- Page 1 Install / Use & Care MANUAL Professional Undercounter Refrigerator / Beverage Center FRUI324DRADA FRUI324DLADA...
-
Page 2: Table Of Contents
CONTENTS Important Safety Instructions Contents: Warnings and safety instructions appearing in this Important Safety Instructions ..........2 guide are not meant to cover all possible conditions and Unpacking Your Appliance ..........3 situations that may occur. Common sense, caution, and Installing Your Appliance ............4 care must be exercised when installing, maintaining, or Cutout &... -
Page 3: Unpacking Your Appliance
If there is damage, the packaging will be needed as proof of damage in transit. Afterwards please dispose of all items responsibly. VIKING RANGE, LLC GREENWOOD, MS 38930 WARNING XXXXXXXXXXXX... -
Page 4: Installing Your Appliance
Viking Range, LLC does not recom- Raise or lower the legs to the required dimension by turning mend the use of a custom made grille as air fl ow may be the legs. -
Page 5: Electrical Shock Hazard
INSTALLING YOUR APPLIANCE WARNING Electrical Shock Hazard Do not remove • Do not use an extension cord with this appliance. ground prong They can be hazardous and can degrade product performance. • This appliance should not, under any circumstanc- es, be installed to an un-grounded electrical supply. •... -
Page 6: Cutout & Dimensions
CUTOUT AND PRODUCT DIMENSIONS ROUGH-IN OPENING DIMENSIONS CABINET DIMENSIONS "A" "B" "C" "D" "E" "F" "G" "H" "J" 24" 31 1/4” to 32 1/4" 24" 23 7/8" 31” to 32" 22 7/8" 46 1/2" (61 cm) (79.4 cm to 81.9 cm) (61 cm) (60.7 cm) (78.7 cm to 81.3 cm) - Page 7 CUTOUT AND PRODUCT DIMENSIONS CUTOUT AND PRODUCT DIMENSIONS PRODUCT DATA ELECTRICAL PRODUCT REQUIREMENTS # WEIGHT 140 lbs 115V/60Hz/15A (63.6 kg) "J" "H" "G" "D" "F" "E" " " (8.9 cm) Figure 9 (54.6 cm) Minimum Solid Door Shown Minimum rough-in opening required is to be larger than the adjusted height of the cabinet.
-
Page 8: Installing The Anti-Tip Device
INSTALLING THE ANTI-TIP DEVICE Anti-Tip WARNING Bracket Leveling Leg • ALL APPLIANCES CAN TIP RESULTING IN INJURY. • INSTALL THE ANTI-TIP Bottom View of ⁄ " BRACKET PACKED WITH Appliance (54.6 cm) THE APPLIANCE. • FOLLOW THE INSTRUC- TIONS BELOW Front of cabinet Anti-Tip Device Figure 10... - Page 9 INSTALLING THE ANTI-TIP DEVICE NOTE When the floor mounted anti-tip bracket is used the mini- mum adjusted height of the cabinet is increased by ⁄ " (9 mm). "V" notches Rear Leveling leg in bracket Figure 11a Screw ⁄ " (54.6 cm) Figure 11 "V"...
-
Page 10: Integrated Panel Dimensions
INTEGRATED PANEL DIMENSIONS INTEGRATED PANEL DIMENSIONS NOTE • Panel thickness may be 5/8" or 3/4" • Center the unit in the 24" opening • If the hinge side of the product is pressed against the adjacent cabinet, use a 5/8" thick panel •... -
Page 11: Integrated Panel Installation
INTEGRATED PANEL INSTALLATION Step 2: Remove the Door Gasket Cut and prepare panels according to the information provided in the Integrated Panel Dimensions section. With the door laying on a flat surface and starting at a corner of the door, remove the magnetic door gasket from the interior side of the door. -
Page 12: Step 4: Install The Door
INTEGRATED PANEL INSTALLATION Step 4: Install the Door If reversing the door swing, reinstall hinges per Door Reversal Instructions. Carefully slide lower hinge bushing over bottom hinge pin. Install the new upper hinge bushing into adaptor plate. Figure 17 Align hinge bushing with top hinge and reinstall upper hinge pin using 1/8”... -
Page 13: Using Your Electronic Control
Time to reach set point varies based upon ambient temperature, temperature of product loaded, door openings, etc. Viking recommends allowing the unit to reach set points before loading. -
Page 14: Interior Adjustments
INTERIOR ADJUSTMENTS Tall bottle CAUTION storage area Shelf load limit is 35 lbs. Overloading the shelf could result in deflection and risk of injury. Shelf support slot Installed shelf tang Rear tang (hook) on shelf Door storage racks Figure 20 To remove the crisper : Pull out until it stops. -
Page 15: Care And Cleaning And Energy Saving Tips
CARE AND CLEANING AND ENERGY SAVING TIPS The following suggestions will minimize the Front Grille cost of operating your refrigeration appliance. Be sure that nothing obstructs the required air fl ow open- ings in front of the cabinet. At least once or twice a year, brush or vacuum lint and dirt from the front grille area (see 1. -
Page 16: Service Information
Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at (888) 845-4641 or write to: VIKING RANGE, LLC... -
Page 17: Before You Call For Service
TROUBLESHOOTING Before You Call for Service CAUTION If the appliance appears to be malfunctioning, read through this manual fi rst. If the problem persists, check the troubleshooting guide below. Locate the problem in the In the unlikely event you lose cooling in your unit, do not guide and refer to the cause and its remedy before calling unplug the product from the electric supply, but do call for service. -
Page 18: Warranty
Any sealed refrigeration system component, as listed below, is warranted to be free from defective materials or workmanship in normal household use during the third through the sixth year from the date of original retail purchase. Viking Range, LLC, warranter, agrees to repair or replace, at its option, any part which fails or is found to be defective during the warranty period. - Page 20 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-(845-4641) or visit our web site at vikingrange.com 30735 (111124)
