Printed Matter No. 9839 1712 01

Publication Date 2023-02-15

Valid from Serial No. -

MWR-KIT

Read all safety warnings and instructions

Failure to follow the safety warnings and instructions may result in

electric shock, fire and/or serious injury.

Save all warnings and instructions for future reference

4027502206

WARNING

MWR-KIT

Product Instructions

Need help?

Do you have a question about the MWR-KIT and is the answer not in the manual?

Questions and answers

Summary of Contents for Atlas Copco MWR-KIT

Page 1 MWR-KIT Printed Matter No. 9839 1712 01 Publication Date 2023-02-15 Valid from Serial No. - Product Instructions MWR-KIT 4027502206 WARNING Read all safety warnings and instructions Failure to follow the safety warnings and instructions may result in electric shock, fire and/or serious injury.
Page 2 Updating the MWR firmware ............... 18 Deleting the MWR firmware.............. 19 Upgrading the MWR-KIT firmware ............ 19 Configuring the MWR-KIT system log .......... 19 Operating Instructions.................. 20 Executing a tightening operation ............ 20 Service ........................ 21 Maintenance Instructions................ 21 © Atlas Copco Industrial Technique AB - 9839 1712 01...
Page 3 Tool calibration required (date)............... 22 Tool calibration required (interval) .............. 22 Tool calibration required (overloaded) ............ 22 Tool hardware error .................. 22 Replace mechanical parts ................ 22 Reconfiguration required ................ 22 Recycling ....................... 23 Environmental regulations ................ 23 Recycling information .................. 23 © Atlas Copco Industrial Technique AB - 9839 1712 01...
Page 4 ■ Damage to parts that occurs as a result of inadequate maintenance or performed by parties other than Atlas Copco or their Certified Service Partners during the warranty period is not covered by the warranty. ■ To avoid damage or destruction of tool parts, service the tool according to the recommended mainte- nance schedules and follow the correct instructions.
Page 5 During the reset process, the current configuration of the MWR-KIT is deleted. Service port The service port allows to connect the MWR-KIT to a PC via network, or directly to the Ethernet port of the PC, to be configured using the Web GUI.
Page 6 Blue LED (B): switched on when an exchange of information between MWR-KIT and MWR using ra- dio frequencies is active. ■ Green LED (G1): switched on when MWR-KIT has an active connection to Power Focus 6000 and a MWR is linked correctly. ■...
Page 7 Altitude: Up to 2000 m Radio module frequencies Refer to the local Regulatory Domain for frequency selection. Europe Number Channel Frequency [MHz] Data rate [bit/s] 868.034 19200 868.297 19200 868.502 19200 868.706 19200 © Atlas Copco Industrial Technique AB - 9839 1712 01...
Page 8 Connect the black termination of the power cable to the OUT 0V interface of the Power Focus 6000. Connect the spring loading termination of the power cable to the MWR-KIT power supply interface. For more information on the controller interfaces, please refer to the Power Focus 6000 Product In- structions.
Page 9 20 cm soit maintenue entre l'appareil et l'opérateur. Installing the unit Install the MWR-KIT on a vertical surface (for example a wall) or an horizontal surface (for example a ta- ble) in one of the following configurations:...
Page 10 Insert the M3x18 screw provided in the installation kit in the designated bracket hole. Slide the 4.5 mm seal over the screw, so that the screw and the bracket are locked together. Insert the screw in one of the screw holes on the MWR-KIT sides and fasten it using a Torx T10 screwdriver.
Page 11 Configuration Instructions Web GUI The MWR-KIT configuration can be changed by using the Web GUI. This user interface allows to config- ure the MWR-KIT and the MWR to use. To access the Web GUI, open a browser and type the MWR-KIT IP address.
Page 12 Connect the MWR-KIT Service port to the PC by Ethernet cable. Configure the PC on the same network of the MWR-KIT. On the PC, open a browser page. Then in the URL box, type the IP address of the MWR-KIT. The Tools page of the MWR-KIT web GUI opens.
Page 13 ■ Region: set the region of the working channels. ■ Channel: set the channel of the MWR-KIT communication. Always update first the communication channel of the MWR, and then the MWR-KIT channel accord- ingly. Service port ■ Service IP: IP address of the MWR-KIT Service port.
Page 14 ■ Extended scan: scan all the available channels. To start the scan of the channels, click on the Start scan button. During the scanning of the channels, the MWR-KIT mode changes from Configuration to Scanning: Tools ■ Info: click on the information icon to display the Tool Details. The icon turns red when there is an ac- tive tool alarm, refer to the paragraph Troubleshooting for more information.
Page 15 From this section it is possible to upload, update and delete MWR firmware versions. Refer to Uploading the MWR firmware [Page 18], Updating the MWR firmware [Page 18] an Deleting the MWR firmware [Page 19]. © Atlas Copco Industrial Technique AB - 9839 1712 01...
Page 16 Linked: status of the MWR. ■ PF6000: serial number of the Power Focus 6000 the MWR is linked with. ■ RSSI: Received Signal Strenght Indication of the busy MWR (indicated in dBm). © Atlas Copco Industrial Technique AB - 9839 1712 01...
Page 17 Connecting a tool Access the MWR-KIT web GUI. From the main menu on the left side of the MWR-KIT page, select Tools. In the Available tools section of the Tool configuration page, click on the Select button of the MWR to link.
Page 18 To exit the Configuration mode and return to the Active mode, click on the Reset button placed in the upper-left part of the page. Uploading the MWR firmware The maximum number of tool firmware versions that can be stored on the SD card of the MWR-KIT is five. Access the MWR-KIT web GUI.
Page 19 Then, click on the Start Scan button. In the upper-left part of the MWR-KIT page, the status changes from the Active mode to the Configuration mode and the progress of the Scanning process is displayed in percentage. The MWR detected during the Scanning process are displayed in the Tools section of the Wrench scan page.
Page 20 Operating Instructions Executing a tightening operation Configure the MWR and the Power Focus 6000 on the MWR-KIT by using the Service port con- nected to the PC Connect the MWR-KIT to the Power Focus 6000 by using the Factory ports of the two devices.
Page 21 MWR-KIT Service Service Maintenance Instructions Cables and connection ports Check the status of the cables and the connections regularly, according to the use of the device. © Atlas Copco Industrial Technique AB - 9839 1712 01...
Page 22 Troubleshooting MWR-KIT Troubleshooting SD card status: Error Solution: restart the MWR-KIT. If the error persists, contact Atlas Copco Service Personnel for assis- tance. Model unsupported Cause: MWR model is not supported by MWR-KIT / Power Focus 6000. Service required Solution: contact Atlas Copco Service Personnel for assistance.
Page 23 Encloser profile Aluminum End cover Aluminum End cover Aluminum Gasket TPE - Thermoplastic Elastomers Wall bracket Steel Spacer spring Stainless steel Spring cable power Stainless steel SD-cover POM - Polyoxymethylene © Atlas Copco Industrial Technique AB - 9839 1712 01...
Page 24 RECYCLE AS Cable Brass Antenna WEEE - Waste of Electrical and Electronic Equipment Label Polycarbonate Light guide panel Polycarbonate WEEE - Waste of Electrical and Electronic Equipment Screw Steel Screw Steel © Atlas Copco Industrial Technique AB - 9839 1712 01...
Page 28 Original instructions © Copyright 2023, Atlas Copco Industrial Technique AB. All rights reserved. Any unauthorized use or copying of the contents or part thereof is prohibited. Atlas Copco Industrial This applies in particular to trademarks, model denominations, part numbers Technique AB and drawings.
