- Page 1 PE5108-ATB / PE5208-ATB PE6108-ATB / PE6208-ATB PE8108-ATB / PE8208-ATB 8-Outlet 1U Metered eco PDU User Manual...
-
Page 2: Compliance Statements
eco PDU PE Series User Manual Compliance Statements FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 3 eco PDU PE Series User Manual KCC Statement Industry Canada Statement This Class A digital apparatus complies with Canadian ICES-003. VCCI Statement RoHS This product is RoHS compliant.
-
Page 4: Pe Device Safety Notice
eco PDU PE Series User Manual PE Device Safety Notice Set the maximum permissible breaker protection in the building circuitry to the current rating specified on the rating plate. Observe all national regulations and safety codes as well as deviations for breakers. ... -
Page 5: User Information
Japan 81-3-5615-5811 Korea 82-2-467-6789 North America 1-888-999-ATEN ext 4988 1-949-428-1111 User Notice All information, documentation, and specifications contained in this manual are subject to change without prior notification by the manufacturer. The manufacturer makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties as to merchantability or fitness for any particular purpose. -
Page 6: Product Information
PDU PE Series User Manual Product Information For information about all ATEN products and how they can help you connect without limits, visit ATEN on the Web or contact an ATEN Authorized Reseller. Visit ATEN on the Web for a list of locations and telephone numbers: International http://www.aten.com... -
Page 7: Table Of Contents
eco PDU PE Series User Manual Contents Compliance Statements ........ii Consignes de sècuritè... - Page 8 eco PDU PE Series User Manual PE6208A / PE8208A Front View ......14 PE6108A / PE6208A / PE8108A / PE8208A Rear View ..14 PE6108A / PE6208A / PE8108A / PE8208A Readout Section .
- Page 9 eco PDU PE Series User Manual The System Log Event List ......51 Notification Settings .
- Page 10 Administrator Login Failure ......107 ATEN Warranty Policy ........108...
-
Page 11: About This Manual
Read this manual thoroughly and follow the installation and operation procedures carefully to prevent any damage to the unit and/or connected devices. The product may be updated, with features and functions added, improved, or removed since the release of this manual. For an up-to-date user manual, visit http://www.aten.com/global/en/. -
Page 12: Conventions
eco PDU PE Series User Manual Conventions This manual uses the following conventions: Monospaced Indicates text that you should key in. Indicates keys you should press. For example, [Enter] means to press the Enter key. If keys need to be chorded, they appear together in the same bracket with a plus sign between them: [Ctrl+Alt]. -
Page 13: Chapter 1 Introduction
ATEN eco PDU supports any 3rd-party SNMP v3 manager software and ATEN eco DC (eco PDU manager web GUI). ATEN eco DC provides you with an easy method for managing multiple devices, offering an intuitive and user-friendly graphical user interface that allows you to configure a PDU device and monitor power status of the equipment connected. - Page 14 eco PDU PE Series User Manual provides a faster response time to recover servers and other devices during power loss due to circuit overload. With its advanced security features and ease of operation, the eco PDU is the most convenient, reliable, and cost-effective way to remotely manage power access for multiple computer installations and allocate power resources efficiently.
-
Page 15: Pe Series Eco Pdu Comparison Chart
Chapter 1. Introduction PE Series eco PDU Comparison Chart Amps Power Cord Monitoring Model Outlets (IEC C19 to) Level Per Port Total PE5108A NEMA 5-15P NEMA 5-15R PE5108B NEMA 6-15P IEC C13 PE5108G IEC C14 IEC C13 PE5208A NEMA 5-20P NEMA 5-20R PE5208B NEMA 6-20P... -
Page 16: Features
eco PDU PE Series User Manual Features Power Distribution Space saving 1U rack mount design with rear mounting IEC or NEMA outlet models 3 digit 7-segment front panel LED display showing the current, IP address of PDU, and outlets ... -
Page 17: Management
Chapter 1. Introduction Management Power status measurement at the PDU/outlet level LED indicators for current and IP address at the PDU device and / or outlet levels. Real-time current, voltage, and kWH displayed in a browsed-based UI for monitoring at the PDU level (PE5108 / PE5208 / PE6108 / PE6208) and at the outlet level (PE7108 / PE7208 / PE8108 / PE8208) ... -
Page 18: Requirements
eco PDU PE Series User Manual Requirements Browsers accessing the eco PDU unit must support TLS 1.2. For cold booting of attached computers, the computer's BIOS must support Wake on LAN or System after AC Back. For safe shutdown: ... -
Page 19: Optional Accessories
Sensor Management Sensors can be managed via the eco PDU’s built-in graphical user interface (GUI) or with ATEN eco DC that can be downloaded from the ATEN website. Cable Holders Cable holders are optional accessories. For added safety, use ATEN Lok-U-Plug cable holders to secure the connecting cables of your attached devices in place on the eco PDU. -
Page 20: Components
eco PDU PE Series User Manual Components PE5108A Front View PE5208A Front View PE5108A / PE5208A Rear View... -
Page 21: Pe5108A / Pe5208A Readout Section
Press the button to recover normal operation. power sockets 8 x NEMA 5-15R or 8 x NEMA 5-20R Note: Holes for ATEN Lok-U-Plug cable holders are located around the sockets. See Securing the Cables, page 23, for further information. ... - Page 22 eco PDU PE Series User Manual Item Description power LED The LED lights when the eco PDU is ready to operate. grounding The wire used to ground the unit connects here. terminal sensor ports External sensors plug into these two RJ-11 ports. power socket The power cord that connects the unit to an AC power source plugs in here.
