Installation and Operation Guide
Part #69-2953-031
© 1998. All rights reserved, Teledyne Instruments, Inc.
Revision Y, January 2025
Use and Disclosure of Data: Information contained herein is classified as EAR99 under the U.S. Export
Administration Regulations. Export, reexport or diversion contrary to U.S. law is prohibited.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GLS and is the answer not in the manual?

Questions and answers

Related Manuals for Teledyne GLS

Summary of Contents for Teledyne GLS

  • Page 1 Installation and Operation Guide Part #69-2953-031 © 1998. All rights reserved, Teledyne Instruments, Inc. Revision Y, January 2025 Use and Disclosure of Data: Information contained herein is classified as EAR99 under the U.S. Export Administration Regulations. Export, reexport or diversion contrary to U.S. law is prohibited.
  • Page 3 Foreword Customer Service Technical Support Other Correspondence EAR99 Technology Subject to Restrictions Contained on the Cover Page...
  • Page 4 EAR99 Technology Subject to Restrictions Contained on the Cover Page...
  • Page 5 GLS Co mpact Sampler Safety Summary Section 1 Safety Summary The ISCO GLS Portable Sampler is a “definite purpose” device, intended for use only with compatible ISCO equipment. Do not use this product with any other manufacturers’ equipment, or for any other purpose.
  • Page 6 GLS Compact Sampler Safety Summary EAR99 Technology Subject to Restrictions Contained on the Cover Page...

  • Page 7: Table Of Contents

    1.1.1 Identifying GLS Components ........
  • Page 8 5.4.1. GLS Self-diagnostics ........
  • Page 9 1-1 GLS Technical Specifications ........
  • Page 10 GLS Compact Sampler Table of Contents EAR99 Technology Subject to Restrictions Contained on the Cover Page...

  • Page 11: Section 1 Introduction

    The liquid detector is also used to halt the sam- pling routine when a full bottle is detected. At the heart of the sampler is the GLS controller. It is environ- mentally sealed to provide protection from accidental submersion and long term exposure to high humidity and corrosive gases.

  • Page 12: Identifying Gls Components

    · Pulse Duration Input Interface (contact Teledyne ISCO’s Special Products Department) • Teledyne ISCO parameter measuring instruments: · Liquid Level Actuator The GLS is designed to meet the needs of general purpose or pri- 1.1.3 Typical Applications ority pollutant sampling in municipal and industrial applica- tions.

  • Page 13: Radio Interference Statement

    Interference-Causing Equipment Regulations. Ce générateur de fréquence radio ISM respecte toutes les exi- gences du Règlement sur le matériel brouilleur du Canada. 1.3 Technical Table 1-1 contains technical specifications for the GLS Compact Sampler. Specifications Table 1-1 GLS Technical Specifications...
  • Page 14 GLS Compact Sampler Section 1 Introduction Table 1-1 GLS Technical Specifications (Continued) Program Memory Non-volatile ROM Flow Meter Signal Requirements 5 to 15 volt DC pulse or 25 millisecond isolated contact closure. Number of Composite Samples to If a maximum number is entered, up to 500. In Continuous Sampling mode,...

  • Page 15: Section 2 Preparing The Gls

    10. Lock the GLS (optional), section 2.9 2.1 Inspecting the Pump Inspect the pump tube before running a program. If the pump tube fails, the GLS will not be able to collect samples. Tube Note The importance of regular tubing replacement cannot be over- stated.
  • Page 16 Cover Figure 2-1 Pump housing cover and thumbscrews Note The GLS will display a pump tube warning as part of the View Log screens when it exceeds 500,000 pump counts. This is the recommended pump tube replacement interval. The pump tube warning is based on a number of pump revolutions.

  • Page 17: Discharge Tube

    • 2.5 and 2 gallon (10 and 7.6 liter) – place the bottle in the GLS base section. • 1 gallon (3.8 liter) – place the bottle deck into the GLS base section. Set the bottle on top of the bottle deck.

