- Page 1 PG5308A / PG5308B PG5308G / PG6308A PG6308B / PG6308G PG8208G / PG8308A PG8308B / PG8308G 8-Outlet 1U eco PDU User Manual...
-
Page 2: Compliance Statements
8-Outlet 1U eco PDU User Manual Compliance Statements FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 3 8-Outlet 1U eco PDU User Manual Industry Canada Statement This Class A digital apparatus complies with Canadian ICES-003. RoHS This product is RoHS compliant. PE Device Safety Notice Set the maximum permissible breaker protection in the building circuitry to the current rating specified on the rating plate. Observe all national regulations and safety codes as well as deviations for breakers.
-
Page 4: User Information
ATEN is not liable for any loss or damage. -
Page 5: Product Information
8-Outlet 1U eco PDU User Manual Product Information For information about all ATEN products and how they can help you connect without limits, visit ATEN on the Web or contact an ATEN Authorized Reseller. Visit ATEN on the Web for a list of locations and telephone numbers: International http://www.aten.com... -
Page 6: Table Of Contents
Components ......... . . 7 PG5308A Front View ........7 PG6308A / PG8308A Front View . - Page 7 8-Outlet 1U eco PDU User Manual RS-232 Command List ....... . 24 Cascade &...
- Page 8 8-Outlet 1U eco PDU User Manual Chapter 6. User Management Overview..........49 Administrator Information .
- Page 9 Script Management........88 ATEN Python Library ........89 Get Outlet Info .
- Page 10 8-Outlet 1U eco PDU User Manual Station List......... . 96 Backup .
- Page 11 PG8208G ......... . 137 ATEN Warranty Policy ........138...
-
Page 12: About This Manual
8-Outlet 1U eco PDU User Manual About This Manual This manual is provided to help you get the most out of your eco PDU. It covers all aspects of the power distribution unit, including installation, configuration, and operation. An overview of the information found in the manual is provided below. -
Page 13: Conventions
The product may be updated, with features and functions added, improved, or removed since the release of this manual. For an up-to-date user manual, visit http://www.aten.com/global/en/. Conventions This manual uses the following conventions: Indicates text that you should key in. - Page 14 8-Outlet 1U eco PDU User Manual This Page Intentionally Left Blank...
-
Page 15: Chapter 1. Introduction
Chapter 1 Introduction Overview ATEN's PG series intelligent PDU lineup includes PG53 metered series, PG63 switched series, and PG83 / PG82 outlet-metered & switched series. Each PG series intelligent PDU features 8 outlets* housed in a compact 1U rack enclosure. - Page 16 IT applications while optimizing overall costs. PG5308A / PG6308A / PG8308A contains 8 × NEMA 5-20R socket Note: configurations. PG5308B / PG5308G / PG6308B / PG6308G / PG8308B / PG8308G contains 6 x IEC60320 C13 and 2 ×...
-
Page 17: Features
Auto Ping & Reboot Environment sensor port enables RJ-45 connectivity to connect or daisy- chain up to 8 environment sensors such as ATEN EA1640 for monitoring and management of temperature, humidity, airflow, differential air pressure, and leaks, featuring alerts for potential threats (sold separately) ... -
Page 18: Network
PON port can be connected to the KN series (up to 16 KN devices) and be secondary Note: To be included in a future firmware release. Supports ATEN’s eco DC (Energy & DCIM Management Web GUI) for monitoring power distribution, energy, and environmental data from PDUs and connected devices Outlet Switch Control ... -
Page 19: Proactive Overload Protection (Pop)
Chapter 1. Introduction Proactive Overload Protection (POP) The PG6308 / PG8208 / PG8308 models feature ATEN's exclusive Proactive Overload Protection (POP) technology. Effective on all non-critical outlets, this added safety feature automatically powers off outlets when a current overload occurs. -
Page 20: Requirements
PDU. Only the ATEN Lok-U-Plug cable holders that have been specifically designed to work with the eco PDU can be used. Using any other kinds of cable securing device could potentially result in irreversible damage or harm to the device or users. -
Page 21: Components
Item Description power outlets 8 × NEMA 5-20R Note: Holes for ATEN Lok-U-Plug cable holders are located around the outlets. See Securing the Cables, page 23, for further information. USB Type-A port Connects to a USB Type-A storage device for firmware upgrade or log export. - Page 22 8-Outlet 1U eco PDU User Manual Item Description enter button Press the button to enter the page of the selected item for more information shown on the LCD display. LAN 2 The cable that connects the unit to the Internet, LAN, WAN, or to cascade up to 64 PG PDUs plugs in here.
-
Page 23: Pg6308A / Pg8308A Front View
Item Description power outlets 8 × NEMA 5-20R Note: Holes for ATEN Lok-U-Plug cable holders are located around the outlets. See Securing the Cables, page 23, for further information. USB Type-A port Connects to a USB Type-A storage device for firmware upgrade or log export. - Page 24 8-Outlet 1U eco PDU User Manual Item Description LAN 2 The cable that connects the unit to the Internet, LAN, WAN, or to cascade up to 64 PG PDUs plugs in here. sensor port Connects the RJ-45 port to a humidity and temperature sensor (e.g.
