Ancona PRH-2716 Instructions

www.anconahome.com
u v
*Pyramid hoods only use parts 1 and 3; please discard parts 2 and 4.
*Rectangle and Canopy hoods use parts 1, 2, 3 and 4.
If range hood is already installed, please remove upper chimney and screws.
Keep parts for posterior steps.
1
If installing Rectangle or Canopy hood, lock parts
with 2 pieces screws W . See Fig. #1.
Please skip this step if installing Pyramid hood.
2
Lock the bracket u to T-box
3
y
Connect tube to T-box
4
Screw the bracket u into the wall, with screws
5 Screw upper chimney bracket to wall. See Fig. #5. Skip this step if bracket
is already installed.
6
Screw the chimney to chimney bracket, with parts previously set aside. See
Fig. #6.
7
Lock the T-box to chimney, with 2 screws
Rectangle or Canopy hood, please see Fig. #7-1, if installing Pyramid hood,
see Fig. #7-2.
8
Attach the 2 round carbon lters (A or B, depending on model) onto the
range hood. See Fig. #8.
Fig. #6
INSTRUCTIONS FOR INSTALLING RECIRCULATION KIT
Pyramid hoods
w x
T-Box*
and
v
w , with 2 pieces screws W
w
. See Fig. #3.
V and plugs
on each side. If installing
W
COMPATIBLE WITH:
Rectangle hoods
Included parts
y
Tube Carbon lter
(1 piece) (2 pieces A +
Installation
to part ,
x w
. See Fig. #2.
X . See Fig. #4.
Fig. #7-1
Canopy hoods
U V
A B
Wall screws
(2 + 1 pieces)
2 pieces B)
Fig. #2
Fig. #4
Fig. #5
Fig. #7-2
MAPRH2716-01
W X
Screws Wall plugs
(8 + 1 pieces canopy (2 pieces)
and rectangle /
6 + 1 pieces pyramid)
Fig. #1
Fig. #3
Fig. #8
