- Page 1 U S E R G U I D E LIGHT HIGH LIGHT LIGHTIN G INSTRU CTIONS PROVID ED ON TANK ACCESS PANEL 1123044 & 112214367 WARNING INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference.
-
Page 2: Warnings
Using it in an enclosed space can kill you. Never use this appliance in an enclosed space such as a camper, tent, car or home. TIKI Brand | Propane Fire Pit User Guide ®... -
Page 3: Table Of Contents
TABLE OF CONTENTS Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . .2 Parts List . - Page 4 LP your warranty. gas supplier prior to use. g. The LP gas tank should not be dropped or handled roughly. TIKI Brand | Propane Fire Pit User Guide ®...
- Page 5 WARNINGS h. Tanks must be stored outdoors, out of the · You must follow all instructions in the “Checking reach of children and must not be stored in a for Leaks” section before operating. To prevent a building, garage or any other enclosed area. fire or explosion when testing for a leak: Your LP gas tank must never be stored where a.
- Page 6 · Do NOT use this propane fire pit for cooking. in use. Allow appliance to cool before moving or · Do NOT wear flammable or loose clothing when storing. operating this propane fire pit. TIKI Brand | Propane Fire Pit User Guide ®...
- Page 7 Lamplight Farms and TIKI® Brand. toward the access door for easy access. · Use only Lamplight Farms and TIKI® Brand- · Do NOT store any combustible materials in the authorized parts. The use of any part that is not base enclosure.
-
Page 8: Parts List
(vented panels) M8 Flange Hex Nut (propane train) M6 Internal Stainless Hex Screw - 20mm long (top ring) Manual Lighting Wand Extra Hardware M6 Internal Stainless Hex Screw (combustion assembly brackets) TIKI Brand | Propane Fire Pit User Guide ®... - Page 9 PARTS LIST Note: Items not shown to actual scale or size 6005444 6005819 6005820 6005674 6005456 6005677 6005457 6006043 6006042 6005822 6005702 6005753 6005502 6005475 6005705 6005821...
-
Page 10: Assembly Instructions
Turn base of the unit over – tank shuttle opening Attach Wheel Kit with (2) hex screws (Item C). and vertical supports pointing downward. Fully tighten with provided wrench (Item B). TIKI Brand | Propane Fire Pit User Guide ®... - Page 11 STEP 3 STEP 4 Engage Adjustable Legs with threaded nuts as Turn base of the unit upright with wheels and shown. adjustable feet on the ground. Attach basin cover support using 4 screws (Item D). Fully Note: Legs should be installed in the holes tighten using provided hex driver (Item A).
- Page 12 Set Tank Access panel in place using the upper and lower alignment pins and check for good alignment between the panels. Ensure panels are aligned before fully tightening screws using provided hex driver (A). TIKI Brand | Propane Fire Pit User Guide ®...
- Page 13 ASSEMBLY INSTRUCTIONS STEP 10 STEP 11 Flip over the combustion assembly and attach Flipping the combustion assembly back over, the 2 internal baffles where indicated. Fully set it on top of the three vertical supports, tighten using screws (Item L). aligning the studs on each leg with the holes in the combustion assembly.Note: Orient control panel towards the front of the unit.
- Page 14 Tabletop User Guide for further assembly instructions. STEP 16 Install (7) additional screws (Item H) into the top ring using provided hex driver (Item A). Fully tighten. Alignment Marks TIKI Brand | Propane Fire Pit User Guide ®...
- Page 15 ASSEMBLY INSTRUCTIONS STEP 17 Install Battery for Igniter : Loosen and remove battery bay cap . Note: Remove plastic wrapper before installing battery. Install AA battery (included) into battery bay – positive pole is outward, towards cap. Reinstall battery cap. STEP 18 STEP 19 Install Manual lighting hook(K): Install lighting...
-
Page 16: Installing Lp Tank
Magnets will release panel and it will tilt outward. Lift alignment pins on the bottom of the door free from the base of the unit. Set panel aside. Make sure control knob is in the ‘off’ position. TIKI Brand | Propane Fire Pit User Guide ®... - Page 17 INSTALLING LP TANK STEP 3 STEP 4 Place LP gas tank upright into opening in tank Connecting LP Gas Tank : shuttle. Orient tank so tank valve is facing Make sure control knob is in the ‘OFF’ position. towards the front of the unit and towards the Before connection, be sure there is no debris in gas line connection.
