Accessories
①
Threaded collar
②
Thin gasket
③
Thick gasket
• The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by JVCKENWOOD Corporation
is under license. Other trademarks and trade names are those of their respective owners.
• Qualcomm aptX is a product of Qualcomm Technologies International, Ltd.
Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other countries, used with permission. aptX is a trademark
of Qualcomm Technologies International, Ltd., registered in the United States and other countries, used with permission.
Take the time to read through this instruction manual.
Familiarity with installation and operation procedures will help you obtain the best performance from your new product.
© 2023
KCA-M100BT
BLUETOOTH® CONTROLLER
INSTRUCTION MANUAL
FCC ID:2AYBO-KCA-M100BT
1
1
1
Advertisement
Table of Contents
Related Manuals for Kenwood KCA-M100BT
Summary of Contents for Kenwood KCA-M100BT
- Page 1 KCA-M100BT BLUETOOTH® CONTROLLER INSTRUCTION MANUAL FCC ID:2AYBO-KCA-M100BT Accessories ① Threaded collar ② Thin gasket ③ Thick gasket • The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by JVCKENWOOD Corporation is under license.
-
Page 2: Controller Functions
KCA-M100BT Contents & Controller Functions Contents Contents & Controller Functions....................2 Installation Instructions.......................3 Mounting Instructions.........................4 Pairing Instructions & Specs......................5 Controller Functions Power ON/OFF and Play/Pause Power ON/OFF (Press and Hold) Play/Pause (Short Press) Volume Up Press to Increase the Volume Volume Down... -
Page 3: Installation - Wiring Diagram
KCA-M100BT Installation Instructions Installation - Wiring Diagram Front (Gray), Rear (White), & Black Subwoofer (Black) Preouts (Left; White, Right; Red) -12V Ground Blue Amplifier Remote Turn On (+12V Output) +12V Switched (Accessory) Yellow +12V Battery (Constant Power) NOTE: After wiring, be sure to insulate and waterproof connections. - Page 4 KCA-M100BT Mounting Instructions Installation - Mounting The KCA-M100BT uses a single hole for installation. It features a threaded-collar mounting system that enables installations in flat surfaces up to 1.75 inches (4.5 cm) in thickness. Please refer to the diagram below:...
-
Page 5: Specifications
2. Press and hold the settings button for 3 seconds. The RGB lights will flash, letting you know that the Bluetooth from the KCA-M100BT is ready to pair with your device. 3. From your Bluetooth device, search for available connections and select the KCA- M100BT. -
Page 6: Important Notes
This equipment generates, uses and can radiate radio frequency energy and, if not installed Model Name: KCA-M100BT and used in accordance with the instructions, may cause Responsible Party: JVCKENWOOD USA CORPORATION harmful interference to radio communications. However,...