-
Page 23: Pe5108B / Pe5108G Front View
Chapter 1. Introduction PE5108B / PE5108G Front View PE5208B / PE5208G Front View PE5108B / PE5108G / PE5208B / PE5208G Rear View... -
Page 24: Pe5108B / Pe5108G / Pe5208B / Pe5208G Readout Section
8 x IEC60320 C13 or 7 x IEC60320 C13 + 1 x C19 Note: Holes for ATEN Lok-U-Plug cable holders are located around the sockets. See Securing the Cables, page 23, for further information. - Page 25 Chapter 1. Introduction Item Description power LED The LED lights when the eco PDU is ready to operate. grounding The wire used to ground the unit connects here. terminal sensor ports External sensors plug into these two RJ-11 ports. power socket The power cord that connects the unit to an AC power source plugs in here.
-
Page 26: Pe6108A / Pe8108A Front View
eco PDU PE Series User Manual PE6108A / PE8108A Front View PE6208A / PE8208A Front View PE6108A / PE6208A / PE8108A / PE8208A Rear View... -
Page 27: Pe6108A / Pe6208A / Pe8108A / Pe8208A Readout Section
Press the button to recover normal operation. power sockets 8 x NEMA 5-15R or 8 x NEMA 5-20R Note: Holes for ATEN Lok-U-Plug cable holders are located around the sockets. See Securing the Cables, page 23, for further information. outlet status These LEDs indicate outlet status. - Page 28 eco PDU PE Series User Manual Item Description reset button This button is recessed and must be pushed with a thin object, such as the end of a paper clip. Press and release to reboot the device. Press and hold for more that three seconds to reset the eco PDU to its factory default settings power LED The LED lights when the eco PDU is ready to operate.
-
Page 29: Pe6108B / Pe6108G / Pe8108B / Pe8108G Front View
Chapter 1. Introduction PE6108B / PE6108G / PE8108B / PE8108G Front View PE6208B / PE6208G / PE8208B / PE8208G Front View PE6108B / PE6108G / PE6208B / PE6208G / PE8108B / PE8108G / PE8208B / PE8208G Rear View... -
Page 30: Pe6108B / Pe6108G / Pe6208B / Pe6208G / Pe8108B / Pe8108G / Pe8208B / Pe8208G Readout Section
8 x IEC320 C13 or 7 x IEC320 C13 + 1 x C19 Note: Holes for ATEN Lok-U-Plug cable holders are located around the sockets. See Securing the Cables, page 23, for further information. - Page 31 Chapter 1. Introduction Item Description reset button This button is recessed and must be pushed with a thin object, such as the end of a paper clip. Press and release to reboot the device. Press and hold for more that three seconds to reset the eco PDU to its factory default settings power LED Lights when the unit is powered up and ready to operate.
- Page 32 eco PDU PE Series User Manual This Page Intentionally Left Blank...