-
Page 25: Pg5308B / Pg5308G Front View
8 in total: 6 × IEC60320 C13 2 × IEC60320 C19 Note: Holes for ATEN Lok-U-Plug cable holders are located around the outlets. See Securing the Cables, page 23, for further information. USB Type-A port Connects to a USB Type-A storage device for firmware upgrade or log export. - Page 26 8-Outlet 1U eco PDU User Manual Item Description select button Press the button to cycle the selection between the items; the LCD display indicates which one is currently displayed. enter button Press the button to enter the page of the selected item for more information shown on the LCD display.
-
Page 27: Pg6308B / Pg6308G / Pg8308B / Pg8308G Front View
8 in total: 6 × IEC60320 C13 2 × IEC60320 C19 Note: Holes for ATEN Lok-U-Plug cable holders are located around the outlets. See Securing the Cables, page 23, for further information. USB Type-A port Connects to a USB Type-A storage device for firmware upgrade or log export. - Page 28 8-Outlet 1U eco PDU User Manual Item Description select button Press the button to cycle the selection between the items; the LCD display indicates which one is currently displayed. enter button Press the button to enter the page of the selected item for more information shown on the LCD display.
-
Page 29: Pg5308 / Pg6308 / Pg8308 Rear View
Chapter 1. Introduction PG5308 / PG6308 / PG8308 Rear View Item Description power cord Connects the unit to an AC power source. circuit breaker As a safety measure, if there is an overcurrent situation in regards to the device’s power, the circuit for outlet 1–4 breakers will trip. -
Page 30: Pg8208G Front View
8 in total: 7 × IEC320 C13 1 × IEC320 C19 Note: Holes for ATEN Lok-U-Plug cable holders are located around the outlets. See Securing the Cables, page 23, for further information. USB Type-A port Connects to a USB Type-A storage device for firmware upgrade or log export. - Page 31 Chapter 1. Introduction Item Description enter button Press the button to enter the page of the selected item for more information shown on the LCD display. LAN 2 The cable that connects the unit to the Internet, LAN, WAN, or to cascade up to 64 PG PDUs plugs in here.
-
Page 32: Pg8208G Rear View
8-Outlet 1U eco PDU User Manual PG8208G Rear View Item Description power inlet Plugs the supplied power cord to the PG8208G's power inlet, and then connects it to the external power source. -
Page 33: Chapter 2. Hardware Setup
Chapter 2 Hardware Setup Before You Begin 1. Important safety information regarding the placement of this device is provided on page 123. Please review it before proceeding. 2. Make sure that power to all the devices you will be connecting have been turned off. - Page 34 8-Outlet 1U eco PDU User Manual 2. Align the mounting brackets’ screw holes with that of the front of the rack, and secure the unit onto the rack using self-supplied screws.
-
Page 35: Installation
Chapter 2. Hardware Setup Installation To set up your installation, refer to the installation diagram below (the numbers in the diagram correspond to the numbered steps), and do the following: PC x 8 Hardware / Software Controller Power RS-232 / RS-485 PG8308G RJ-45 Front View... - Page 36 5. (Optional) Connect an RS-232/RS-485 serial controller to the unit's COM port. Note: You can also use the port as a PON port, connecting to an ATEN KVM over IP Switch via an Ethernet cable. 6. Connect the unit’s built-in power cord to an AC power source, thereby turning it on, and then turn on the connected devices.
-
Page 37: Securing The Cables
Chapter 2. Hardware Setup Securing the Cables For added safety, use ATEN Lok-U-Plug cable holders to secure the cables of your powered devices in place on the eco PDU. Secure the cable holders using the specially designed holes around the individual power outlets, as shown below: Note: 1. -
Page 38: Rs-232 Command List
8-Outlet 1U eco PDU User Manual RS-232 Command List Please refer to the table and figure below for the RS-232 management and the list of commands. DB-9 RS-232 RS-232 RX RS-232 TX RS-485 D+ RS-485 D- Wire Table Color Black Brown Orange... -
Page 39: Cascade & Bridge
PDUs. Cascade To cascade multiple ATEN eco PDUs, all the units must be in the same network segment. The cascaded devices can be with different IP addresses. Note: To cascade your devices with one set of IP address, please connect all your units through either LAN 1 port or LAN 2 port. -
Page 40: Concatenate Eco Pdus By Bridge And Cascade
8-Outlet 1U eco PDU User Manual 5. Repeat the procedures similar to step 3 and step 4 to connect other slave units to complete your installation. To use one set of IP address from switch router, connect your eco PDUs as the steps below: 1. -
Page 41: Chapter 3 Basic Operation And First-Time Setup
DC All eco PDUs support eco DC (Energy & DCIM management web GUI). ATEN eco DC provides you with an easy method for managing multiple devices, offering an intuitive and user-friendly Graphical User Interface that allows you to configure a PDU device and monitor power status of the equipment connected to it. -
Page 42: First-Time Setup
8-Outlet 1U eco PDU User Manual First-Time Setup Once the eco PDU installation and connections have been completed, the administrator shall start configuring its network parameters, including changing, the default administrator login settings, and adding users. The easiest way to accomplish this is to log in to it with a browser using a PC within the same LAN. -
Page 43: Network Configuration
Chapter 3. Basic Operation and First-Time Setup Note: Operation details are discussed in the next chapter. For further setup information, continue with this chapter Network Configuration To set up the network, do the following: 1. Click the Setup. The Device Configuration page, similar to the one below, appears. -
Page 44: Changing The Administrator Login
8-Outlet 1U eco PDU User Manual Changing the Administrator Login To change the default administrator username and password, do the following: 1. Click User. Once users have been added to the system, the Accounts page displays a detailed list of users—with more information about them in the large central panel: 2. -
Page 45: Moving On
Chapter 3. Basic Operation and First-Time Setup Note: If you forget the administrator’s name or password, use the reset button to reset the unit. See reset button, page 14 for details. Moving On After setting up the network and changing the default administrator username and password, you can proceed to other administration activities, including adding users, which is covered in the next chapter. - Page 46 8-Outlet 1U eco PDU User Manual This Page Intentionally Left Blank...
