- Page 1 STANDARD SERIES 51" X 32" HYDRAULIC LIFT TABLE SLTSTAN1T5132 840023 Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
-
Page 2: Safety Information
SAFETY INFORMATION WARNING! If operating the lift table improperly, a person may be seriously injured. Therefore, operate properly according to the following instruction. o Read & thoroughly understand the Instruction Manual completely before using. Follow all safety instructions strictly. o It is necessary to check all safety devices before operation. o Make sure that there are no obstacles in the working area. -
Page 3: Daily Inspection
DAILY INSPECTION Daily inspection is effective to find the malfunction or fault on the lift table. Before operation, check the lift table according to the following points. CAUTION! Do not use the lift table if any malfunction or fault is found. o Check all the terms of WARNING and CAUTION. -
Page 4: Specifications
NOTE ◇ The table is equipped with an aluminum guard to avoid accidental danger. ◇ If aluminum guard strikes an object while the table lowers, stop operation and check the lift table. After making sure no abnormality, strike the UP buttons lightly and then the electric system will function as before. ■... - Page 5 HYDRAULIC CIRCUIT & ELECTRIC PRINICIPLE DIAGRAM...
- Page 6 SERVICE INSTRUCTIONS ■ Do routine check of fasteners, packing and oil leaking. ■ Do routine check of the function of the lift table. ■ Before service the lift table, make sure to turn off the AC power supply. ■ After service it is necessary to check the function of the lift table again. ■...
-
Page 7: Troubleshooting
TROUBLE SHOOTING Note: Before service it is necessary to screw two eyebolts into relevant screw-holes on the basis lest the table lowers accidentally. - Page 8 PARTS DIAGRAM / EXPLODED VIEW...
- Page 13 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non- economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims,...
- Page 14 NEED HELP? CONTACT US FIRST. 1-800-605-7595 info@palletworks.com www.palletforks.com © 2024 Titan Brands...