-
Page 33: Chapter 2. Hardware Setup
Chapter 2 Hardware Setup Before You Begin 1. Important safety information regarding the placement of this device is provided on page 83. Please review it before proceeding. 2. Make sure that power to all the devices you will be connecting have been turned off. -
Page 34: Installation
eco PDU PE Series User Manual Installation To set up your eco PDU installation, refer to the installation diagram on the next page (the numbers in the diagram correspond to the numbered steps), and do the following: 1. Use a grounding wire to ground the eco PDU by connecting one end of the wire to its grounding terminal, and the other end of the wire to a suitable grounded object. -
Page 35: Securing The Cables
Chapter 2. Hardware Setup Securing the Cables For added safety, use ATEN Lok-U-Plug cable holders to secure the cables from your attached devices in place on the eco PDU unit. Secure the cable holders using the specially designed holes around the individual power outlets, as shown below: Note: 1. -
Page 36: Securing The Sensors
eco PDU PE Series User Manual Securing the Sensors Connect the sensors to the eco PDU’s front panel sensor ports and secure them using sensor mounts, tie wraps, and adhesive cable tie holders. If you use a tie wrap to secure the sensor, tighten the tie wrap over the recessed channel on the sensor, as shown in the following diagram: Note: 1. -
Page 37: Chapter 3 Basic Operation And First-Time Setup
Graphical Interface that allows you to configure a PDU device and monitor power status of the equipment connected to it. eco DC Energy Management Software can be downloaded from the ATEN website, along with a separate eco DC User Manual. -
Page 38: First-Time Setup
eco PDU PE Series User Manual First-Time Setup Once the eco PDU installation has been cabled up, the next task the Administrator needs to perform involve configuring the network parameters, changing the default Super Administrator login settings, and adding users. The way to accomplish this is to log in via web browser. -
Page 39: Network Configuration
Chapter 3. Basic Operation and First-Time Setup Network Configuration To configure the network settings, do the following: 1. Click the Setup tab. 2. The interface displays the Device Configuration page. A screen similar to the one below appears: 3. Fill in the fields according to the information provided under Device Configuration, page 54. -
Page 40: Changing The Administrator Login
eco PDU PE Series User Manual Changing the Administrator Login To change the default Administrator username and password, do the following: 1. Click the User tab. The Accounts page has a detailed list of users—with more information about them—in the large central panel: 2. -
Page 41: Chapter 4. Browser Operation
Chapter 4 Browser Operation Logging In The eco PDU can be accessed via a supported Internet browser from any platform. Note: Browsers must support TLS 1.0. To access the eco PDU do the following: 1. Open your browser and specify the IP address of the eco PDU you want to access in the browser's URL location bar. -
Page 42: The Eco Pdu Main Page
eco PDU PE Series User Manual 3. Provide a valid username and password (set by the administrator). 4. Select your preferred language from the drop-down menu. 5. Then click Login to bring up the browser main page. The eco PDU Main Page After you have successfully logged in, the eco PDU Main Page comes up with the Energy Connections page displayed: Note: The screen depicts an Administrator’s page. -
Page 43: Page Components
The Sidebar provides a tree view listing of outlets that relate to the various tab bar and menu bar selections. Help Connects to on-line help at the ATEN website for the device’s configuration and operation. Logout Click this button to log out of your eco PDU session. -
Page 44: Energy
eco PDU PE Series User Manual Energy Connections When you log in to the eco PDU, the interface opens with its default selection of the Energy tab; and the Connections menu. The contents of the PDU Status, Sensor Status, and Outlet Status sections are displayed in the main panel. - Page 45 Chapter 4. Browser Operation PDU Status All eco PDU models support PDU device level monitoring. The PDU Status section allows you to set up a power management configuration for the PDU device as a whole: PDU Threshold Settings These fields are used to set the maximum, minimum, and fluctuation threshold settings for Aggregate Current, Voltage, Power, and Aggregate Power Dissipation.
-
Page 46: Outlet Status
eco PDU PE Series User Manual Outlet Status The Outlet Status section allows you to set up a power management configuration for each of the individual outlets: Threshold Settings These fields are used to set the maximum and minimum threshold settings for the Aggregate Current, Voltage, Power, and Power Dissipation. -
Page 47: Configuration
The Configuration page is used to configure the settings of the PDU at the individual power outlet level. POP Settings This section allows you to configure the settings for ATEN’s exclusive Proactive Overload Protection (POP) technology. Effective on all non-critical outlets, this added safety feature automatically powers off when a current overload occurs. - Page 48 eco PDU PE Series User Manual POP Setting Scenarios Setting Description Triggers Proactive Overload Protection to power off an outlet when it's Current Max Threshold setting is exceeded. Only the outlet that exceeds the threshold setting is powered off. Triggers setting A and: Triggers Proactive Overload Protection to shut off power to a newly inserted device (LIFO), when it...