-
Page 47: Chapter 4. Logging In
Chapter 4 Logging In Logging In The eco PDU can be accessed via a supported Internet browser from any platform. Note: Browsers must support TLS 1.0. To access the eco PDU do the following: 1. Open your browser and specify the IP address of the eco PDU you want to access in the browser's URL location bar. -
Page 48: The Eco Pdu Main Page
8-Outlet 1U eco PDU User Manual 3. Provide a valid Username and Password (set by the eco PDU administrator). 4. Select your preferred Language from the drop-down menu. 5. Click Login to bring up the browser main page. The eco PDU Main Page After you have successfully logged in, the eco PDU main page comes up with the Energy Connections page displayed: Note: The screen depicts an administrator’s page. -
Page 49: Page Components
Help Connects to the online help section on the ATEN website for the device’s configuration and operation. Logout Click this button to log out of your eco PDU session. - Page 50 8-Outlet 1U eco PDU User Manual This Page Intentionally Left Blank...
-
Page 51: Chapter 5 Energy
Chapter 5 Energy Connection When you log in to the eco PDU, the interface opens with its default selection of Energy Connections, with the PDU Status, Sensor Status, Bank Status, and > Outlet Status sections displayed in the main panel. -
Page 52: Pdu Status
8-Outlet 1U eco PDU User Manual PDU Status All eco PDU models support PDU device level monitoring. The PDU Status section allows you to set up a power management configuration for the PDU device as a whole: PDU Threshold Settings These fields are used to set the maximum threshold settings for the Power, and Aggregate Power Dissipation. -
Page 53: Bank Status
Chapter 5. Energy Bank Status All eco PDU models support Bank level monitoring. The Bank Status section allows you to set up a power management configuration for each of the individual banks: Threshold Settings These fields are used to set the maximum and minimum threshold settings for the Aggregate Current, Voltage, Power, and Power Dissipation. -
Page 54: Outlet Status
8-Outlet 1U eco PDU User Manual Outlet Status Only PG8208G and PG8308 series support Outlet level monitoring. The Outlet Status section allows you to set up a power management configuration for each of the individual outlets: Threshold Settings These fields are used to set the maximum and minimum threshold settings for the Aggregate Current, Voltage, Power, and Power Dissipation. -
Page 55: Configuration
The Configuration page is used to configure the settings of the eco PDU at the bank and individual power outlet level: POP Settings This section allows you to configure the settings for ATEN’s exclusive Proactive Overload Protection (POP) technology. Effective on all non-critical outlets, this added safety feature automatically powers off when a current overload occurs. -
Page 56: Power On Time Schedule Settings
8-Outlet 1U eco PDU User Manual Enable Bank POP Priority Mode: Automatically powers off the outlets according to a pre-configured Bank POP Priority List. See Bank POP Priority List, page 42. Note: PG5308 does not support POP function. Power On Time Schedule Settings Check the Enable Power On Time Schedule box to use the Power ON Delay setting to set the amount of time the eco PDU waits before powering on an outlet. -
Page 57: Outlet Configuration
Chapter 5. Energy Outlet Configuration Outlet Configuration lets you set up the power management configuration for the selected outlet. The meanings of the field headings are described in the following table. Control/Display Description Outlet Shows the port number of the listed outlet. Outlet Name Each outlet can be given a distinctive name. - Page 58 8-Outlet 1U eco PDU User Manual Control/Display Description Remote Turn ON Use the drop-down menu to select one of the choices, below: Method Wake on LAN This is a safe shutdown and restart option. If this is selected, when an outlet is turned Off, the eco PDU first sends a message to the computer telling it to prepare for a shutdown;...
- Page 59 Chapter 5. Energy Control/Display Description MAC Address In order to use either of the safe shutdown and restart methods, the MAC address of the computer connected to the outlet must be filled in here. Auto Ping Auto Ping Method defines the mechanism which the eco PDU uses Method to ping a device and to reboot the outlet.
