wilson & bradley CINETTO PIANO PS40.2 Assembly Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
CINETTO
PIANO
(PS40.2)
Assembly instruc� ons

Advertisement

loading
Need help?

Need help?

Do you have a question about the CINETTO PIANO PS40.2 and is the answer not in the manual?

Questions and answers

Related Manuals for wilson & bradley CINETTO PIANO PS40.2

Summary of Contents for wilson & bradley CINETTO PIANO PS40.2

  • Page 1 CINETTO PIANO (PS40.2) Assembly instruc� ons...
  • Page 2 Contents Intro ........................................1 Cabinet Requirements ................................. 3 Calculation of door height ................................4 Doors width calculation ................................5 Working requests for doors ............................... 7 Wardrobe configuration ................................18 Start Assembly Instructions Assembly of top track and mechanism ..........................19 Assembly of bottom track and mechanism ........................

  • Page 3: Cabinet Requirements

    Cabinet requirements Top height clearance = Min 60 mm Bo� om height clearance = Min 60 mm Bo� om depth clearance = Min 72 mm Free space required under the wardrobe in corrispondence of the lower slide with closed door. FREE SPACE REQUIRED Standard leveler...
  • Page 4 Calcula� on of door height ABBREVIATIONS: = gap between the bo� om and the fl oor H1 = door height = thickness of bo� om and top panel = distance between bo� om and top panel H1 = X + 2T + 120 - G LOWER SLIDE G (35 / 25 / 17) H 3 5...
  • Page 5 Doors width calcula� on ABBREVIATIONS: LB = rail length WA = door width = overlapping For 2 Door Overlay Carcase LB = 2WA + X – 2S To calculate from Door width Overlay Carcase WA = (LB – X + 2S) / 2 To calculate from Inner carcase width LB = 1784 MIN X = 4 MIN...
  • Page 6 Doors width calcula� on ABBREVIATIONS: LB = rail length WA = door width = overlapping For 3 Door Overlay Carcase LB = 3WA + 2X – 2S To calculate from Door width Overlay Carcase WA = (LB – 2X + 2S) / 3 To calculate from Inner carcase width LB = 3908 MIN X = 4 MIN...
  • Page 7 How to move the a� achment of the upper slide 3 mm Left - red Left - red 3 mm Right - blue Right - blue...
  • Page 8 Working requests for the doors Drilling for 2 Door Systems Door widths of 888 ÷ 1000 mm The star� ng reference for making the milling / or drilling of the doors, is always the center of the door, whatever its width is.
  • Page 9 Door widths of 1001 ÷ 1800 mm The star� ng reference for making the milling / or drilling of the doors, is always the center of the door, whatever its width is. Le� Hand Doors WA = 1001 ÷ 1800 86,5...
  • Page 10 Door widths of 888 ÷ 1000 mm The star� ng reference for making the milling / or drilling of the doors, is always the center of the door, whatever its width is. Right Hand Doors WA = 888 ÷ 1000 86,5...
  • Page 11 Door widths of 1001 ÷ 1800 mm The star� ng reference for making the milling / or drilling of the doors, is always the center of the door, whatever its width is. Right Hand Doors WA = 1001 ÷ 1800 86,5...
  • Page 12 Working requests for the doors Drilling for 3 Door Systems Door widths of 1300 ÷ 1410 mm The star� ng reference for making the milling / or drilling of the doors, is always the center of the door, whatever its width is.
  • Page 13 Door widths of 1411 ÷ 1800 mm The star� ng reference for making the milling / or drilling of the doors, is always the center of the door, whatever its width is. Le� Hand Doors WA = 1411 ÷ 1800 127,5...
  • Page 14 The star� ng reference for making the milling / or drilling of the doors, is always the center of the door, whatever its width is. Middle Right Hand MIN - MAX 26,5 98,5...
  • Page 15 The star� ng reference for making the milling / or drilling of the doors, is always the center of the door, whatever its width is. Middle Le� Hand MIN - MAX 26,5 98,5...
  • Page 16 Door widths of 1300 ÷ 1410 mm The star� ng reference for making the milling / or drilling of the doors, is always the center of the door, whatever its width is. Right Hand Doors WA = 1300 ÷ 1410 127,5...
