Summary of Contents for Scion xB-Security
- Page 1 SECURITY SYSTEM xB - Security DESIGNED FOR USE WITH YOUR VEHICLE’S REMOTE KEYLESS ENTRY SYSTEM OWNER’S GUIDE Rev. B 09/23/05...
-
Page 2: Table Of Contents
SCION Page 1 To better understand the features and functions of this security system, please read this Owner’s Guide completely prior to use. TABLE OF CONTENTS DESCRIPTION PAGE INTRODUCTION BRIEF DESCRIPTION– SECURITY FEATURES 3, 4 OPERATION ARMING THE SECURITY (except PASSIVE ARMING) DISARMING THE SECURITY (except PASSIVE DISARMING) PASSIVE (AUTOMATIC) ARMING &... -
Page 3: Introduction
Page 2 SCION INTRODUCTION Congratulations on your choice of the xB add-on security system to protect your vehicle! To get the most from the system, we strongly recommend that you read this Owner’s Guide completely to learn all of its features and functions. -
Page 4: Brief Description- Security Features
TRIGGER an ALARM immediately. (If the system was PASSIVELY ARMED, the ENTRY DELAY must pass after opening a door before the ALARM is TRIGGERED.) The xB-Security utilizes RADAR SENSOR. RADAR SENSOR The RADAR SENSOR works synchronized with vehicle theft deterrent system.If somebody intrudes into the vehicle while the vehicle theft... - Page 5 Page 4 SCION FEATURES FUNCTIONS Note (Cotinued) RADAR SENSOR • To avoid false alarm, please disarm alarm before placing large objects, such as suitcases or surfboards, on the roof of the vehicle. • Please disarm the alarm system, or shut off the radar sensor function, before washing the vehicle.
-
Page 6: Operation
SCION Page 5 OPERATION ARMING THE SECURITY (except PASSIVE ARMING) The system may be A in several ways. Do one of the following: RMED Lock the doors with your key: Remove the key from the ignition switch. Exit the vehicle, and close all the doors.* Close the trunk or hatch, if necessary.*... -
Page 7: Disarming The Security (Except Passive Disarming)
Page 6 SCION OPERATION DISARMING THE xB - SECURITY (except PASSIVE DISARMING) The system may be D in several ways. Do one of the following: ISARMED Unlock the doors with your key: Insert the key into the door key switch and turn it toward the rear of... -
Page 8: Passive (Automatic) Arming & Disarming
SCION Page 7 OPERATION PASSIVE (AUTOMATIC) ARMING & DISARMING When the xB -Security is programmed to P , the system will A after the ignition key ASSIVELY is removed and all doors are closed; you do not need to lock the doors. When you come back to your vehicle and open a door, you must insert the key into the ignition switch and turn it to “ON”... -
Page 9: Automatic Rearming
UNLOCKED BY TRUNK OR HATCH ENTRY LIGHT UP FOR 30 PRESSING THE IS OPENED... SECONDS... SYSTEM AUTOMAT- SECONDS UNLOCK BUTTON ICALLY RELOCKS (PRE-ARM), THEN ON THE REMOTE THE DOORS, THEN FLASH WHEN THE CONTROL... THE XB-SECURITY SYSTEM IS ARMED AUTOMATICALLY REARMS. -
Page 10: Alarm Information
SCION Page 9 ALARM INFORMATION ALARM TRIGGERS While the system is A , an A will be T when any of the following occurs: RMED LARM RIGGERED Forcibly opening any door. Manually unlocking a door Manually operating an inside lock button will T... -
Page 11: Alarm Descriptions
Page 10 SCION ALARM INFORMATION ALARM DESCRIPTIONS Regular A LARM When an A is triggered in any way other than initial detection by the R LARM ENSOR ADAR the following occur: The horn sounds repeatedly for 60 seconds. The headlights flash repeatedly for 60 seconds. -
Page 12: Radar Sensor Information
SCION Page 11 RADAR SENSOR INFORMATION RADAR SENSOR CHECK PROCEDURE 1. A the system. Press the LOCK button on the remote control or lock the doors with the key. (Remember, the system will not ARM if any door is open.) 2. -
Page 13: Programming
Page 12 SCION PROGRAMMING The xB -Security is factory-set to not P . To change the system’s operation for P ASSIVELY ASSIVE operation, as well as adjust the E time, follow the procedure below. For more RMING NTRY ELAY information on this feature, please refer to page 7. -
Page 14: Warning And Caution Information
SCION Page 13 Warning • This product is applicable only to vehicles with 12V DC, negative grounding specifications. Do not use in vehicles with 24V specifications. Otherwise, damage to the unit or a fire may result. • Never attempt to disassemble or modify the product. Otherwise, an accident, fire or electric shock may result.