-
Page 60: Sensor Config
8-Outlet 1U eco PDU User Manual Sensor Config Sensor Config page allows you to configure the alarm for the EA1640 Temperature & Humidity Sensor(s) that connects to the PG8308 unit, and other sensor(s) that connects to the aforementioned EA1640 sensor. Item Description Shows the port type of the connected EA1640 unit. -
Page 61: Sensor Installation
EA1440 (for 4-pin terminal block), as the connected sensor(s) to estimate the maximum number of EA1640 unit. 3. The sensors are sold separately. Please contact your ATEN dealer or go to ATEN website for product information. The diagrams below illustrate the examples about sensor installation. - Page 62 RJ-45 EA1640 EA1640 RJ-45 RJ-11 RJ-11 ATEN ATEN ATEN Door Sensor Temperature Leakage Sensor Temperature (e.g. EA1440) Sensor (e.g. EA1540) Sensor (e.g. EA1340) (e.g. EA1340) RJ-45 EA1640 EA1640 RJ-45 RJ-11 ATEN Temperature ATEN Door Sensor Sensor (e.g. EA1340) (e.g. EA1440)
-
Page 63: Chapter 6 User Management
Chapter 6 User Management Overview Selecting the User tab brings up the Accounts menu, with the Administrator Information and User Information displayed in the main panel. Note: There is a pre-installed administrator account. It can be used to set up the device and to begin creating users and groups. -
Page 64: Administrator Information
8-Outlet 1U eco PDU User Manual Administrator Information This section is used to set the administrator username and password. Only administrators can view this section. For details, see Changing the Administrator Login, page 30. Administrator Define the user name and password for the administrator. ... -
Page 65: User Information
Chapter 6. User Management User Information To add a user, do the following: 1. Set the Management field to Enable. 2. Key in a name and password in the Name and Password fields. 3. Set the outlet-by-outlet permissions of the user in the Outlet field. 4. - Page 66 8-Outlet 1U eco PDU User Manual Field Description Outlet This field allows you to set the outlet-by-outlet permissions of the user. Click on the user/port icon to cycle through the three permissions options, as follows: User has complete access to this outlet. User has read-only access to this outlet.
-
Page 67: Chapter 7 Log
Chapter 7 Overview The eco PDU keeps a record of all transactions that take place on its installation, and stores up to 1024 events at a any given time. -
Page 68: The System Log Event List
8-Outlet 1U eco PDU User Manual The System Log Event List The System Log page provides a powerful array of filters and functions that allow you to view and export the log file data, as well as be informed by SNMP Trap / Syslog / SMTP of specified events as they occur. -
Page 69: Notification Settings
Chapter 7. Log The buttons in the bottom row function as follows: Clear: Click to erase the contents of the log event list First Page: Click to go to the first page of the log event list ... - Page 70 8-Outlet 1U eco PDU User Manual When you first open the page, only the main category items appear. (Main category item rows have a gray background.) Subcategory items are nested under the main category headings. Click the accordion in front of the main category headings to display the subcategory items.
-
Page 71: Chapter 8 Setup
Chapter 8 Setup Device Management The Setup page allows administrators and users with device management permission to configure and control the overall eco PDU operations. -
Page 72: Device Configuration
This item displays the eco PDU’s MAC address. Firmware Version This item displays the current firmware version. You can check if there are any newer versions available on the ATEN website. Rack Location This field lets you give the rack location a unique name for easy Name reference. -
Page 73: Serial Settings
Chapter 8. Setup Select whether to allow only secure browser logins, as shown below: An explanation of the fields is given in the table below: Field Explanation HTTP The port number for a browser login. The default is 80. HTTPS The port number for a secure browser login. - Page 74 8-Outlet 1U eco PDU User Manual For dynamic IP address assignment, select the Obtain IP address automatically radio button. (This is the default setting.) To specify a fixed IP address, select the Set IP address manually radio button and fill in the IP address with values appropriate for your network.
-
Page 75: Ipv6 Configuration
Chapter 8. Setup IPv6 Configuration The eco PDU’s IPv6 IP and DNS addresses (the traditional method of specifying IP addresses) can either be assigned automatically (DHCP), or manually, by specifying a fix IP address. For dynamic IP address assignment, select the Enable autoconfiguration radio button. -
Page 76: Event Notification
8-Outlet 1U eco PDU User Manual To specify the DNS Server address manually, select the Set DNS server address manually radio button, and fill in the addresses for the Preferred and Alternate DNS servers with values appropriate for your network. Note: 1. -
Page 77: Snmp Trap Receivers
Chapter 8. Setup 1. Check Enable report from the following SMTP server, and key in the IP address of your SMTP server. 2. If your server requires authentication, check the My server requires authentication checkbox. 3. Key in the appropriate account information in the Account Name, Password, and From fields. -
Page 78: Syslog Server
8-Outlet 1U eco PDU User Manual 1. Check Enable SNMP Trap. 2. Select which version of SNMP you want to use. 3. Key in the IP address(es) and the service port number(s) of the computer(s) to be notified by the SNMP trap events. The valid port range is 1–65535, with the default port value being 162. -
Page 79: Time Zone
Chapter 8. Setup Time Zone To establish the time zone that the eco PDU is located in, use the Time Zone drop-down menu to choose the city that most closely corresponds to where it is at. If your country or region employs daylight saving time (summer time), check the corresponding checkbox. -
Page 80: Network Time
8-Outlet 1U eco PDU User Manual Network Time To have the time automatically synchronized to a network time server, do the following: 1. Check the Enable auto adjustment checkbox. 2. Select your preferred time server – or – Check the Preferred custom server IP checkbox, and key in the IP address of the time server of your choice. -
