Lineum Star Half Phantom
Model ULB18
Dual Color Undercover Interior LED Lightbar
Please Note: These instructions are provided as a general guideline only.
vehicles may require special mounting, wiring, and/or weather-sealing. This is the
sole responsibility of the installer. Star Safety Technologies assumes no responsibility
for the integrity of the installation for this or any of its products.
455 Rochester Street
585-226-9500
www.StarSafetyTechnologies.com
TM
Some
Avon, NY 14414
(F) 888-478-2797
PLIT521 REV C
IMPORTANT: Please read all of the following instructions before installing your new
CAUTION: Please be sure to check that your cigarette plug outlet is properly fused.
Testing the light before this fuse is properly installed will void the
warranty on the light.
WARNING!!!!
Before installing any of the brackets,
slide the enclosed rubber channel
over the front edge of the baffle .
There are several optional mounting brackets that can be used to mount your
™. Each light is packaged with the bracket that was selected at the time the light
Phantom
was ordered. Please review the separate mounting instructions that are included with each
bracket. You can visit www.star1889.com for a detailed list of available mounting brackets
and their known vehicle compatibility.
3/14/24
Star Half Phantom™
LED undercover lightbar.
Care should be taken when positioning this warning light so that the light
and/or cord does not interfere with the proper operation of the driver-side
or passenger- side airbag! Failure to heed this warning may result in
serious or fatal injury.
CAUTION: All of our DC powered warning lights are polarity
sensitive. These lights are polarity protected only if the
appropriate fuse is used. All wires connected to the positive
terminal of the battery should be fused at the battery for their
rated load. Testing the light before this fuse is properly
installed will void the warranty on the light.
Gasket Installation
Mounting
Star Half Phantom™
The
is designed to be mounted on the
inside of your vehicle. It is not intended for exterior
applications and is not warranted against water damage.
It is the sole responsibility of the owner to ensure the warning
light is secure. Check your light every time you enter the
vehicle to ensure that it is mounted securely. The manufacturer
assumes no responsibility for the secure mounting of this light.
-1-
Star Half