  • Page 18: Sample Cooling

    For maximum cooling, fill the base (with the bottle and deck in place) with water and freeze the base section and its contents. 2.5 Installing a Power The GLS must be powered by a 12-Volt DC power source. Teledyne ISCO recommends using one of the following 900 series Source power sources: Batteries –...

  • Page 19: Nickel-Cadmium Battery And Power Pack Position

    4. Power Packs Only – Route the AC line cord though the cen- ter section's Tubing/Cable port. Note If you use a battery to power the GLS, always install a fully charged one before running a program. EAR99 Technology Subject to Restrictions Contained on the Cover Page...

  • Page 20: The Suction Line And Strainer

    60-9003-092 for a complete description of each power source. 2.6 The Suction Line and The suction line carries the liquid from the sampling point to the GLS pump tubing. The GLS is designed to use: Strainer • -inch (6 mm) I.D. Vinyl tubing •...

  • Page 21: Connecting The Vinyl Suction Line

    GLS Compact Sampler Section 2 Preparing the GLS Attach vinyl suction line to the pump tubing with the tube cou- 2.6.3 Connecting the Vinyl pling. Two couplings are available, one for each size of vinyl line. Suction Line Attach the vinyl suction line to the pump tube with the tubing coupler.

  • Page 22: Connecting External Devices

    5 seconds in duration restores the oper- ation. 2.8 Positioning the GLS There are a few considerations when selecting a site for the GLS. The foremost concern should be personal safety. WARNING The installation and use of this product may subject you to hazardous working conditions that can cause you serious or fatal injuries.
  • Page 23 (P/N 60-2954-033). Contact your sales represen- tative or Teledyne ISCO for more information. After the GLS is in place, the strainer and suction line should be properly positioned. The strainer should be placed in the stream so that represen- tative samples are collected.

  • Page 24: Locking The Gls

    4 feet (1.2 m) 2.9 Locking the GLS Access to the inside of the GLS can be easily secured by placing a padlock on the carrying handle. Because the carrying handle must be repositioned before gaining access, locking the handle in an upright position secures the top cover, center section and con- troller, and the base.

  • Page 25: Section 3 Programming

    GLS Compact Sampler Section 3 Programming 3.1 Introduction to GLS This section shows you how to program the GLS. In this section you will find: Programming • The GLS Interface – This explains how you operate the GLS using the keypad and display. Section 3.2.

  • Page 26: The Gls Display

    3.2.2. The GLS Keypad state will determine which buttons are active. 3.3 GLS Operating States The GLS has many states of operation. States of operation can be classified as either “interactive” or “non-interactive.” Interactive States – • • Standby — The display shows “PROGRAM, VIEW LOG,”...

  • Page 27: Programming

    To use the One-button Programming, press: This sequence of buttons must be pressed within 10 seconds. At all times the GLS holds two programs, the Stored program 3.4.2. Stored Programs and the Current program. The Stored and Current program set- tings may or may not be the same.
  • Page 28 Programming Step #1 – Pacing 3.4.3.1 Sample Pacing The GLS displays two pacing options – Time Paced and Flow Paced. Select Time to collect samples at uniform time intervals. TIME PACED Select Flow to collect samples based on flow volumes. An input...
  • Page 29 2 gallon (7.6 liter) ProPak liner 7000 You may use a non-standard bottle in the GLS. When entering the non-standard bottle volume, it is advisable to enter a value less than the total volume. Again, this will reduce the possibility of missed samples and spills.
  • Page 30 Programming Step #5 – Sample Volume 3.4.3.5 Sample Volume Enter the volume to collect at each sampling event. This value must be within the range shown on the GLS display. To enter the SAMPLE VOLUME sample volume: 80 ml (10-930) 1.
  • Page 31 Tip – If you enter an incorrect value, press the Stop button . The GLS will restore the original setting and wait for a new value. 3. Enter the minutes with the number entry buttons. Press the Enter button to accept the minutes setting and advance the cursor to the day setting.

  • Page 32: Setting The Time And Date

    CALIBRATE TO CHANGE This Suction Line display reports the suction line diameter and length. This information must be correct so that the GLS can deliver sample volumes as programmed. Verify that the diameter and length match the suction line in use.