Page 81: Security
Chapter 8. Setup Security The Security page controls access to the eco PDU. Login Failures Login Failures allows you to set your account lockout policy. For Allowed field, enter the number of failed login attempts that will cause a user account to be locked. For Timeout field, enter the account lockout duration. -
Page 82: Working Mode
8-Outlet 1U eco PDU User Manual Working Mode If Enable Telnet Server is checked, the eco PDU is accessible via a Telnet sessions using the Telnet username and password (see Telnet, page 25). If Enable Modbus is checked, the eco PDU is accessible and the measurements of the eco PDU such as current, voltage, power, temperature, humidity, and pressure can be read via the Modbus communications protocol. -
Page 83: Session Timeout
Chapter 8. Setup Session Timeout If Enable Web Session Timeout in is checked, a user's web session will logout due to inactivity after the number of Minute(s) entered (1–5) is surpassed. Account Policy The Account Policy section governs policies in regard to the login usernames and passwords. -
Page 84: Ip Filter / Mac Filter
8-Outlet 1U eco PDU User Manual IP Filter / MAC Filter If any filters have been configured, they appear in the IP Filter and/or MAC Filter list boxes. IP and MAC Filters control access to the eco PDU based on the IP and/or MAC addresses of the client computers attempting to connect. -
Page 85: Ip Filter / Mac Filter Conflict
Chapter 8. Setup 3. To filter a single IP address, key in the same address as the start IP. To filter a continuous range of addresses, key in the end number of the range (for example, 192.168.0.225). 4. After filling in the address, click OK. 5. -
Page 86: Authentication & Authorization
8-Outlet 1U eco PDU User Manual Authentication & Authorization The Authentication & Authorization field is used to set up login authentication and authorization management from external sources. RADIUS Settings To allow authentication and authorization for the eco PDU device through a RADIUS server, do the following: 1. -
Page 87: Ldap Settings
Chapter 8. Setup 4. In the Retries field, set the number of allowed retries for attempting to connect to the RADIUS server. The default retries is 3 times. 5. In the Shared Secret field, key in the character string that you want to use for authentication between the eco PDU device and the RADIUS Server. -
Page 88: Tacacs+ Settings
8-Outlet 1U eco PDU User Manual 2. Select a Type of LDAP Server and Security option and fill in the IP addresses/hostname, port numbers, Bind DN, Password, Login Name Attribute, Base DN, User entry object class, and Login Attribute for the LDAP servers. -
Page 89: Private Certificate
When logging in over a secure (SSL) connection, a signed certificate is used to verify that the user is logging in to the intended site. For enhanced security, the Private Certificate section allows you to use your own private encryption key and signed certificate, rather than the default ATEN certificate. -
Page 90: Generating A Self-Signed Certificate
2. Click Browse to the right of Certificate to locate the location path of the certificate file, and select it. 3. Click Upload to complete the procedure. Note: 1. Clicking Restore Default returns the device to using the default ATEN certificate. 2. Both the private encryption key and the signed certificate must be imported at the same time. -
Page 91: Wireless Network
Chapter 8. Setup Wireless Network The Wireless Network page allows you to enable the Wi-Fi capability of the eco PDU. Item Description Enable Wi-Fi Check to enable the Wi-Fi function on the eco PDU. Scan Once the Wi-Fi adapter is connected to the eco PUD’s USB Type-A port, click Scan to scan for any available wireless network in your area. -
Page 92: Ipv4 Configuration
8-Outlet 1U eco PDU User Manual IPv4 Configuration The eco PDU’s IPv4 IP and DNS addresses (the traditional method of specifying IP addresses) can either be assigned automatically (DHCP), or manually, by specifying a fix IP address. For dynamic IP address assignment, select the Obtain IP address automatically radio button. -
Page 93: Ipv6 Configuration
Chapter 8. Setup IPv6 Configuration The eco PDU’s IPv6 IP and DNS addresses (the traditional method of specifying IP addresses) can either be assigned automatically (DHCP), or manually, by specifying a fix IP address. For dynamic IP address assignment, select the Enable autoconfiguration radio button. -
Page 94: Cascade
8-Outlet 1U eco PDU User Manual Cascade The Cascade page allows you to manage and cascade eco PDU in your installation. Check Manage other PDUs over Ethernet checkbox to start the settings. Adding a PDU To add a cascade PDU, do the following: 1. -
Page 95: Connecting A Pdu
Chapter 8. Setup Connecting a PDU To connect to a cascaded PDU, do the following: 1. Check the checkbox(s) beside the ID column of the eco PDU(s) you want to connect. 2. Click Connect. Discovering To discover a cascaded PDU in your installation, do the following: 1. -
Page 96: Rules
8-Outlet 1U eco PDU User Manual Rules The Rules page allows you to manage and set rules for the eco PDU in your installation. Add a New Rule To add a new rule, do the following: 1. Click on the Add button to continue. 2. -
Page 97: Edit The Rules
Chapter 8. Setup Edit the Rules You can edit the rules using the elements: Item Description Enable Check to enable the rule you configured for your eco PDU. Name Enter the name for the rules. Detail Click to bring up more options to configure the rules. Delete Click the bin icon to remove the rules. -
Page 98: Scheduler
8-Outlet 1U eco PDU User Manual Scheduler Use the Scheduler page to power on, power off, or reboot the eco PDU. Creating an Event To create an event, do the following: 1. Go to Setup > Scheduler. 2. Create one or more power-on, power-off, and/or reboot actions. These actions will be selectable when configuring an event. - Page 99 Chapter 8. Setup b) In the pop-up screen, name the action, and use the drop-down lists to configure the action and the target outlet(s). c) Click Save. The action is added to the list. 3. Create an event. a) Click +Create Event. b) In Create Event page, name the event, and then configure the schedule and action as needed.
