- Page 1 TECHNICAL MANUAL Additional ringtone Art. 1229A Passion.Technology. Design.
- Page 2 Table of contents Warning Description ..................3 Technical specifications ..............4 Installation Art.1229A ..............5 Connections ..................6 1229A connections ...................6 System performance and layouts ..........7...
- Page 3 Description Article 1229A is an audio/video switch unit that can be used in “Building Kit” (exclusively 2-wire), Simplebus Top and Kit Video systems. 8 7 6 5 4 3 2 1 1. Speaker. 2. SW1 Volume adjustment switch. Set the switch to the left to exclude the call ringtone (Privacy function).
- Page 4 Technical specifications GENERAL INFO Product height (mm) Product width (mm) Product depth (mm) MOUNTING/INSTALLATION DIN rail mounted DIN modules (no.) AUDIO/VIDEO SPECIFICATIONS Audio system Audio/video system...
- Page 5 Installation Art.1229A CLACK ! CLACK ! REMOVAL...
- Page 6 Connections 1229A connections VIDEO ENTRY FLOOR DOOR CALL SYSTEM RISER S+ S- 1229A 1214/2C 12/24V AC/DC USE OF RELAY FOR ADDITIONAL RINGERS VIDEO ENTRY SYSTEM RISER 20 m MAX - Use shielded cable for the connection and do not route the cables in the vicinity of heavy inductive loads or power supply cables (230V/400V).
- Page 7 System performance and layouts For further information of system performance and to view installation layouts, click on the type of system that best meets your needs: • Audio/video kit for the creation of audio-video systems for individual residences. • Building Kit audio/video system for the creation of audio-video systems for small apartment blocks.
