CHIMINEA USER GUIDE
1123082
WARNING
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHIMINEA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for tiki CHIMINEA

  • Page 1 CHIMINEA USER GUIDE 1123082 WARNING INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference.
  • Page 2: Table Of Contents

    Light your Chiminea without the Hopper . . . . . . 13 Light your Chiminea with the Hopper . . . . . . . . . 14 Extinguishing .
  • Page 3: Warnings

    Chiminea. asphyxiation. • DO NOT store or use LP cylinders within 30 ft. of the Chiminea while it is in operation. WARNING: Hot Surface Hazard • DO NOT use the Chiminea on or near DO NOT touch when in use. The...
  • Page 4 Always follow Contact your local fire department for details. local laws and ordinances when burning. • DO NOT alter or modify the Chiminea in any manner. • The Chiminea should be inspected and cleaned after every use.
  • Page 5: Pre-Assembly

    PRE-ASSEMBLY Remove all parts from the packaging, including the Part Description Quantity smaller components that are stored within the cone/ A Cone/Main Body main body (A) and the ash pan (O). B Legs Compare all parts with the Package Contents and C Trumpet Hardware Included lists.
  • Page 6 Note: Not shown to actual scale or size. T I K I Bra n d | Ch im i n e a Use r G ui d e ®...
  • Page 7: Assembly Instructions

    ASSEMBLY INSTRUCTIONS CAUTION Some parts may contain sharp edges. Wear protective gloves when assembling, moving, or handling the product. Note: DO NOT overtighten screws. ST E P 1 ST EP 2 Flip the cone (A) upside down on a flat surface. Set the cone (A) with assembled feet right side Assemble the legs (B) to bottom of cone (A).
  • Page 8 ST EP 3 ST E P 4 Assemble the lower (D) and middle (E) chimney Place the deflector (G) on the top chimney sections. Secure each section with 3 screws section (F). Align the holes and secure with 3 (W). Do not over tighten. screws (U).
  • Page 9 ST EP 6 ST E P 8 Place chute (K) on the bottom two posts of the Install the hopper (H) by sliding the chute hopper (H). Next, place the first heat shield (II) through the holes in the heat cover (I) and the on the hopper and fasten 3 nuts (X) to the three cone (A).
  • Page 10 ST EP 9 ST E P 1 0 Place the grate (N) inside the center of the Install the ash pan (O) within the cone/main cone (A). The grate should sit flush if properly body (A). aligned. Place the pellet insert (M) on top of the grate (N), and align the hopper chute (K) through the opening of the pellet insert.
  • Page 11 ST EP 11 Note: The screen (L) should be hung on the Use 2 screws (W) to attach screen handle to hook of the lower chimney (D) when adding screen. wood or performing cleaning and maintenance Place the screen (K) on lower hook of the cone (A).
  • Page 12: Pellet Hopper Removal

    PELLET HOPPER REMOVAL The Chiminea can be used without the pellet hopper, which can be left in place or removed. Note: The Chiminea should be completely cooled down, approximately 12 hours, before removing the hopper. To remove the hopper: 1. Remove the 3 screws (U) that attach the hopper (H) to the heat cover (I).
  • Page 13: Light Your Chiminea Without The Hopper

    LIGHT YOUR CHIMINEA WITHOUT THE HOPPER If the hopper is left in place, ensure that the Chute door in the Chute door in the chute door is closed prior to and throughout open position closed position use. The pellet insert should also be removed.
  • Page 14: Light Your Chiminea With The Hopper

    LIGHT YOUR CHIMINEA WITH THE HOPPER CAUTION Keep clothing, hair, and face away from the flame when lighting the Chiminea. 1. Place the chute door in the closed position then, open the hopper lid. Note: The chute door should be closed prior to opening the hopper lid.
  • Page 15: Extinguishing

    Only in the case of an emergency should you use a garden hose and water: Note: If no garden hose is available, you can pour water over the Chiminea. Use caution as this generates a significant amount of steam and smoke. You can also use sand or a dry chemical extinguisher that is specified for wood fire applications.
  • Page 16: Care & Maintenance

    CARE & MAINTENANCE CAUTION Allow the Chiminea to cool for at least 12 hours before performing any cleaning or maintenance. Some parts may contain sharp edges. Wear protective gloves when moving or handling product With proper care, you can improve the efficiency and performance of your Chiminea and prolong its life.
  • Page 17: Limited Warranty

    LIMITED WARRANTY Visit tikibrand.com/customer-service/our-guarantee or contact us at 1-888-473-1088 for more information. For information on patents, go to tikibrand.com/patents. KEEP THE FIRE GOING FOR MORE WOOD PACKS AND OTHER PRODUCTS TO HELP YOU ENJOY YOUR FIRE, VISIT TIKIBRAND.COM...
  • Page 18: Frequently Asked Questions

    When the flames are fully visible through the fuel and hinders some tending. front opening of the Chiminea and are no longer Can I use firewood in the Chiminea? traveling up into the chimney, another wood...
  • Page 19 If soot or ash has accumulated on the outside 15 ft. to any walls, structures or buildings, and of the Chiminea, wipe down with a damp cloth should not be placed on any combustible once the Chiminea is completely cool. Rinse...
  • Page 20 T IK IB R A N D .C O M 4002599 REV4 ©2024 Lamplight Farms Incorporated T I K I Bra nd | Ch i m i ne a Use r Guid e ®...