- Page 100 8-Outlet 1U eco PDU User Manual c) Click Save. The event is added to the event list. Use the toggle button to enable/disable created events.
-
Page 101: Python Script
Chapter 8. Setup Python Script Pyton Script allows users to read the status of ports / connected sensors and control the outlets using the python script integrated with ATEN Python library. Add a New Script To add a new script, do the following:... -
Page 102: Script Management
8-Outlet 1U eco PDU User Manual 1. Click on Create a New Script button. 2. Enter the script name. 3. Enter your source code. 4. Save your script. Note: You can create up to 4 scripts. Script Management From the script list, click on the script you’d like to run to enter the script. The script detail page offers you the following function and information: Item Description... -
Page 103: Aten Python Library
Description Script Output Displays the messages detailing the success or failure of each operation. ATEN Python Library Use the following to write your Python script. Get Outlet Info To get the information about current, voltage, power, frequency, or status of the outlet. -
Page 104: Get Bank Info
8-Outlet 1U eco PDU User Manual Get Bank Info To get the information about current, voltage, power, or frequency of the bank. Syntax atenPythonLib.getBankInfo(port, target, station=1) Example 1. To get the power information of station 1 bank 1: atenPythonLib.getBankInfo(1, “pow”) 2. - Page 105 Chapter 8. Setup Example 1. To get the temperature information of the sensor connected to station 1's sensor port: atenPythonLib.getSensorInfo(1, “temp”, 1) 2. To get the humidity information of the sensor connected to station 1's sensor port: atenPythonLib.changeOutletStatus(1, “hum”, 2)
- Page 106 8-Outlet 1U eco PDU User Manual This Page Intentionally Left Blank...
-
Page 107: Chapter 9 Pdu
Chapter 9 Overview The PDU function is used to upgrade the eco PDU’s firmware, and to backup and restore the device’s configuration settings. -
Page 108: Upgrade Main Firmware
8-Outlet 1U eco PDU User Manual Upgrade Main Firmware The Upgrade Main Firmware page is used to upgrade the firmware of the eco PDU. When you click the Upgrade Main Firmware tab, the display opens with the Firmware file menu page, which looks similar to the one below: A description of the items shown in this panel are given in the table below: Item Description... -
Page 109: Upgrading The Firmware
Chapter 9. PDU Upgrading the Firmware To upgrade the firmware / GE sensor firmware, refer to the UI snapshot on the preceding page, and do the following: 1. Go to our website and download the firmware upgrade file to a convenient location on your computer. -
Page 110: Backup/Restore
8-Outlet 1U eco PDU User Manual Backup/Restore Selecting Backup/Restore on the menu bar gives you the ability to back up the switch’s configuration and user profile information: Station List Station List lists the eco PDU only. Backup To backup the device’s settings, do the following:... -
Page 111: Restore
Chapter 9. PDU 1. In the Password field, key in a password for the setting file to be backed Note: Entering a password is optional. If you do enter a password, make a note of it, since you will need it to be able to restore the file. 2. - Page 112 8-Outlet 1U eco PDU User Manual This Page Intentionally Left Blank...
-
Page 113: Chapter 10. Lcd Menu
Chapter 10 LCD Menu Readout Section on eco PDU The readout section on ATEN eco PDU contains an LCD display for users to check the settings of the unit, and 3 buttons that deliver the following functions: Button Description MENU / BACK Press the button to return to the previous page. -
Page 114: Home Screen
8-Outlet 1U eco PDU User Manual Home Screen Once the unit is connected to an AC power source and turned on, home screen shows on the LCD display. Device (Standalone) -IP1 -IP2 10.3.52.129 0.00 109.64 0.0000 0.0034 KWH Supported Model Item Description PG8208G... -
Page 115: Alert
Chapter 10. LCD Menu Alert On main menu screen, select Alert and press ENTER button to enter its page to check your alert settings. All eco PDU models support Alert function. NO ALERT ALERT Alert -Device Measure Current Sensor Over max threshold Dry Contact Switch ON/OFF Network... -
Page 116: Measure
8-Outlet 1U eco PDU User Manual Measure Users are able to check the following information about your eco PDU. Measure Alert Device Measure Bank Sensor Outlet Dry Contact Switch ON/OFF Network Supported Model Item Description PG8208G PG5308 PG6308 PG8308 Device Indicates the current (A), the voltage (V), the ... -
Page 117: Sensor
Chapter 10. LCD Menu Sensor Select Sensor on the main menu screen and enter its page to check the threshold settings of your installed sensor(s). Sensor EA1640-01 Alert ------ [01-01] ------ Measure [Name] Sensor [Temperature] Dry Contact [Humidity] Switch ON/OFF [Pressure] Network Access your eco PDU via a supported Internet browser, go to Energy >... -
Page 118: Dry Contact
8-Outlet 1U eco PDU User Manual Dry Contact Dry Contact shows the status of the sensor that connected to the installed sensor, EA1640. Refer to Sensor Config, page 46 for how to set up the sensor(s) connected to EA1640. Dry Cntact EA1640-01 ------ [01-01] ------ Alert [Name]... -
Page 119: Switch On/Off
Chapter 10. LCD Menu Switch ON/OFF Switch On/OFF is the function for user to change the power status of the eco PDU. Switch ON/OFF Alert Device Measure - Bank [01] Sensor - Bank [02] Dry Contact Switch ON/OFF Network Supported Model Item Description PG8208G... -
Page 120: Bank
8-Outlet 1U eco PDU User Manual Supported Model Item Description PG8208G PG5308 PG6308 PG8308 Power ON Turn the unit on. Power OFF Turn the unit off. Reboot Reboot the unit. Bank On bank selection list, press SELECT button to select the bank you'd like to check, and then press ENTER button to select the following actions: Switch ON/OFF Bank [01]... -