- Page 49 Chapter 4. Browser Operation Buzzer Setting Checking the Enable Buzzer Alarm box sounds an alarm and sends SNMP trap or e-mail alerts when a threshold setting exceeds the minimum or maximum setting. Outlet Reboot Setting Checking the Enable Outlet Sequential Reboot box allows you to sequentially reboot all outlets by pressing the Power Control Button of Outlet 1 for more than 8 seconds.
-
Page 50: Outlet Configuration
eco PDU PE Series User Manual Outlet Configuration Outlet Configuration lets you set up the power management configuration for the selected outlet. The meanings of the field headings are described in the following table. Heading Meaning Outlet Shows the port number of the listed outlet. Outlet Name Each outlet can be given a distinctive name. - Page 51 Chapter 4. Browser Operation Heading Meaning Delay Time (sec) Sets the amount of time the eco PDU waits after the Power Button Power OFF is clicked (see Outlet Status, page 34), before it turns off the power to the outlet. For the System after AC Back option (see below), after the delay time expires, the eco PDU waits another fifteen seconds, then shuts the computer down.
- Page 52 eco PDU PE Series User Manual Heading Meaning Holiday Mode Use this drop-down menu to select the outlet’s Holiday Mode. When Holiday Mode is enabled, each outlet will be set to the selection chosen for it: POWER OFF or POWER ON. When Holiday Mode is disabled, the outlets return to the outlet status setting before Holiday Mode was enabled.
-
Page 53: Heartbeat
PDU Power Controller to monitor the connected device(s) and control when the outlet(s) is rebooted. Make sure to install the ATEN utility, Power Monitor, to your PC before configuring Heartbeat Monitor settings. You can download the Power... - Page 54 eco PDU PE Series User Manual Create a New Target To create a new target, click on the +Create Target button to enter Create Target page, and fill in the following fields: Item Description Target Name Enter the name for the target device. Action Select the outlet to be rebooted, and define how many times you'd like to reboot the selected outlet.
- Page 55 Chapter 4. Browser Operation Save your settings, and now the target is created and listed on the Heartbeat Monitor list. Monitor, Edit, and Delete a Target Heartbeat Monitor list delivers the following information: Item Description Target Name The name of the target device IP Address The IP address of the target device Outlet No.
- Page 56 eco PDU PE Series User Manual On the Edit Target page, you may: Make changes of the settings and click on Save button to apply the changed settings. Click on Cancel button to discard your changed settings. Click on Delete button to remove the target from Heartbeat Monitor list.
-
Page 57: Autoping
Chapter 4. Browser Operation Autoping Autoping Monitoring defines the mechanism which the eco PDU uses to ping a device and to reboot the outlet. To enable this setting, you need to create a new target first. Create a New Target To create a new target, click on the +Create Target button to enter Create Target page, and fill in the following fields:... - Page 58 eco PDU PE Series User Manual Item Description Target Name Enter the name for the target device. Action Enter the maximum number of times that the eco PDU reboots the outlet of the target device after the consecutive pings. "None" means no outlet will be rebooted.
- Page 59 Chapter 4. Browser Operation Monitor, Edit, and Delete a Target To edit or delete a target, click on the target to be edited to enter the Edit Target page. On the Edit Target page, you may: Make changes of the settings and click on Save button to apply the changed settings.
-
Page 60: User
eco PDU PE Series User Manual User When you select the User tab the screen comes up with Administrator Information and User Information displayed in the main panel. The eco PDU supports one Administrator account and up to eight User accounts. Note: 1. -
Page 61: Administrator Information
Chapter 4. Browser Operation Administrator Information This section is used to set the Administrator name and password. Only Administrators can view this section. For details, see Changing the Administrator Login, page 28. SNMPv3 Account Information Enter values for Name, Auth-Password and Priv-Password for SNMPv3 authentication, if required. - Page 62 eco PDU PE Series User Manual The various options are explained in more detail in the following table: Field Description Management The Management field allows you to Enable or Disable a user’s account: Enable – stores the user account (see User Information, page 49 ...
