- Page 1 NewPre3101/3102/3103 Series AI Edge General-Purpose Controller Hardware Installation Manual Publication date: October 2021 Version: V1.2 No. : 112028525...
- Page 2 AI Edge General-Purpose Controller NewPre3101/3102/3103 Series Hardware Installation Manual Disclaimer: Kyland Technology Co., Ltd.. tries its best to make the information in this manual as accurate and up-to-date as possible. However, we cannot guarantee that this manual is completely free of any technical errors or clerical mistakes and reserve the right to amend it without notice to the user.
- Page 3 Notice for Safe Use This product has good and reliable performance within the designed range of use, but it is necessary to avoid damage or destruction caused by man to the device. Before using the device, read this manual carefully to ensure the safety of the user and the device. Please keep this manual after reading for future reference.
- Page 4 Do not operate the device or connect or disconnect cables during lightning weather. Please use the connectors and cables approved by our marketing or technical support personnel to prevent the module functions from being affected due to the non-standard connectors and cables.
-
Page 5: Table Of Contents
Table of Contents 1 Product Overview ........................6 2 Structure and Interface ........................ 8 2.1 Front panel ............................8 2.2 Side panel ............................9 3 Installation..........................11 3.1 Dimension drawing .......................... 11 3.2 Installation methods and procedures ....................12 3.3 Wall-mounted ..........................13 3.4 Install and replace hard disk ...................... -
Page 6: Product Overview
Product Overview 1 Product Overview Edge General-Purpose Controller NewPre3101/3102/3103 Series Edge General-Purpose Controller of Intel Coffee Lake platform developed by our company. Its robust and closed chassis design, fan less but efficient single-ribbed chassis cooling surface, over current and over voltage at the power input and excellent EMC protection, IP30 (3102)/IP40 (3101) protection level make this Series of products used in a variety of harsh environmental sites. - Page 7 Product Overview Electric port Four 10/100/1000Base-T(X) electric ports, RJ45 4 x RS232/485/422 Serial Interface (The mode can be changed through the BIOS) USB Connector Four USB3.0, four USB3.1 One HDMI, DP, VGA interface (support dual display, support 1080P HD display); The Video interface 3102 Series adds an independent graphics card interface DIDO interface...
-
Page 8: Structure And Interface
CCC certification and meets the requirements of the standard. The device is powered by a dedicated interface. 2.1 Front panel AI Edge General-Purpose Controller NewPre3101 Series Figure 1 NewPre3101 front panel labeling diagram AI Edge General-Purpose Controller NewPre3102 Series... -
Page 9: Side Panel
DIDO/CAN interface is an optional interface. LOUT Headphone (10) Microphone (11) Internet interface (12) USB Connector (13) COM1-4 RS-232/485/422 interface (14) Ground screw (15) Power interface 12DV (16) Discrete graphics card interface 2.2 Side panel AI Edge General-Purpose Controller NewPre3101 Series... - Page 10 Structure and Interface 2.5-inch hard disk port Figure 3 NewPre3101 side panel labeling diagram AI Edge General-Purpose Controller NewPre3102 Series 2.5-inch hard disk port Figure 4 NewPre3102 side plate labeling diagram...
-
Page 11: Installation
Installation 3 Installation 3.1 Dimension drawing AI Edge General-Purpose Controller NewPre3101 Series Figure 5 NewPre3101 installation dimension drawing (Unit: mm) AI Edge General-Purpose Controller NewPre3102 Series... -
Page 12: Installation Methods And Procedures
Installation Figure 6 NewPre3102 installation dimension drawing (Unit: mm) Note: The device casing is part of the whole machine cooling system, the casing will be hot during normal operation, please do not cover the casing when the device is working. ... -
Page 13: Wall-Mounted
Installation 5) The installation environment should meet the requirements of the authority. Do not touch the device directly with your hands to avoid personal injury. 6) Only professionals or trained and qualified personnel can install, replace and maintain the device. Warning: In a high-temperature environment, the bios enables the high-temperature protection function. -
Page 14: Install And Replace Hard Disk
Installation Figure 7 Wall-mounted installation diagram Wall-mounted removal Step 1. According to the following figure arrow 2 pointing to the reverse, using a screwdriver to loosen the four screws fixed, move the device upward until the screws into the Ф10 part of the device wall-mounted hole, and then the wall-mounted hole through the loosened four screws, the device can be detached from the wall or cabinet wall. - Page 15 Installation panel. Step 2. Insert the assembled 2.5-inch solid state hard disk support into the hard disk slot. Step 3. Install the HDD panel and tighten the screws using a screwdriver. Hard disk replacement 2.5-inch solid-state hard disk replacement Step 1.