Page 121: Outlet
Chapter 10. LCD Menu Outlet Press SELECT button to select the outlet to be checked and press ENTER button to enter the outlet detailed page to select the action to be taken: Switch ON/OFF Outlet [01] Bank [01] Power OFF Power ON - Outlet [01] Reboot... -
Page 122: Network
8-Outlet 1U eco PDU User Manual Network Network page contains 2 subpages, IP and Bridge. Network Alert Measure Bridge Disable Sensor Dry Contact Switch ON/OFF Network Supported Model Item Description PG8208G PG5308 PG6308 PG8308 The IPv4 or IPv6 configuration of LAN1, LAN ... -
Page 123: Cascade
Chapter 10. LCD Menu Cascade Cascade page displays the eco PDU's status as illustrated below: Cascade Measure State Standalone Sensor Dry Contact Switch ON/OFF Network Cascade Supported Model Item Description PG8208G PG5308 PG6308 PG8308 State State shows which mode this eco PDU is in: ... -
Page 124: Settings
8-Outlet 1U eco PDU User Manual Settings Enter the Settings page to configure the following: Settings Sensor Rotate LCD Dry Contact Clear PW Dissipation Switch ON/OFF Set Console Network Reboot Cascade Settings Supported Model Item Description PG8208G PG5308 PG6308 PG8308 Rotate LCD Enter the page to set the degree to rotate the ... -
Page 125: Download Log
Chapter 10. LCD Menu To download the event log of your eco PDU, please insert a USB drive to USB Type-A port in advanced. See USB Type-A port, page 13 for details. Dry Contact Download Log Switch ON/OFF Network Cascade Settings Supported Model Item... -
Page 126: Pdu
8-Outlet 1U eco PDU User Manual To back up or restore the configurations of the eco PDU, or to perform firmware upgrade, please insert a USB drive to USB Type-A port in advanced. See USB Type-A port, page 13 for details. Switch ON/OFF Backup CFG Network... -
Page 127: Chapter 11 Telnet Commands
Chapter 11 Telnet Commands Remote Terminal Operations With ATEN eco PDU you can log in remotely from a computer using Telnet interface that allows system control through a high-end controller or PC. Telnet Telnet is a program that connects to a device over a network to provide text- based management and control. -
Page 128: Logging In
8-Outlet 1U eco PDU User Manual Note: If the Enable Telnet Server option is not available, please download the latest firmware from our website. Logging In To log in to the eco PDU via Telnet, do the following: 1. On your computer, open the start menu and select Run, type cmd into Open field, and click OK. -
Page 129: Session Timeout
Chapter 11. Telnet Commands 5. When the Telnet session is established, Logged in successfully appears along with the command line prompt: Session Timeout A live Telnet connection would be terminated if there is no incoming data with 60 Seconds. -
Page 130: Commands
8-Outlet 1U eco PDU User Manual Commands Use the Telnet commands to view and configure the eco PDU as described in each section. The text-based command line provides some of the same functions found under the Energy tab of the eco PDU’s web-based GUI. Commands to view and configure the eco PDU are provide in the following sections. -
Page 131: Read Power Outlet Status
Chapter 11. Telnet Commands Read Power Outlet Status The Read Power Outlet Status command allows you to view the power status of an outlet on the eco PDU. The formula for Read Outlet Status commands is as follows: Command + Outlet + Number + Option + [Enter] 1. -
Page 132: Switch Outlet Status
8-Outlet 1U eco PDU User Manual Switch Outlet Status The Switch Outlet Status command allows you to change the power status of an outlet on the eco PDU. The formula for Switch Outlet Status commands is as follows: Command + Outlet + Number + Option + Control + [Enter] 1. - Page 133 Chapter 11. Telnet Commands The following table lists the available Switch Outlet Status commands: Command Outlet Option Control Enter Description [Enter] Switch outlet XX on with imme option imme or delay. delay XX: Outlet number (01–04) [Enter] Switch outlet XX off with imme option imme or delay.
-
Page 134: Read Environmental Value
8-Outlet 1U eco PDU User Manual Read Environmental Value The Read Environmental Value command allows you to view measurements from the eco PDU’s environmental sensors. The formula for Read Environmental Value commands is as follows: Command + Outlet + Number + Option + [Enter] 1. -
Page 135: Close Telnet Session
Chapter 11. Telnet Commands The following table lists the available Read Environmental Value commands: Command Sensor Option Enter Description [Enter] Read the environmental sensor value read simple on the selected power outlet with sensor format environmental sensor installed. Outlet XX with option simple or format. XX: Outlet number (01–04). -
Page 136: Reboot Pdu Device
8-Outlet 1U eco PDU User Manual Reboot PDU Device The Reboot PDU Device command allows you to reboot the eco PDU. The formula for Reboot PDU Device commands is as follows: Command + [Enter] 1. For example, if you want to reboot the eco PDU, type the following: reboot [Enter] The following tables show the possible values for the Read Environmental Value commands:... -
Page 137: Appendix
Appendix Safety Instructions General This product is for indoor use only. Read all of these instructions. Save them for future reference. Follow all warnings and instructions marked on the device. Do not place the device on any unstable surface (cart, stand, table, etc.). If the device falls, serious damage will result. - Page 138 8-Outlet 1U eco PDU User Manual Do not allow anything to rest on the power cord or cables. Route the power cord and cables so that they cannot be stepped on or tripped over. To help protect your system from sudden, transient increases and decreases in electrical power, use a surge suppressor, line conditioner, or uninterruptible power supply (UPS).
