- Page 1 — L&W AUTOLINE L&W Autoline Base Unit OPERATING INSTRUCTIONS https://manual-hub.com/...
- Page 2 https://manual-hub.com/...
- Page 3 However, should any errors be detected, ABB would gratefully appreciate being informed of them. In case of errors in this document, ABB shall not be liable for incidental or consequential damages in connection with or arising from such errors.
- Page 4 All adjustments, settings, calibration routines and service not described in this manual must be performed by ABB specialist-trained personnel. All covers must be in place during normal operation. The equipment has moving parts that are operated pneumatically and/or electrically.
-
Page 5: Table Of Contents
Table of contents 1 Introduction....................3 1.1 Measurement method................3 2 System description..................5 3 Installation....................7 3.1 Connections....................7 3.2 Connecting the AC power................7 3.3 Connecting the compressed air supply............. 7 3.3.1 Main valve....................7 3.3.2 Paper feed pressure................8 3.3.3 Measurement air.................. - Page 6 L&W Autoline Base Unit | OPERATING INSTRUCTIONS https://manual-hub.com/...
-
Page 7: Introduction
1 Introduction L&W Autoline is a complete system for fast and accurate paper quality measurements. It is mainly used in paper mills, but also at pulp mills, R&D centers, converting, and more. Several testing modules are available and L&W Autoline is configured to suit the paper grades produced. L&W Autoline is mainly designed to test cross-direction profiles, but testing machine- direction profiles and smaller sheets is also possible. - Page 8 A second sample strip can be queued during measurement. During a measurement of a strip, the next strip can be prepared. L&W Autoline Base Unit | OPERATING INSTRUCTIONS https://manual-hub.com/...
-
Page 9: System Description
2 System description Front view Sample holder Air filter Touch-screen on adjustable arm 10 Compressed air supply equipment Top hood, for ABB certfied service 11 Buttons to adjust transparent front cover speed Transparent front cover 12 Emergency stop Doors 13 Main ON/OFF switch... -
Page 10: Side View
Side view ABB Service, only to be used by certified ABB service technicians LAN – Data Exchange Air inlet Power supply L&W Autoline Base Unit | OPERATING INSTRUCTIONS https://manual-hub.com/... -
Page 11: Installation
Four connections are located at the left side of L&W Autoline Base Unit: • ABB Service. This port is connected to the internal network of L&W Autoline Base Unit. This port is only for ABB service personal during diagnostic and calibration services and must not be connected to an external device or network. -
Page 12: Paper Feed Pressure
The compressed air supply can be shut off from the main valve. When the valve is closed (OFF), the air system in L&W Autoline Base Unit is not pressurized. 3.3.2 Paper feed pressure The air that actuates the paper feed pressure roller is controlled by a separate regulator. -
Page 13: Operating The System
4 Operating the system 4.1 Using the main ON/OFF switch When the system is turned OFF, the whole system is shut down. To turn the system on or off, use the ON/OFF switch. 4.2 Using the emergency stop NOTE The emergency stop must only be used to prevent injury. The emergency stop shuts off the power supply to L&W Autoline Base Unit, together with the compressed air supply to some of the instruments. -
Page 14: Data Views
The upper right corner of the touch-screen includes the diagnostics symbol , see 4.3.3 Accessing an instrument. 4.3.2 Data views These views are available: Data view Description Trending Numeric Shows data trends in tabular format Trending Graphic Shows data trends as graphs Custom Trend Shows data trends as separate graphs as specified by the operator Summary Numeric... -
Page 15: Preparing One Or More Tests
3. Align the sample against the front edge towards you and fasten it in the clamp. Make sure that the strip is straight and securely fastened in the clamp, otherwise the paper can get stuck during the test. 4. Select on the touch-screen to create a measurement profile. -
Page 16: Example With Available Options
4. Repeat steps 1–3 for each other test you want to prepare. 4.5.1 Example with available options This illustration shows an example of the Testing field when one test is in progress, while three other tests have been prepared in the software: These are the available options: Use the Queue function See 4.5.2 Using the Queue function. -
Page 17: Data Export
5 Data export Measured data can be exported from L&W Autoline Base Unit. Measurement reports can be exported into the formats AL1, XML, CSV, PDF, and Excel. A measurement file can be exported the regular way and through shortcuts. 5.1 Exporting a profile from Autoline the regular way When a measurement is completed, its data is found in four views: Summary Numeric, Trending Numeric, CD Graphs, and Trending Graphic. -
Page 18: Maintenance
Carefully read the SAFETY INFORMATION in the beginning of this manual. 6.1 Maintenance intervals It is recommended to check the instrument regularly. The maintenance interval depends on environmental conditions and use. For specific recommendations, contact your local ABB support for Lorentzen & Wettre products. Recommended interval Action When neccessary Clean the transparent front cover with a damped microfiber cloth. -
Page 19: Cleaning The Clamp
6.3.2 Cleaning the clamp Some paper grades can result in deposits accumulating on the belt, which causes the samples to slip. If this occurs, use the air nozzle to clean the clamp. 6.4 Moving the system If it is necessary to move the L&W Autoline Base Unit, use the wheels. NOTE Use the wheels only for short distances on a smooth surface. -
Page 20: Troubleshooting
System is down Emergency stop is not reset Do a check of the emergency stop. Fuses are faulty Contact a certified ABB Lorenzon & Wettre service technician. Paper jam Paper is stuck in the system Remove or adjust the paper. -
Page 21: Technical Specification
8 Technical specification L&W Autoline Base Unit – Code 601 System Inclusive Case with accessories Transport fixation Rated voltage 110–230 V AC Frequency 50–60 Hz Rated power 500 W for L&W Autoline L 400 W for L&W Autoline S Power consumption 500 W maximum , 360 W average , 175 W... -
Page 22: Accessories
9 Accessories Case with accessories for L&W Autoline Base Unit: Adapter ½" to 10 mm Fuse for PF4 2 A Wrench 17 mm Allen key set Glass fuses 2 A and 5 A Bits holder O-rings L&W Autoline Base Unit | OPERATING INSTRUCTIONS https://manual-hub.com/... - Page 23 In the European Union Please contact your local ABB representative who will inform you about the take-back of the product. Small products (and small amounts) might be taken back by your local collection facilities.
- Page 24 — ABB AB/LORENTZEN & WETTRE P.O. BOX 4, SE-164 93 Kista, Sweden Phone: +46-8-477 90 00 www.abb.com/pulpandpaper https://manual-hub.com/...
