- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. New Braunfels 03207245 Owner's Manual Shop genuine replacement parts for New Braunfels 03207245 Find Your New Braunfels Grill Parts - Select From 24 Models -------- Manual continues below --------...
- Page 2 THIS UNIT IS HEAVY. CARBON MONOXIDE HAZARD Burning charcoal inside can kill you. It gives off carbon DO NOT assemble monoxide, which has no odor. NEVER burn charcoal without a helper. inside homes, vehicles or tents. Hondo Deluxe 03207245 E / 42802128(02-12-03)
-
Page 3: Parts List
STOP! Call Our Help Line Missing a part? No need to go back to the store! The store where you made your purchase does not stock parts for this item. If you need parts, whether they are missing or damaged, call the Customer Service toll free Help Line. - Page 4 DO NOT ASSEMBLE WITHOUT A HELPER. • Cart should be assembled in position Attach Wire Shelf shown. • Connect leg sections together as Extenders shown. • Make sure short legs with axle holes are on the same side. • Affix wire shelf as shown in section •...
- Page 5 Firebox • Attach knockout cover to the firebox chamber using two 8-32 x 1/2 screws and 8-32 keps nuts. • With smoker turned onto its right side, lower the firebox over the opening on smoke chamber as shown. Align the holes in the smoke chamber to those on the firebox and insert six 1/4 - 20 x 3/4 hex...
- Page 6 Lids removed for clarity. • Insert wire and cast iron grates as shown. • Hang the grease can holder under the smoke chamber on right side. Enter through large hole first. • An empty soup can is recommended to hang from grease can holder. Grease Can Holder...
-
Page 7: Hardware List
ALWAYS WEAR PROTECTIVE CLOTHING TO PREVENT INJURY. Limited Warranty New Braunfels Smoker Co. warrants this grill/smoker for replacement or repair of parts and/or workmanship for a period of ninety (90) days . Paint is not warranted and will require touchup. - Page 8 With any type of live fire cooking, allow enough time to build a Before you begin . . . fire and get the grill/smoker up to temperature. Familairize yourself with the major components and controls of Build a fire using either charcoal briquettes, lump charcoal, or the unit.
- Page 9 Grilling Maintenance Position both fire grates in the smoke chamber. Build a fire on When finished cooking, and the unit has adequately cooled, top of the fire grates using either charcoal briquettes, lump clean out all remaining ashes. Ashes collect moisture, which charcoal, or wood chunks.