-
Page 139: Rack Mounting
Appendix Instructions for installation and interconnection Equipment intended for use only in restricted access area Protective earthing used as a safeguard Protective conductor current exceeding ES2 limits Plugs as disconnect devices CAUTION: Risk of Explosion if Battery is replaced by an Incorrect Type. Dispose of Used Batteries According to the Instructions. -
Page 140: The Eco Pdu's Main Power Cord
To secure the cables in the eco PDU’s power outlets, use only the ATEN Lock-Your-Plug cable holders that have been specifically designed to work with the eco PDU. Using any other kind of cable securing device could be highly dangerous. Please contact your ATEN dealer for information about ATEN Lock-Your-Plugs. -
Page 141: Resetting The Circuit Breaker
Appendix Resetting the Circuit Breaker Before switching the circuit breaker to reset a trip, power down and disconnect all devices connected to the eco PDU's power outlets to prevent damage caused by a sudden power surge. If a power surge causes the eco PDU’s circuit breaker to switch off the power and it needs to be reset, follow the instructions below. -
Page 142: Technical Support
8-Outlet 1U eco PDU User Manual Technical Support International For online technical support – including troubleshooting, documentation, and software updates: http://eservice.aten.com For telephone support, see Telephone Support on page iv. North America Email Support support@aten-usa.com Online Troubleshooting http://www.aten-usa.com/support... -
Page 143: Ip Address Determination
Appendix IP Address Determination If you are an administrator logging in for the first time, you need to access the eco PDU in order to give it an IP address that users can connect to. There are two methods to choose from. In each case, your client computer must be on the same network segment as the eco PDU. -
Page 144: Method 2
ATEN eco DC allows you to determine/assign an IP address in order to configure a PDU device and monitor power status of the equipment connected to it. ATEN eco DC can be obtained from the Download area of the ATEN website. -
Page 145: Specifications
Appendix Specifications PG5308A / PG5308B / PG5308G Function PG5308A PG5308B PG5308G Electrical Nominal Input 100–120 VAC 100–240 VAC 100–240 VAC Voltage Maximum Input 30A Max, 24A (UL) 30A Max, 24A (UL) 32A Max Current Input Frequency 50–60 Hz Input Connection... - Page 146 8-Outlet 1U eco PDU User Manual Function PG5308A PG5308B PG5308G Environmental Temperature 0–60°C/ –20–60°C (Operating / Storage) Humidity (Operating 0–80% RH, Non-Condensing & Storage) Compliance EMC Verification Safety Verification UL, PSE UL, PSE CE, UKCA...
-
Page 147: Pg6308A / Pg6308B / Pg6308G
Appendix PG6308A / PG6308B / PG6308G Function PG6308A PG6308B PG6308G Electrical Nominal Input 100–120 VAC 100–240 VAC 100–240 VAC Voltage Maximum Input 30A Max, 24A (UL) 30A Max, 24A (UL) 32A Max Current Input Frequency 50–60 Hz Input Connection NEMA L5-30P NEMA L6-30P IEC 60309 32A 3600VA (Max),... - Page 148 8-Outlet 1U eco PDU User Manual Function PG6308A PG6308B PG6308G Humidity (Operating 0–80% RH, Non-Condensing & Storage) Compliance EMC Verification Safety Verification UL, PSE UL, PSE CE, UKCA...
-
Page 149: Pg8308A / Pg8308B / Pg8308G
Appendix PG8308A / PG8308B / PG8308G Function PG8308A PG8308B PG8308G Electrical Nominal Input 100–120 VAC 100–240 VAC 100–240 VAC Voltage Maximum Input 30A Max, 24A (UL) 30A Max, 24A (UL) 32A Max Current Input Frequency 50–60 Hz Input Connection 30A Max, 24A (UL) NEMA L6-30P IEC 60309 32A 3600VA (Max),... - Page 150 8-Outlet 1U eco PDU User Manual Function PG8308A PG8308B PG8308G Humidity (Operating 0–80% RH, Non-Condensing & Storage) Compliance EMC Verification Safety Verification UL, PSE UL, PSE CE, UKCA...
- Page 151 Appendix PG8208G Function PG8208G Electrical Nominal Input Voltage 100–240 VAC Maximum Input Current 16A Max Input Frequency 50–60 Hz Input Connection IEC 60320 C20 Input Power 3840VA (Max) 7 × IEC320 C13 Outlet Type 1 × IEC320 C19 Nominal Output Voltage 100–240 VAC C13:10A (Max) Maximum Output Current (Outlet)
-
Page 152: Aten Warranty Policy
Copyright © 2025 ATEN® International Co., Ltd. Released: 2025-05-19 ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved. All other brand names and trademarks are the registered property of their respective owners.
Need help?
Do you have a question about the PG5308A and is the answer not in the manual?
Questions and answers