  • Page 33: Calibrating Sample Volumes

    1. Enter the suction line size. 2. Enter the suction line length. 3. If the liquid detector is disabled, the GLS will ask for a manual or “fixed” suction head since it will not be able to calculate the head.

  • Page 34: Calibration Step 1

    . The GLS advances to the Suction 3.6.1. Calibration Step 1 Line Size display. The Suction Line Size is the inside diameter (I.D.) of the suction line tubing. Two sizes of suction line may be used with the GLS: SUCTION LINE SIZE: 6 mm 9 mm •...

  • Page 35: Calibration Step 3

    3.6.3. Calibration Step 3 abled. Since the GLS will be unable to calculate the suction head as it collects each sample, the GLS will ask for a manual or “fixed” suction head. The GLS skips this step when the Liquid Detector is enabled.

  • Page 36: Manual Pump Operation

    1. Enter the measured volume. Press the appropriate number buttons on the keypad. Tip – If you enter an incorrect value, press the Stop button . The GLS will restore the original setting and wait for a new value. 2. Press the Enter button to accept the value.

  • Page 37: Section 4 Running A Program

    CURRENT TIME: 07:49:32 1/10/25 4.3 Sampler Inhibit Before the GLS takes its first sample, it checks the inhibit line of the Flow Meter connector. If the GLS detects a logic low (grounded) level, it will suspend the program until the external device returns the line to a logic high (or open) level.

  • Page 38: Run State Displays

    Note The GLS will not “store” samples while it is inhibited. The GLS takes no action at all when it counts down a complete time or flow-pacing interval.

  • Page 39: Sample Collection Cycle

    If the GLS is in the Continuous Sampling mode, it only displays the next sample number. Errors – If the GLS encounters an error while running a program, the fol- lowing display alternates with the pacing interval countdown display:...

  • Page 40: Pausing Or Stopping A Program

    If the liquid detector finds that this excess amount of liquid is being returned through the liquid path, the GLS stops the program and indicates that the bottle is full. The duration of the post-purge is automatically calculated by the GLS based on the programmed suction line settings.

  • Page 41: Recovering The Sampler

    • A GLS with battery, full sample bottle, and ice may weigh as much as 63 pounds (28.6 kg). • The GLS must be kept level to avoid spilling the bottle’s contents. To prepare a full bottle to return to the lab you must first gain 4.8.2 Preparing the Full...

  • Page 42: Errors

    The GLS can detect program errors or conditions that have 4.8.4 Errors caused it to miss a sample. If the GLS encounters an error con- dition and is still running a program, it alternates the message below with the current display.

  • Page 43: Grab Samples

    (in ml). Press 200 ml (10-9990) the Enter button to continue. 3. The GLS waits for you to prepare to collect a grab sample. GRAB SAMPLE Pull the lower pump tube from the bulkhead fitting. Hold...
  • Page 44 GLS Compact Sampler Section 4 Running a Program EAR99 Technology Subject to Restrictions Contained on the Cover Page...

  • Page 45: Section 5 Servicing The Sampler

    Section 5 Servicing the Sampler 5.1 Servicing the Sampler This section contains instructions necessary to perform routine and preventive maintenance on the GLS and its related compo- nents. The topics are outlined below. Routine maintenance — at user determined intervals •...

  • Page 46: Vinyl Suction Line

    The 2 gallon (7.6 liter) ProPak™ system was developed by Teledyne ISCO to offer the greatest convenience in preparing sample containers for re-use. Simply remove the used liner and place a new one in the holder. Used ProPak liners can be disposed of or recycled.

  • Page 47: Replacing The Pump Tube

    Check the condition of the pump tube regularly and if the tube shows signs of fatigue or wear, replace it immediately. A properly maintained sampler will pro- vide the years of reliable service that is expected of a Teledyne ISCO Sampler. WARNING Pump may actuate without warning.

  • Page 48: Liquid Detector And Pump Housing Covers Removed

    6. Clean the inside of the pump housing if necessary. Note Teledyne ISCO replacement pump tubes are marked with two black bands. These bands are used to correctly locate the tub- ing in the liquid detector and the pump. Position the pump inlet, or short end, in the upper groove of the liquid detector.

