SINK SPECIFICATIONS
Matte Stone Vessel Sink
TM
Model VG04003
MODEL VG04003
FEATURES
PACKING LIST
For warranty purposes contact our toll free number:
TOLL FREE: (866) 591 - 7792
E-Mail: techmail@vigoindustries.com
www.vigoindustries.com
DIMENSIONS
MODEL #
SINK
SINK
LENGTH
WIDTH
VG04003
17 3/4"
14 3/8"
SINK
HOLE
HEIGHT
DIAMETER
5 "
1 3/4"
17 3/4"