  • Page 17 Door widths of 1411 ÷ 1800 mm The star� ng reference for making the milling / or drilling of the doors, is always the center of the door, whatever its width is. Right Hand Doors WA = 1411 ÷ 1800 127,5...
  • Page 18 Wardrobe confi gura� on BLUE BLUE BLUE BLUE...
  • Page 19 Play video Assembly instruc� ons Click here or scan the QR code to play the installation video.
  • Page 20 Left - red Right - blue Left - red Right - blue Left - red Right - blue...
  • Page 21 Left - red Right - blue Left - red Right - blue...
  • Page 22 Posi� oning and fi xing of the upper locks ABBREVIATIONS: = depth WA = door width = carcase overlay Left - red d = WA / 2 - S - 400 Right - blue d = WA / 2 - S - 400...
  • Page 23 Left - red Right - blue d = WA / 2 – S – 604 Left - red X = 4 MIN X = 4 MIN d1 = WA + WA / 2 + X - S - 214 Right - blue X = 4 MIN X = 4 MIN d1 = WA + WA / 2 + X - S - 214...
  • Page 24 Posi� oning and fi xing of the so� -closing device in the opening Right - blue Left - red Left - red Right - blue Left - red Right - blue Left - red Right - blue...
  • Page 25 Left - red Right - blue Left - red Left - red Right - blue Left - red Right - blue Right - blue Left - red Right - blue Left - red Left - red Right - blue Right - blue Left - red Right - blue...
  • Page 26 Play video Click here or scan the QR code to play the installation video.
  • Page 27 Posi� oning and fi xing of the lower locks...
  • Page 28 Left d = WA / 2 – S – 400 Right d = WA / 2 - S - 400 Left Right d = WA / 2 - S - 604 Left X = 4 MIN X = 4 MIN d1 = WA + WA / 2 + X - S - 214...
  • Page 29 Right X = 4 MIN X = 4 MIN d1 = WA + WA / 2 + X - S - 214 ABBREVIATIONS: = depth WA = door width = carcase overlay 8 mm...
  • Page 30 N.B. The lower slide must be closed during the door hooking.
  • Page 31 3 mm 35 mm 25 mm 17 mm Distance between the door and the fl oor (17 mm, 25 mm, 35 mm).
  • Page 32 Play video Rail Fixing Click here or scan the QR code to play the installation video. Fixing from outside of the carcase: Minimum 80mm carcase clearance to ceiling Top Screw Posi� on 73mm and 133mm in from carcase edge on underside of carcase Bo�...
  • Page 33 Fixing from inside of the carcase: Minimum 80mm carcase clearance to ceiling Top Screw Posi� on 45.5mm and 180mm in from carcase edge on underside of carcase Bo� om Screw Posi� on 30mm in from carcase edge on underside of carcase 45,5 16÷43* (*including handle thickness) Standard leveler...
  • Page 34 Play video Click here or scan the QR code to play the installation video.
  • Page 35 Play video Click here or scan the QR code to play the installation video. Open the upper slide before hanging the door. 3 mm 4 mm RAIL DOOR DOOR -4 +6 mm Close the door. Adjust the level of the door, aligning it with the upper rail.
  • Page 36 Play video Click here or scan the QR code to play the installation video. 8 mm Check the ver� cal alignment and the central distance between the doors, eventually move the upper Le� or Right locks. 8 mm...
  • Page 37 8 mm Hook the lower slide and fi x the screws. See next page Door adjusted too high. Door adjusted too low.
  • Page 38 Scan to view Correct posi� oning of the lower slide Troubleshooting: FAQ Door adjusted too high. Door adjusted too low. SOLUTION Open the door. Loose the lower stop with an 8 mm fork key. Close the door again. Make sure that the lower slider is completely inside the lower stopper.
  • Page 39 Make the eventual ver� cal adjustment. Once the door is adjusted you can shake the door in the lower part of the door as in the pictures. Only now fi x the lower stop again. The door must be shut during this step.
  • Page 40 Do you need to re-adjust the door? Do not forget to unlock the lower and upper stops before any further doors adjustment. (1) Slightly shake (2) the door at the bo� om with both hands in this way the bo� om stop will align automa� cally to the top stop.
  • Page 41 How to remove the doors. 8 mm 4 mm RAIL DOOR...
  • Page 42 3 mm...