-
Page 63: Log
Chapter 4. Browser Operation The Log tab keeps a record of transactions that take place on its installation, and stores up to 128 events at one time. The System Log page provides a powerful array of filters and functions that allow you to view and export the log file data, as well as be informed by email of specified events as they occur. -
Page 64: Notification Settings
eco PDU PE Series User Manual Previous Page: click to move to the previous page of the log event list Next Page: click to move to the next page of the log event list Last Page: click to move to the last page of the log event list ... - Page 65 Chapter 4. Browser Operation Sub-category items are nested under the main category headings. Click the arrow in front of the main category headings to display the subcategory items. (Sub-category item rows have a white background.) Click the checkboxes under the column headings to select which component(s) will receive notification of the log events.
-
Page 66: Setup
eco PDU PE Series User Manual Setup The Setup tab provides Device Configuration and Security settings. The Device Configuration page allows administrators to configure eco PDU system settings. The Security page controls access to the PDU. Device Configuration This page presents information about the selected device, as described in the following sections: General Item... - Page 67 Chapter 4. Browser Operation Service Ports As a security measure, if a firewall is being used, the Administrator can specify the port numbers that the firewall will allow. If a port other than the default is used, users must specify the port number as part of the IP address when they log in.
- Page 68 eco PDU PE Series User Manual IPv4 Configuration The PDU’s IPv4 IP and DNS addresses (the traditional method of specifying IP addresses) can either be assigned dynamically (DHCP), or a fixed IP address can be specified. For dynamic IP address assignment, select the Obtain IP address automatically radio button.
- Page 69 Chapter 4. Browser Operation IPv6 Configuration The eco PDU’s IPv6 IP and DNS addresses (the traditional method of specifying IP addresses) can either be assigned automatically (DHCP), or manually, by specifying a fix IP address. For dynamic IP address assignment, select the Enable autoconfiguration radio button.
- Page 70 eco PDU PE Series User Manual Event Notification The Event Notification section is divided into three sections: SMTP Server; SNMP Trap Receivers; and Syslog Server. Each section is described below. SMTP Server To have the eco PDU email reports from the SMTP server to you, do the following: 1.
- Page 71 Chapter 4. Browser Operation SNMP Trap Receivers Up to four SNMP management stations can be specified. If you want to use SNMP trap notifications, do the following: 1. Check Enable SNMP Trap. 2. Select which version of SNMP you want to use. 3.
- Page 72 eco PDU PE Series User Manual Syslog Server To record all the events that take place on eco PDU devices and write them to the eco PDU Syslog server, do the following: 1. Check Enable Syslog Server. 2. Key in the IP address and the port number of the Syslog server. The valid port range is 1-65535.
-
Page 73: Date/Time
Chapter 4. Browser Operation Date/Time The Date/Time dialog page sets the eco PDU time parameters: Time Zone To establish the time zone that the eco PDU is located in, drop down the Time Zone list and choose the city that most closely corresponds to where it is at. - Page 74 eco PDU PE Series User Manual Manual Input Use this section to specify the eco PDU’s date and time manually. Click the calendar icon and click the calendar entry for the date. Key the time into the Time field, using the HH:MM:SS (hours, minutes, seconds) format.
-
Page 75: Security
Chapter 4. Browser Operation Security The Security page controls access to the eco PDU device. Login Failures Allowed sets the number of consecutive failed login attempts that are permitted from a remote user. Timeout sets the amount of time a remote user must wait before attempting to login again after exceeding the number of allowed failures. -
Page 76: Ipinstaller Setting
eco PDU PE Series User Manual If Enable Telnet Server is checked, the PDU is accessible via a Telnet sessions using the Telnet username and password (see Telnet, page 49) IPInstaller Setting If Disable is checked, the IP address of the eco PDU cannot be found by the IP Installer software. -
Page 77: Ip Filter / Mac Filter
Chapter 4. Browser Operation Item Description Password Must Contain At Least Checking any of these items requires users to include at least one of the specified items in their password. Note: This policy does not affect existing user accounts. Only new user accounts created after this policy has been enabled, and users required to change their passwords are affected. - Page 78 eco PDU PE Series User Manual 1. Click Add. A dialog box similar to the one below appears: 2. Specify the start filter address in the dialog box (for example, 192.168.0.200), then click OK. 3. To filter a single IP address, key in the same address as the start IP. To filter a continuous range of addresses, key in the end number of the range (for example, 192.168.0.225).
