NewPre2100 5G
Edge General-Purpose Controller
Hardware Installation Manual
Publication date: April 2022
Issue: V1.2
No. : 112028563
Publication unit: Kyland Technology Co., Ltd.
Address: Floor 9, Building 2, Yard 30, Xishanhui, Shijingshan
District, Beijing
Website:
http://www.kyland.com.cn
http://www.kyland.cn
Customer service hotline: (+8608) 88798888
Email:
support@kyland.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NewPre2100 5G and is the answer not in the manual?

Questions and answers

Related Manuals for KYLAND NewPre2100 5G

Summary of Contents for KYLAND NewPre2100 5G

  • Page 1 NewPre2100 5G Edge General-Purpose Controller Hardware Installation Manual Publication date: April 2022 Issue: V1.2 No. : 112028563 Publication unit: Kyland Technology Co., Ltd. Address: Floor 9, Building 2, Yard 30, Xishanhui, Shijingshan District, Beijing Website: http://www.kyland.com.cn http://www.kyland.cn Customer service hotline: (+8608) 88798888 Email: support@kyland.com...

  • Page 2: Preface

    Preface This manual provides you with hardware installation instructions for the NewPre2100 5G Edge General-Purpose Controller.

  • Page 3: Legal Statement

    Kyland Technology Co., Ltd.., and you shall strictly abide by the confidentiality obligation; Without the prior written consent of Kyland Technology Co., Ltd.., you may not disclose the contents of this Manual to or provide it to any third party for use.
  • Page 4 4. If you find any technical errors or clerical errors in this document, please contact Kyland Technology Co., Ltd.., and we will try our best to correct them in time. 5. Infringement shall be prosecuted.
  • Page 5 Notice for Safe Use This product has good and reliable performance within the designed range of use, but it is necessary to avoid damage or destruction caused by man to the device. Before using the device, read this manual carefully to ensure the safety of the user and the device. Please keep this manual after reading for future reference.
  • Page 6  Do not operate the device or connect or disconnect cables during lightning weather.  Please use the connectors and cables approved by our marketing or technical support personnel to prevent the module functions from being affected due to the non-standard connectors and cables.

  • Page 7: Table Of Contents

    Table of Contents Preface............................2 Legal Statement ..........................3 1 Product Overview ........................9 2 Structure and Interface ......................11 2.1 Front panel ............................11 2.2 Side panel ............................13 2.3 Top panel ............................14 3 Installation..........................16 3.1 Dimension drawing .......................... 16 3.2 Installation methods and procedures ....................
  • Page 8 7 Basic Performance and Specifications ..................32...

  • Page 9: Product Overview

    5G field applications. The NewPre2100 5G Edge General-Purpose Controller supports either card rail or wall mount, and the following configurations are supported for different device types.
  • Page 10 4-way DI/DO interfaces (2-way DI/DO interfaces, available only when selecting DI/DO interface NewPre2100-P521-M1-D0-W3) Other interfaces Two SIM card slots Operating temperature -40℃～+75℃ PWR1-PWR2: power input Terminal interface: 24V+, 24V-: 24V voltage input...

  • Page 11: Structure And Interface

    2 Structure and Interface Note: In order to maintain the cleanliness of the interface and to protect the operational performance of the device, it is recommended that users order a separate interface dust cover (optional) according to the form of the device interface.
  • Page 12 USB1 USB3.0 communication interface 1 USB2 USB3.0 communication interface 2 (8)~(13) 10/100/1000Base-T(X) Ethernet communication interfaces 1 to 6 (14) AT1~AT4 5G antenna installation interface (15) WIFI antenna installation interface (16) CAN1 CAN communication interface 1 (17) CAN2 CAN communication interface 2 (18) S1~S2 RS-232/485/422 communication interface...

  • Page 13: Side Panel

    Figure 2 NewPre2100-P521-M1-D0-W0 front panel labeling diagram Table 3 NewPre2100-P521-M1-D0-W0 front panel labeling instructions Identification Description PWR1 24V power input 1 indicator PWR2 24V power input 2 indicator Operation indicator Alarm indicator Reset Reset button USB1 USB3.0 communication interface 1 USB2 USB3.0 communication interface 2 (8)~(11)

  • Page 14: Top Panel

    Figure 3 NewPre2100-P521-M1-D0-W3 / NewPre2100-P521-M1-D0-W0 side panel labeling diagram 2.3 Top panel  5G Edge General-Purpose Controller NewPre2100-P521-M1-D0-W3 NewPre2100-P521-M1-D0-W0 Top panel...
  • Page 15 Figure 4 NewPre2100-P521-M1-D0-W3 / NewPre2100-P521-M1-D0-W0 top panel labeling diagram Table 4 NewPre2100-P521-M1-D0-W3 / NewPre2100-P521-M1-D0-W0 top panel labeling instructions Identification Description SIM1 SIM card slot 1 SIM2 SIM card slot 2 Card cover CONSOLE CPU debugging serial interface Power interface 24V Grounding screw...