-
Page 16: Wire
Wire 4 Wire 4.1 10/100/1000Base-T(X) Ethernet interface The 10/100/1000Base-T(X) Ethernet interface adopts standard RJ45 connector with adaptive function, which automatically configured 10M/100M/1000M state full-duplex/half-duplex operation mode, and supports MDI/MDI-X self-identification function of the cable, i.e. it can be connected with terminal device and network device using either direct network cable or crossover network cable. -
Page 17: Rs-232 /Rs-485/Rs-422 Interface
Wire Direct cable Cross cable Figure 10 10/100/1000Base-T(X) RJ45 connector direct and cross cable interconnection Description: RJ45 connectors are wired as standard 568B (1-orange white, 2-orange, 3-green white, 4-blue, 5-blue white, 6-green, 7-brown white, 8-brown). 4.2 RS-232 /RS-485/RS-422 interface The RS-232, RS-422, and RS-485 interfaces use DB9 wiring terminal interfaces. The pin definition is shown in the following figure. -
Page 18: Usb Interface
Wire 4.3 USB interface The USB interfaces are located on the front panel of the device and contain four USB3.0 interfaces and four USB3.1 interfaces, all of which use standard A female port. USB interface pin definition is shown in the figure below. Figure 12 USB3.0/ USB 3.1 interface pin number Table 5 USB3.0/ USB 3.1 interface pin definition USB pin... - Page 19 Wire grounding screw 7 / GND G Green component 8 / GND B Blue component grounding screw grounding screw 9 / +5V Power supply (not 10 / GND grounding screw used) 11 / N/C Not used. 12 / SDA Serial data signal 13 / H SYNC Horizontal 14 / V SYNC...
-
Page 20: Dido Interface
Wire Figure 13 HDMI interface pin number Table 6 HDMI interface pin definition HDMI pin Definition HDMI pin Definition TMDS_Data2+ TMDS_Data2- TMDS_Data1+ TMDS_Data1- TMDS_Data0+ TMDS_Data0- TMDS_Clock+ TMDS_Clock- Hot plug detect 4.4 DIDO interface Device pin definition, 8-way DIDO interface. Figure 14 DIDO terminal cable interface diagram Table 7 DIDO pin definition... -
Page 21: Grounding
Wire DIDO pin Definition DIDO pin Definition 24V_FGND 24V_FGND DO3+ DO4+ DO7+ DO8+ CH2- CH2+ CH4- CH4+ CH6- CH6+ CH7- CH7+ CH8+ CH8- 24V_FGND 24V_FGND CANA_2_H CANA_2_L DO1+ DO2+ DO5+ DO6+ CH1+ CH1- CH3+ CH3- CH5+ CH5- CAN_ISO_GND CAN_ISO_GND CANA_1_H CANA_1_L Table 8 DIDO terminal line definition table Cable model: Cable -CN36PIN data cable - Male to male screw type customization... -
Page 22: Power Supply Terminal
Wire housing, which is called the "casing ground". One end of the grounding screw is crimped to the cold crimp terminal and fixed with grounding screw at the "casing ground", and the other end of the grounding screw is reliably connected to the earth. Description: Grounding screw cross-sectional area of 2.5mm or more;... - Page 23 Wire Step 2. Remove the power supply terminal plug from the device. Step 3. Insert one end of the power cable and grounding screw into the power supply terminal as required and secure the power cable and grounding screw. Step 4. Plug the connected power cord back into the corresponding power supply terminal socket of the device.
-
Page 24: Led Indicator State
LED Indicator State 5 LED Indicator State Table 10 Description of indicators on the front panel State Description The input power supply is connected and running properly Power indicator (blue) The input power supply is disconnected or runs abnormally 1000M working state (1000Base-TX) Rate indicator 10/100/1000Base-T(X) -
Page 25: Basic Performance And Specifications
Basic Performance and Specifications 6 Basic Performance and Specifications Power supply Power supply Input rated voltage range Input maximum voltage range identification 12VDC 12VDC Access terminal 4 core 5.08mm spacing plug out wiring terminals Nominal power Nominal power 65W (3101) /350W (3102 nominal power with independent graphics card) Mechanical structure Casing All-metal unibody... - Page 26 Customer service hotline: 010-88796676 Fax: 010-88796678 Website: http://www.kyland.com.cn Email: services@kyland.com.cn For more information about KYLAND products, please visit our website: http://www.kyland.com.cn http://www.kyland.com...
