ECONOMY SERIES HYDRAULIC

MOBILE LIFT TABLE

MSLTECON2817

840026

Operator's Manual

Read the Operator's Manual entirely. When you see this

symbol, the subsequent instructions and warnings are

serious follow without exception. Your life and the lives

of others depend on it!

Need help?

Do you have a question about the ECONOMY MSLTECON2817 and is the answer not in the manual?

Questions and answers

Summary of Contents for Titan Attachments ECONOMY MSLTECON2817

Page 1 ECONOMY SERIES HYDRAULIC MOBILE LIFT TABLE MSLTECON2817 840026 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION 1. Do not exceed 500 lb. max weight capacity. Be aware of dynamic loading! Sudden load movement may briefly create excess load causing product failure. 2. Use only on flat, level, and hard surface capable of supporting the Lift Table and any item(s) placed on Table.
Page 3 PARTS DIAGRAM / EXPLODED VIEW...
Page 4 PART DESCRIPTION PART DESCRIPTION PROTECTIVE MAT (26) RUBBER PAD 4” LOCKING SWIVERL LIFT TABLE (27) CASTER SCISSOR ARM (28) WASHER 8 ROLLER (29) SPRING WASHER 8 RETAINING RING 12 (30) HEX BOLT M8*16 (31) HANDLE (32) PULL ROD RETAINING RING 14 (33) CONTROL LEVER BASE...
Page 5 ASSEMBLY INSTRUCTIONS The Hydraulic Lift Table requires some assembly after you unpack it. 1. Attach [12] Wheel to the lift table using [14] Bolt M8x65, [13] Bushing and [11] Lock Nut M8 2. Attach [23] Pump lever to the lift table using [47] Bolt M8x35, [28] Washer M8 and [25] Nut M8.
Page 6 3. Attach [31] Handle to the lift table using [21] Bolt M8x40.
Page 7 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non- economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims,...