-
Page 79: Modifying Filters
Chapter 4. Browser Operation Modifying Filters To modify a filter, select it in the IP Filter or MAC Filter list box and click Modify. The Modify dialog box is similar to the Add dialog box. When it comes up, simply delete the old address(es) and replace it with the new one(s). -
Page 80: Authentication & Authorization
eco PDU PE Series User Manual Authentication & Authorization The Authentication & Authorization page is used to set up login authentication and authorization management from external sources. RADIUS Settings To allow authentication and authorization for the eco PDU device through a RADIUS server, do the following: 1. - Page 81 Chapter 4. Browser Operation 6. On the RADIUS server, set the entry for each user as follows: su/administrator or su/user Where xxxx represents the Username given to the user when the account was created on the eco PDU device. The user’s access rights are the ones assigned for the eco PDU device, as well.
-
Page 82: Private Certificate
When logging in over a secure (SSL) connection, a signed certificate is used to verify that the user is logging in to the intended site. For enhanced security, the Private Certificate section allows you to use your own private encryption key and signed certificate, rather than the default ATEN certificate. - Page 83 2. Click Browse to the right of Certificate; browse to where your certificate file is located; and select it. 3. Click Upload to complete the procedure. Note: 1. Clicking Restore Default returns the device to using the default ATEN certificate. 2. Both the private encryption key and the signed certificate must be imported at the same time.
-
Page 84: Rules
eco PDU PE Series User Manual Rules The Rules page allows you to manage and set rules for the eco PDU in your installation. Add a New Rule To add a new rule, do the following: 1. Click on the Add button to continue. 2. - Page 85 Chapter 4. Browser Operation Edit the Rules You can edit the rules using the elements: Item Description Enable Check to enable the rule you configured for your eco PDU. Name Enter the name for the rules. Detail Click to bring up more options to configure the rules. Delete Click the bin icon to remove the rules.
-
Page 86: Scheduler
eco PDU PE Series User Manual Scheduler Use the Scheduler page to power on, power off, or reboot the eco PDU. To create an event, follow the steps below. 1. Go to Setup > Scheduler. 2. Create one or more power-on, power-off, and/or reboot actions. These actions will be selectable when configuring an event. - Page 87 Chapter 4. Browser Operation c) Click Save. The action is added to the list. 3. Create an event. a) Click +Create Event. b) In the pop-up screen, name the event, and then configure the schedule and action as needed. c) Click Save. The event is added to the event list. Use the toggle button to enable/disable created events.
-
Page 88: Mail Control
eco PDU PE Series User Manual Mail Control Mail Control is to send the CLI commands by email to control the eco PDU . The default setting is disabled. Item Description Enable Check the checkbox to enable mail control function. Control Username Define the username to perform mail control function. - Page 89 Chapter 4. Browser Operation Receive Mail Server Fill in the following information to define your mail server of the email account that you set to receive the command email(s). Item Description Server Address Enter server address of the email provider that you use to retrieve the command email(s) from the mail server.
- Page 90 eco PDU PE Series User Manual Send Mail Server Specify the information about your outgoing email server. Item Description Server Address Enter the outgoing email server address of your email provider. Server Port Enter the port number that your email server uses. STMPS Enable the checkbox to encrypt and secure the outgoing emails.
-
Page 91: Pdu
Chapter 4. Browser Operation The PDU tab is used to upgrade the eco PDU’s firmware, and to backup and restore the device’s configuration settings. Upgrade Main Firmware The Upgrade Main Firmware page is used to upgrade the firmware of the eco PDU. - Page 92 eco PDU PE Series User Manual Upgrading the Firmware To upgrade the firmware refer to the screenshot on the preceding page, and do the following: 1. Go to our website and download the new firmware file to a convenient location on your computer.
-
Page 93: Backup/Restore
Chapter 4. Browser Operation Backup/Restore Selecting Backup/Restore on the menu bar gives you the ability to back up the switch’s configuration and user profile information: Backup To backup the device’s settings do the following: 1. In the Password field, key in a password for the file. Note: Entering a password is optional. - Page 94 eco PDU PE Series User Manual 2. In the Password field, key in the same password that you used to save the file. Note: If you did not set a password when you created the backup file, you can omit this step. 3.
-
Page 95: Chapter 5. Appendix
Appendix Safety Instructions General This product is for indoor use only. Read all of these instructions. Save them for future reference. Follow all warnings and instructions marked on the device. Do not place the device on any unstable surface (cart, stand, table, etc.). If the device falls, serious damage will result. - Page 96 eco PDU PE Series User Manual If an extension cord is used with this device make sure that the total of the ampere ratings of all products used on this cord does not exceed the extension cord ampere rating. Make sure that the total of all products plugged into the wall outlet does not exceed 15 amperes.