- Page 18 LP gas tank by turning knob counterclockwise until it is free. Place the protective cap cover on the LP tank and store the tank outdoors in a well-ventilated area out of direct sunlight. TIKI Brand | Propane Fire Pit User Guide ®...
-
Page 19: Checking For Leaks
CHECKING FOR LEAKS WARNING Before using this propane fire pit, make sure you have read, understand and are following all information provided in the Warnings section of this manual. Failure to follow those instructions can cause death, serious injury or property damage. WARNING The burner must be replaced prior to operating the unit if it is evident the burner is damaged. - Page 20 LP gas tank valve to ‘CLOSED’ and disconnect LP gas tank, per ‘Disconnecting LP Gas Tank” (see page 18) Contact 1-888-473-1088 for assistance. If no bubbles appear after one minute, turn LP gas tank valve to ‘CLOSED,’ wipe away solution and continue. TIKI Brand | Propane Fire Pit User Guide ®...
-
Page 21: Burner Lighting
Thermocouple Tip. If spark is not arcing between the Electrode Tip and Thermocouple Tip or is arcing between the Electrode Tip and any other surface, call STEP 5 TIKI Customer Service at 1-888-473-1088. Connect LP gas tank per ‘Installing LP Gas Tank’ Thermocouple Tip section. - Page 22 CAUTION If ignition does not occur in 5 seconds, turn control knob to ‘OFF,’ wait a minimum of 5 minutes, fan appliance, and repeat lighting procedure. TIKI Brand | Propane Fire Pit User Guide ®...
-
Page 23: Extinguishing Your Fire
EXTINGUISHING YOUR FIRE DANGER Failure to follow all instructions may result in serious bodily injury or death, or in a fire or explosion causing damage to property. STEP 1 STEP 2 Turn LP gas tank valve to Turn control knob to the ‘CLOSED. -
Page 24: Basin Cover & Lava Rocks
When the Fire Pit is in use, the Basin Cover may be stored under the unit. Place cover onto wire rack provided as shown taking care to not strike the propane system. TIKI Brand | Propane Fire Pit User Guide... - Page 25 Do NOT dump lava rocks out of package. Carefully place lava rocks by hand so damage to burner or basin does not occur. Use only Lamplight Farms and TIKI® Brand-authorized basin media. The use of any media that is not factory-authorized can be dangerous and will void your warranty.
-
Page 26: Care & Maintenance
· After a period of storage and/or non-use, check for leaks, burner obstructions, and inspect for any abrasion, wear or cuts to the hose. · Check inside the tank compartment and underside of the valve area occasionally for any obstructions such as spiderwebs, animal nests, etc. TIKI Brand | Propane Fire Pit User Guide ®... - Page 27 CARE & MAINTENANCE Cleaning Surfaces: · Wipe surfaces clean with mild dishwashing detergent or baking soda mixed with water. · For stubborn stains, use a citrus-based cleaner and a nylon scrubbing brush. · Rinse clean with water. · Allow to air dry. ·...
-
Page 28: Troubleshooting
– Call 1-888-473-1088 for details POSSIBLE CAUSE SOLUTION Orifice or air inlets blocked Clean orifice and air inlets to ensure proper gas flow POSSIBLE CAUSE SOLUTION Burner ports blocked Clean burner ports TIKI Brand | Propane Fire Pit User Guide ®... - Page 29 TROUBLESHOOTING PROBLEM: BURNER WILL NOT LIGHT USING IGNITER OR MATCH cont. POSSIBLE CAUSE SOLUTION Air in supply system Open gas line and bleed air from the line (press control knob in) for not more than 1 minute or until you smell gas. Turn control knob to ‘off,’ wait at least 5 minutes for gas to dissipate.
- Page 30 Ice buildup on LP tank due to slow Turn off propane fire pit, turn off fuel tank valve, vaporization disconnect LP tank and replace. Reconnect propane fire pit, check appliance for leaks, and light normally TIKI Brand | Propane Fire Pit User Guide ®...
-
Page 31: Limited Warranty
LIMITED WARRANTY Visit TIKIBrand.com/customer-service/our-guarantee or contact us at 1-888-473-1088 for more information. For information on patents go to TIKIBrand.com/patents Specifications: · Certifications: ANS Z21.97 * CSA 2.41-2017 · Normal Hourly Input Rating: 40,000 BTU/hr. (11.7kW) · Fuel: Liquid Propane Gas ·... - Page 32 T IK IB R A ND .C OM 4002278 REV7 ©2024 Lamplight Farms Incorporated TIKI Brand | Propane Fire Pit User Guide ®...
