY AH C 8B-HK6-003-010 WINDOW,CASS 8Z-HK4-228-110 SPR-P,LID 8A-HK5-206-110 HLDR,LID 8Z-HK4-210-110 NUT, B-BOX 8Z-HK4-206-210 HLDR,ARM ASSY 8A-HK5-207-010 LEVER,EJECT 8A-HK5-201-010 HLDR,BAT 8A-HJ2-207-010 BAT-CONTACT,(-) 8A-HK5-202-010 HLDR,CONT...
- Page 22 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9630472 0251431 Printed in Singapore...
- Page 23 SERVICE MANUAL STEREO BASIC TAPE MECHANISM : 7ZM-1 P3NF CASSETTE PLAYER • This Service Manual contains information about the difference between HS-PX517<AH> and HS-PX517<AE>. If requiring other information, see Service Manual of HS-PX517<AE>, (S/M Code No. 09-013-439-1N1). S/M Code No. 09-014-439-1S2...
- Page 24 SPECIFICATIONS Maximum output: 4 mW + 4 mW (EIAJ 32 ohms) Power sources: DC 1.2 V using supplied rechargeable battery NB-5G, DC 1.5 V using an R6 (AA) dry cell battery, AC house current using an optional AC adaptor Maximum outside dimensions: 79.1 (W) x 110 (H) x 20.8 (D) mm in.) (excluding projecting parts and controls)
- Page 25 MECHANICAL EXPLODED VIEW 1 / 1 SH-CHAS, 7ZM-1 HS-PX517 AHISF (FileName:HSPX517.EPS) 13/4/15 BHK-6 – 3 –...
- Page 26 MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. REF. NO. PART NO. DESCRIPTION KANRI DESCRIPTION KANRI 8A-HK5-053-010 LID,CASS ASSY AH C 8B-HK6-003-010 WINDOW,CASS 8Z-HK4-228-110 SPR-P,LID 8A-HK5-206-110 HLDR,LID 8Z-HK4-210-110 NUT, B-BOX 8Z-HK4-206-210 HLDR,ARM ASSY 8A-HK5-207-010 LEVER,EJECT 8A-HK5-201-010 HLDR,BAT 8A-HJ2-207-010 BAT-CONTACT,(-) 8A-HK5-202-010 HLDR,CONT...
- Page 27 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9630472 0251431 Printed in Singapore...