- Page 97 Appendix Only adjust those controls that are covered in the operating instructions. Improper adjustment of other controls may result in damage that will require extensive work by a qualified technician to repair. Do not connect the RJ-11 connector marked “Sensor” to a public telecommunication network.
-
Page 98: Consignes De Sécurité
eco PDU PE Series User Manual Consignes de sécurité Général Ce produit est destiné exclusivement à une utilisation à l’intérieur. Veuillez lire la totalité de ces instructions. Conservez-les afin de pouvoir vous y référer ultérieurement. Respectez l’ensemble des avertissements et instructions inscrits sur l’appareil. - Page 99 Appendix L’équipement doit être installé à proximité de la prise murale et le dispositif de déconnexion (prise de courant femelle) doit être facile d’accès. Veillez à ce que rien ne repose sur le cordon d’alimentation ou les câbles. Acheminez le cordon d’alimentation et les câbles de sorte que personne ne puisse marcher ou trébucher dessus.
- Page 100 eco PDU PE Series User Manual N’utilisez que les commandes qui sont abordées dans le mode d’emploi. Le réglage incorrect d’autres commandes peut être à l’origine de dommages qui nécessiteront beaucoup de travail pour qu’un technicien qualifié puisse réparer l’unité. ...
-
Page 101: Rack Mounting
To secure the cables in the eco PDU’s power outlets, use only the ATEN Lok-U-Plug cable holders that have been specifically designed to work with the eco PDU. Using any other kind of cable securing device could be highly dangerous. Please contact your ATEN dealer for information about ATEN Lok-U-Plugs. -
Page 102: Montage Sur Bâti
Fixation des câbles d’alimentation Pour fixer les câbles aux sorties d’alimentation de l’unité d’alimentation éco, utilisez uniquement les supports de câble Lok-U- Plug d’ATEN qui ont été conçus spécialement pour être utilisés avec l’unité... - Page 103 Appendix d’alimentation éco. L’utilisation de tout autre type système de fixation de câble pourrait s’avérer très dangereuse. Veuillez contacter votre revendeur ATEN pour plus d’informations sur le support de câble ATEN Lok-U-Plug.
-
Page 104: Technical Support
PDU PE Series User Manual Technical Support International For online technical support – including troubleshooting, documentation, and software updates: http://eservice.aten.com For telephone support, see Telephone Support, page v North America Email Support support@aten-usa.com Online Troubleshooting http://www.aten-usa.com/support Technical... -
Page 105: Ip Address Determination
Appendix IP Address Determination If you are an administrator logging in for the first time, you need to access the eco PDU in order to give it an IP address that users can connect to. There are two methods to choose from. In each case, your client computer must be on the same network segment as the eco PDU. - Page 106 ATEN eco DC allows you to determine/assign an IP address in order to configure a PDU device and monitor power status of the equipment connected to it. ATEN eco DC can be obtained from the Download area of the ATEN website.
-
Page 107: Specifications
Appendix Specifications PE5108A / PE5108B / PE5108G PE5108A PE5108B PE5108G Electrical Nominal Input 100–120 VAC 100–240 VAC 100–240 VAC Voltage Maximum 15A Max; 15A Max; 10A Max Input Current 12A (UL de-rated) 12A (UL de-rated) Input 50–60 Hz 50–60 Hz 50–60 Hz Frequency Input... - Page 108 eco PDU PE Series User Manual PE5108A PE5108B PE5108G Environment Sensor Ports Voltage Range: Voltage Range: Voltage Range: 100VAC–250VAC +/- 100VAC– 250VAC +/- 100VAC–250VAC +/- Power Range: Power Range: Power Range: Metering 100W–Maximum 100W–Maximum 100W –Maximum Accuracy Capacity +/- 2%...
-
Page 109: Pe5208A / Pe5208B / Pe5208G
Appendix PE5208A / PE5208B / PE5208G PE5208A PE5208B PE5208G Electrical Nominal Input 100–120 VAC 100–240 VAC 100–240 VAC Voltage Maximum 20A Max; 20A Max; 16A Max Input Current 16A(UL de-rated) 16A(UL de-rated) Input 50–60 Hz 50–60 Hz 50–60 Hz Frequency ... - Page 110 eco PDU PE Series User Manual PE5208A PE5208B PE5208G Environment Sensor Ports Voltage Range: Voltage Range: Voltage Range: 100VAC–250VAC +/- 100VAC–250VAC +/- 100VAC–250VAC +/- Power Range: Power Range: Power Range: Metering 100W–Maximum 100W–Maximum 100W–Maximum Accuracy Capacity +/- 2% Capacity +/- 2%...
