- Page 1 USER MANUAL MODEL NUMBER: GI-30N-AM GI-30NK-AM GI-30NV-AM AND RELATED UNITS 30 Gallon Air Operated Portable Gel Unit with Agitator English (Original Instructions)
-
Page 2: Protect The Environment
• Do not exceed an incoming air pressure of 100 psi (7 bar). • Do not exceed a fluid temperature of 100˚F (37˚C). • Always flush the unit with fresh water for 5 minutes when switching from an alkaline to an acid or an acid to an alkaline. • Only use clean and dry air. Air must be filtered and free of moisture or pump life will be diminished. If needed, install a water separator (WS-20CFM) before the unit. • Do not use an air lubricator before the unit. • Never use unit with hydrocarbons or flammable products. PROTECT THE ENVIRONMENT Please dispose of packaging materials, old machine components, and hazardous fluids in an environmentally safe way according to local waste disposal regulations. Always remember to recycle. *Specifications and parts are subject to change without notice. Model No.: GI-30N-AM, GI-30NK-AM, GI-30NV-AM AND RELATED UNITS Page 2 of 8 | 02252015... -
Page 3: Specifications
SPECIFICATIONS Power type Compressed air Chemical pickup type Draws from pre-mixed solution Number of products unit can One product draw from Suction line length/diameter 3/8 in. (9.5 mm) inside diameter Capacity 30 gallons (132.15 liters) Discharge hose diameter/length 30 ft. (9 m) hose, with 1/2 in. (12.7 mm) inside diameter Discharge wand/tip type 24 in. (60.9 cm) stainless steel wand with fan tip and ball valve (Fan tips included: ST2520SS, ST1510, ST2508, and ST4008SS) Output distance 6-10 ft. (1.8-3 m) (Varies based on viscosity of product) Output volume 0.5-1 gal/min (1.89-3.79 l/min) (Varies based on viscosity of product and fan tip size) Flow rate* 2 gal/min (7.6 l/min) (Varies based on fan tip used) Pump seals Santoprene, Viton, or Kalrez Wheel type Two 10 inch non-marking wheels, two 5 inch casters with lock *Dilution rates and flow rates given are based on chemical with viscosity of water and factory air pressure settings. Model No.: GI-30N-AM, GI-30NK-AM, GI-30NV-AM AND RELATED UNITS Page 3 of 8 | 02252015... -
Page 4: After Use Instructions
(3.4 bar), adjust the pressure by turning the knob on 3. Close the discharge valve (HV60) after all pressure has the top of the air regulator (R25). been relieved from the system. Maintenance Instructions: Note: Disconnect coupler (FACI14) from air lines on the back of the unit before opening the back plate and servicing the unit. To keep your portable unit operating properly, periodically perform the following maintenance procedures: • Check the air pump (P56/P56K/P56V) for wear and leaks. • Inspect hoses for leaks or excessive wear. Make sure all hose clamps are in good condition and properly secured. • Replace filter (AFR25) in regulator (R25) as needed. • Check the suction tube and screen for debris and clean as needed. • Drain compressor tank on a regular basis to ensure proper operation of pump. Model No.: GI-30N-AM, GI-30NK-AM, GI-30NV-AM AND RELATED UNITS Page 4 of 8 | 02252015... - Page 5 DP-A PVCV34FM CST5SS-L CST5SS DISCHARGE WAND AIR MOTOR AND AGITATOR ITEM NUMBER: SSGWA12 ST2520SS HHSB1214 SC1212 GEL-MTR-IR PL-GEL-MTR S1420125 GEL-PROP-2 ST4008SS ST2508 ST1510 SSN1224 HV60 HBSS1212 Model No.: GI-30N-AM, GI-30NK-AM, GI-30NV-AM AND RELATED UNITS Page 5 of 8 | 02252015...
- Page 6 Muffler EC14-2 SSC38 (Included with GEL-MTR-IR) PLATE ASSEMBLY Outside View HBSS1438 AP25 FACI14 NV14Y HBSS1438 SSC38 HBSS1438 BVB14 SSA14 F38SS BEL14M14M HBSS1438 FACI14 SSA14 AP25 AP25 FWP12 BEL14F14M HBSS1212 SSA14 BPS-58SO Model No.: GI-30N-AM, GI-30NK-AM, GI-30NV-AM AND RELATED UNITS Page 6 of 8 | 02252015...
-
Page 7: Optional Components
ITEM NUMBER: H12-30 BPS-SSR BPS-58SO H12B-H (Available per .) HBSS1212 SSC12 BPS-SSR BPS-58SO ANTI-KINK SPRING WITH RETAINING PIN ITEM NUMBER: AKSS12 HHPB3414 AKSS12-P SSC38 AKSS-HPC HBSSEL1438 PVCV34FM OPTIONAL COMPONENTS WATER SEPARATOR 30 ft (9 m) AIR HOSE ASSEMBLY ITEM NUMBER: WS-20CFM ITEM NUMBER: AH30 Model No.: GI-30N-AM, GI-30NK-AM, GI-30NV-AM AND RELATED UNITS Page 7 of 8 | 02252015... - Page 8 FWP12 7/8 ID X 1.5 OD X 0.05 THK SSFW ST2520SS VEEJET NOZZLE, S.S. 2520 FWP14 C-816 1/2in SS WASHER ST4008SS VEEJET NOZZLE, S.S. 4008 GEL-MTR-IR GEL MOTOR-AIR OPERATED-LUBE FREE-INCLUDES INLET TANK-30N ROTO MOLDED 30 GALLON UNIT W/ HANDLE FITTINGS TW916 1/2 INT TOOTH L/W 410SS GEL-PROP-2 GEL IT PROP AND SHAFT NONMARKING WHEEL FOR PORTABLE UNITS H12B-H 1/2 INCH BLUE HOSE - Available per ft. WS-20CFM TSUNAMI WATER SEPARATOR 20 CFM H14B-H 1/4 INCH BLUE HOSE - Available per ft. H38B-H 3/8 INCH BLUE HOSE - Available per ft. Model No.: GI-30N-AM, GI-30NK-AM, GI-30NV-AM AND RELATED UNITS Page 8 of 8 | 02252015...
