WCH CH32L103 Reference Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Overview
CH32L103 is an industrial-grade general-purpose microcontroller based on 32-bit RISC-V instruction set and
architecture. Adopting QingKe V4C core, it supports hardware interrupt stack and improves interrupt response
efficiency. This series of products are loaded with rich peripheral interfaces and functional modules. Its internal
organizational structure meets the low-cost and low-power embedded application scenarios.
This manual is aimed at user's application development and provides detailed information about the use of
CH32L103 products.
RISC-V core version comparison overview
Features
Instruction
Core
set
versions
QingKeV4B
IMAC
QingKeV4C
IMAC
QingKeV4F
IMAFC
Hardware
Interrupt
stack
nesting
interrupt
levels
levels
channels
2
2
2
2
3
8
CH32L103 Reference Manual
Fast
Integer
division
Vector table model
cycles
4
9
Address or command
4
5
Address or command
4
5
Address or command
V1.9
https://wch-ic.com
Extended
Memory
instruction
protection
Supported
None
Supported
Standard
Supported
Standard
