Star Mini Phantom
Interior Undercover Mini LED Light
(Lineum LED Dual Color)
IMPORTANT:
Please read all of the following instructions before installing your new light.
CAUTION: Please be sure to check that your cigarette plug outlet or hard wire is properly
fused with a 5 amp fuse. Testing the light before this fuse is properly
installed will void the warranty on the light.
Due to continuous product improvements, we must reserve the right to change any specifications and information,
contained in this manual at any time without notice. Star Headlight & Lantern Co., Inc. makes no warranty of any
kind with regard to this manual, including, but not limited to, the implied warranties of merchantability and fitness
for a particular purpose. Signal Vehicle Products, Inc. shall not be liable for errors contained herein or for
incidental or consequential damages in connection with the furnishing, performance, or use of this manual.
PATENTS D530,029 and D632,421
ULB9LDC Series
NOTICE
™
PLIT530 REV. C
4/14/16
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Star Mini Phantom ULB9LDC Series
Summary of Contents for Star Mini Phantom ULB9LDC Series
- Page 1 Due to continuous product improvements, we must reserve the right to change any specifications and information, contained in this manual at any time without notice. Star Headlight & Lantern Co., Inc. makes no warranty of any kind with regard to this manual, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
- Page 2 Please Note: These instructions are provided as a general guideline only. Specific mounting, wiring, and/or weather-sealing may be necessary and are the sole responsibility of the installer. Star Headlight assumes no responsibility for the integrity of the installation for this or any of its products.
- Page 3 Mounting Front Windshield Adhesive Mount The hood can be installed such that the cord can exit either side. Route the cord through the appropriate slot and slide the hood onto the back of the light until the hooks on the hood “latch”...
- Page 4 (ULB9S Mounting CONT’D) Optional Reflective Hood Label Installation Practice installing label BEFORE removing backing. 1. Align the notch in the label with the center of the hood taking care that the front edge of the label lines up with the front edge of the hood. 2.
- Page 5 Optional Bracket Mounting (Deck, Mirror, or Suction Cup) (Optional mounting kit 274-ULB9-BKT sold separately) 1. Decide which side you want the cord to exit the light and determine which way you will need to mount the ULB9-BKT to your light. 2.
-
Page 6: Connections And Operation
Connections and Operation ULB9LDC (cig plug version only) The ULB9LDC (cig plug version) can be left plugged into the outlet in your vehicle. Either function can be turned on and off using the lighted power switches on the cord. Note: If one of the patterns is set for Steady, it will override the other if both colors are activated. - Page 7 (Programming CONT’D) PATTERNS The ULB9LDC Series lights are designed with 12 different patterns in one of two phases. The second phase is identical to the first, but flashes opposite from the first. It will only be noticeable when synchronizing two of the ULB9LDC-1 lights (hardwire versions only). After the final pattern is reached, the patterns will cycle through again.
- Page 8 DUAL-FUNCTION FLASHING MODE The ULB9LDC Series lights do have an option that will allow you to program either switch (or power wire) to automatically activate BOTH functions/colors to flash opposite of one another. To do this proceed as follows: • Turn on the switch you want to use to activate dual-color flashing. •...