  • Page 16: Installation

    3 Installation 3.1 Dimension drawing  5G Edge General-Purpose Controller NewPre2100-P521-M1-D0-W3 NewPre2100-P521-M1-D0-W0 (The panel takes NewPre2100-P521-M1-D0-W3 as an example, the same as later) Figure 5 NewPre2100-P521-M1-D0-W3 / NewPre2100-P521-M1-D0-W0 installation dimension drawing (Unit: mm)

  • Page 17: Installation Methods And Procedures

    Note:  The device casing is part of the whole machine cooling system, the casing will be hot during normal operation, please do not cover the casing when the device is working.  The pictures in this manual are schematic drawings. For details, refer to the actual objects. 3.2 Installation methods and procedures The device can be mounted on rails or walls.
  • Page 18 Figure 6 Clamping rail installation diagram  Clamping rail removal Step 1. As shown on the left of the following figure, insert the screwdriver head into the hole at the lower part of the spring lock piece, lift the screw handle upward, and open the spring lock piece of the DIN clamping rail base.

  • Page 19: Wall-Mounted

    3.2.2 Wall-mounted Description: If wall-mounted installation is required, the user needs to order a wall-mounted plate (optional).  Wall-mounted Step 1. Secure the wall-mounted plate to the rear panel of the device using screws according to the screw holes on the rear panel of the device. Step 2.

  • Page 20: Antenna Installation And Sim Card Installation

    arrow 2 pointing to the following figure, until the screws into the Ф6.5 part of the device wall-mounted plate hole, and then the wall-mounted hole through the loosened four screws, the device can be detached from the wall or cabinet wall. Step 2.
  • Page 21 Step 1. Obtain the SIM card for installation. Step 2. Remove the screws from the top panel card cover with a screwdriver to expose the SIM card slot. Step 3. Insert the metal IC part of the SIM card upward into the SIM card slot. Step 4.

  • Page 22: Wire

    4 Wire 4.1 10/100/1000Base-T(X) Ethernet interface The 10/100/1000Base-T(X) Ethernet interface adopts standard RJ45 connector with adaptive function, which automatically configured 10M/100M/1000M state full-duplex/half-duplex operation mode, and supports MDI/MDI-X self-identification function of the cable, i.e. it can be connected with terminal device and network device using either direct network cable or crossover network cable.

  • Page 23: Rs-232/Rs-485/Rs-422 Interface

    Straight line line Straight line line Figure 11 10/100/1000Base-T(X) RJ45 connector direct and cross cable interconnection Description: RJ45 connectors are wired as standard 568B (1-orange white, 2-orange, 3-green white, 4-blue, 5-blue white, 6-green, 7-brown white, 8-brown). 4.2 RS-232/RS-485/RS-422 interface RS-232/RS-422/RS-485 interface pins are defined as shown in the following figure. Figure 12 Interface pin definition Table 6 serial interface pin definition RS-232...

  • Page 24: Usb Connector

    Description: Pins 1-4 are way 1, and pins 5-8 are way 2. 4.3 USB connector The USB interface is located on the front panel of the device and contains two USB3.0 interfaces, both of which use standard A female ports. USB interface pins are defined as shown in the figure below.

  • Page 25: Di/Do Interface

    Figure 14 CAN interface diagram Table 8 CAN pin definition CAN1 Definition CAN2 Definition CAN1_H CAN2_H CAN1_L CAN2_L CAN1_GND CAN2_GND 4.5 DI/DO interface The following figure shows the pin definition of 4-way DI/DO interfaces (2-way DI/DO interfaces). (available only when selecting NewPre2100-P521-M1-D0-W3) Figure 15 AI/DI/DO wiring terminal interface diagram Table 9 DI/DO pin definitions DI/DO pin...

  • Page 26: Console Interface

    4.6 Console interface  RJ45 Management interface Connect the 9-pin serial interface of the PC to the Console interface of the device using a DB9-RJ45 network cable. Run the HyperTerminal software of WINDOWS system to call the console software of the device to realize the configuration, maintenance, and management functions of the device.

  • Page 27: Grounding

    TXD (Send data) RXD (Receive data) GND (Grounding) GND (Grounding) 4.7 Grounding The device is properly grounded to protect the device from lightning and interference. Therefore, you must properly connect the grounding screw. Ground the device before powering on, and disconnect the grounding screw after powering off the device.
  • Page 28 Table 11 5-core 5.08mm spacing plug out wiring terminals definition Termin Signal name DC wire definition AC wire definition number PWR1：+ PWR1：L PWR1：- PWR1：N PGND protected ground PGND protected ground PWR2：- PWR2：N PWR2：+ PWR2：L  Wire and installation Step 1. Properly ground the device according to the grounding procedure. Step 2.
  • Page 29 Note: Before connecting to the power supply, please confirm that the power supply matches the power supply requirements marked on the device to avoid damage to the device. Warning:  Do not touch any exposed wires, terminals and dangerous voltage marks marked on the product to avoid injury to human body.

  • Page 30: Reset

    5 Reset The Reset button is located on the front panel of the device and has the function of rebooting and restoring the default configuration. Press the reset button for 0.5~3 seconds and then release it to complete the device restart. Keep pressing the reset button for more than 3 seconds and release it to restore the default configuration and restart.

  • Page 31: Led Indicator State

    6 LED Indicator State Table 13 Description of indicators on the front panel State Description The input power supply 1 is connected and running properly Power indicator 1 (green) The input power supply 1 is disconnected or runs abnormally The input power supply 2 is connected and running properly Power indicator 2 (green) The input power supply 2 is disconnected or runs...
  • Page 32 7 Basic Performance and Specifications Power supply Power supply Input rated voltage range Input maximum voltage range identification 24VDC 18-72VDC Access terminal 5-core 5.08mm spacing plug out wiring terminals Nominal power Nominal power <25W Mechanical structure Casing All-metal unibody, fanless Degree of IP40 protection...