  • Page 49: Replacing The Discharge Tube

    Note The peristaltic pump and tube will perform the best when you: – Use Teledyne ISCO replacement pump tubes or bulk tubing. – Install the tube properly, aligning the inside edges of the bands with the outside edges of the liquid detector.

  • Page 50: Servicing Batteries And Power Packs

    GLS to detect an overfilled bottle. Figure 5-1 Discharge tube and tube guide If you are using a battery to power the GLS, Teledyne ISCO rec- 5.2.4. Servicing Batteries and ommends that you install a freshly charged battery before Power Packs starting each program.
  • Page 51 GLS Compact Sampler Section 5 Servicing the Sampler CAUTION The GLS controller contains electronic circuitry that can be damaged by static discharge. Open the controller only in a static-free environment. 4. Lift the front panel slowly so that the connecting wires are not pulled excessively.

  • Page 52: Renewing The Desiccant

    Material Safety Data Sheets are located at the end of this manual. To renew the desiccant: 1. Remove the bag from the GLS controller. 2. Place a sheet of brown paper on a flat metal sheet. You can use a brown grocery bag and a typical cookie sheet.

  • Page 53: Diagnostics And Repair

    If the cause of the problem cannot be determined, the GLS self-diagnostics routine can be used to test the sampler's func- tions.
  • Page 54 “NO” and the GLS returns to the Standby state. To reset the program settings, select YES. The GLS will ask if you are sure. Select YES and the GLS will load the default set- tings and turn itself off. EAR99 Technology Subject to Restrictions Contained on the Cover Page...

  • Page 55: Contacting Teledyne Isco For Assistance

    Technical Service: iscowatersupport@teledyne.com World Wide Web: http://www.teledyneisco.com Should it become necessary to return the GLS to the factory for 5.4.3. Return Instructions repair, please contact Teledyne ISCO first and obtain a Return Material Authorization (RMA). This will aid in the prompt repair and return of the sampler.
  • Page 56 4700 Superior Street Lincoln, Nebraska, USA 68504 Note Your warranty, found in the back of this manual, describes con- ditions under which Teledyne ISCO will pay surface shipping costs. EAR99 Technology Subject to Restrictions Contained on the Cover Page 5-12...

  • Page 57: Section 6 Gls Options

    YES the GLS advances to the password entry displays in CHANGE PASSWORD steps 6 and 7. If you select NO, the GLS retains the exist- ing password and returns to the Standby state. EAR99 Technology Subject to Restrictions Contained on the Cover Page...

  • Page 58: Storing A Program

    Paused state. If the password is incorrect, or if there is no password entered within 60 seconds, the sampler resumes the count down to the next sample. In any case, the GLS logs the missed sample as USER STOPPED PUMP.

  • Page 59: Disable Bottle Full Detection

    The most significant effect is the sample volume accuracy. Although you can calibrate the sample volumes at a fixed suction head, the GLS will be unable to compensate for varying stream levels. Secondly, the GLS will not be able to detect a full bottle.

  • Page 60: Software Updates

    The software is updated by transferring a binary file (.BIN) from a PC to the GLS. This requires the new binary file, a PC-to-GLS connect cable (Teledyne ISCO P/N 60-2954-021), and a program running on your PC.

  • Page 61: Strainers

    60-6700-046 Silastic pump tubing, bulk 10' length, for pump and discharge tubes 60-6700-047 Silastic pump tubing, bulk 50' length, for pump and discharge tubes 60-2954-033 Suspension Harness Assembly, GLS Suction line and strainers 60-9004-378 " ID  10' vinyl suction line with standard weighted polypropylene strainer "...
  • Page 62 GLS Compact Sampler Section 6 GLS Options 60-3004-107 Connect cable, 25', Teledyne ISCO sampler to Teledyne ISCO flow meter 60-5314-301 Connector with 22' cable terminating in two wires, for use with non-Teledyne ISCO flow meters having an isolated contact closure...