-
Page 111: Pe6108A / Pe6108B / Pe6108G
Appendix PE6108A / PE6108B / PE6108G PE6108A PE6108B PE6108G Electrical Nominal Input 100–120 VAC 100–240 VAC 100–240 VAC Voltage Maximum 15A Max; 15A Max; 10A Max Input Current 12A (UL de-rated) 12A (UL de-rated) Input 50–60 Hz 50–60 Hz 50–60 Hz Frequency Input NEMA 5-15P... - Page 112 eco PDU PE Series User Manual PE6108A PE6108B PE6108G Voltage Range: Voltage Range: Voltage Range: 100VAC–250VAC +/- 100VAC–250VAC +/- 100VAC–250VAC +/- Power Range: Power Range: Power Range: Metering 100W –Maximum 100W –Maximum 100W –Maximum Accuracy Capacity +/- 2% Capacity +/- 2%...
-
Page 113: Pe6208A / Pe6208B / Pe6208G
Appendix PE6208A / PE6208B / PE6208G PE6208A PE6208B PE6208G Electrical Nominal Input 100–120 VAC 100–240 VAC 100–240 VAC Voltage Maximum 20A Max; 20A Max; 16A Max Input Current 16A(UL de-rated) 16A(UL de-rated) Input 50–60 Hz 50–60 Hz 50–60 Hz Frequency ... - Page 114 eco PDU PE Series User Manual PE6208A PE6208B PE6208G Environment Sensor Ports Voltage Range: Voltage Range: Voltage Range: 100VAC–250VAC +/- 100VAC–250VAC +/- 100VAC–250VAC +/- Power Range: Power Range: Power Range: Metering 100W–Maximum 100W–Maximum 100W–Maximum Accuracy Capacity +/- 2% Capacity +/- 2%...
-
Page 115: Pe8108A / Pe8108B / Pe8108G
Appendix PE8108A / PE8108B / PE8108G PE8108A PE8108B PE8108G Electrical Nominal Input 100–120 VAC 100–240 VAC 100–240 VAC Voltage Maximum 15A Max; 15A Max; 10A Max Input Current 12A (UL de-rated) 12A (UL de-rated) Input 50–60 Hz 50–60 Hz 50–60 Hz Frequency Input NEMA 5-15P... - Page 116 eco PDU PE Series User Manual PE8108A PE8108B PE8108G Voltage Range: Voltage Range: Voltage Range: 100VAC–250VAC +/- 100VAC–250VAC +/- 100VAC–250VAC +/- Power Range: Power Range: Power Range: Metering 100W –Maximum 100W –Maximum 100W –Maximum Accuracy Capacity +/- 2% Capacity +/- 2%...
-
Page 117: Pe8208A / Pe8208B / Pe8208G
Appendix PE8208A / PE8208B / PE8208G PE8208A PE8208B PE8208G Electrical Nominal Input 100–120 VAC 100–240 VAC 100–240 VAC Voltage Maximum 20A Max; 20A Max; 16A Max Input Current 16A(UL de-rated) 16A(UL de-rated) Input 50–60 Hz 50–60 Hz 50–60 Hz Frequency Input NEMA 5-20P NEMA 6-20P... - Page 118 eco PDU PE Series User Manual PE8208A PE8208B PE8208G Environment Sensor Ports Voltage Range: Voltage Range: Voltage Range: 100VAC–250VAC +/- 100VAC–250VAC +/- 100VAC–250VAC +/- Power Range: Power Range: Power Range: Metering 100W–Maximum 100W–Maximum 100W–Maximum Accuracy Capacity +/- 2% Capacity +/- 2%...
-
Page 119: Administrator Login Failure
Appendix Administrator Login Failure If you are unable to perform an administrator login (because the username and password information has become corrupted, or you have forgotten it, for example), you can clear the login information with the following procedure: 1. Power off the eco PDU and remove its housing. 2. -
Page 120: Aten Warranty Policy
Copyright © 2025 ATEN® International Co., Ltd. Released: 2025-03-07 ATEN and the ATEN logo are registered trademarks of ATEN International Co., Ltd. All rights reserved. All other brand names and trademarks are the registered property of their respective owners.
