Arctic Accelero Twin Turbo II Installation Manual

Installation Manual: www.arctic.ac/fileadmin/att2/manual_en.pdf
EN
Montageanleitung: www.arctic.ac/fileadmin/att2/manual_de.pdf
Guide d'installation: www.arctic.ac/fileadmin/att2/manual_fr.pdf
Manual de instalación: www.arctic.ac/fileadmin/att2/manual_es.pdf
Manual de Instalação: www.arctic.ac/fileadmin/att2/manual_pt.pdf
Installationsmanual: www.arctic.ac/fileadmin/att2/manual_se.pdf
Accessories
Screws (M2) Washers
x 4
*Thermal Adhesive (3 g)
x 1
Heatsinks
x 11
A
*After opening the thermal adhesive, use it shortly thereafter. You may purchase additional heatsinks and thermal adhesive at att2.arctic.ac
Preparation
1
Please ensure that the fan connector pin
assignment on your VGA board is in
accordance with the following table.
3
4
Not cleaning circuit components thoroughly
3
with an eraser leads to no adhesiveness of
the thermal adhesive at all.
6
43.2 mm - use 43.2 mm - use
53.2 mm - use 53.2 mm - use
? ?
51.0 mm - use 51.0 mm - use
58.4 mm - use 58.4 mm - use
or or
6
7a
Spacer
Spacer (1.5 mm)
x 4 x 1
Insulation Tape
(0.5 cm x 10 cm each)
x 2
B
Main Cable Set
Pin No.
Pin 1
1
2 Pin 2
Pin 3
Pin 4
Apply the insulation tape onto the circuit Apply the insulation tape onto the circuit
4
components in order to prevent short components in order to prevent short
circuit caused by RAM and VR heatsink circuit caused by RAM and VR heatsink
interference. interference.
Choose the correct mounting hole size and spacers:
Mounting Hole
① ① 43.2 mm x 43.2 mm
or or
or or
6
② ② 53.2 mm x 53.2 mm
or or
6
③ ③ 51.0 mm x 61.0 mm
58.4 mm x 58.4 mm
43.2 mm x 43.2 mm
58.4 mm x 58.4 mm
6
Please note this table is for reference only. Refer to your own VGA card holes position during installation. The updated
information is available at att2.arctic.ac.
Instalační příručka: www.arctic.ac/fileadmin/att2/manual_cz.pdf
Telepítési kézikönyv: www.arctic.ac/fileadmin/att2/manual_hu.pdf
Instrukcja montażu: www.arctic.ac/fileadmin/att2/manual_pl.pdf
Installatiehandleiding: www.arctic.ac/fileadmin/att2/manual_nl.pdf
Руководство пользователя: www.arctic.ac/fileadmin/att2/manual_ru.pdf
RU
Manuale di installazione: www.arctic.ac/fileadmin/att2/manual_it.pdf
IT
Spacer (2.3 mm)
x 1
4-pin Fan
Power Adapter
x 5
x 4
C
Color Description
Black Ground
Red VDC
Yellow Signal
Blue PWM
Appropriate Spacers Compatible Models
2.3 mm
NVIDIA GeForce:
6600 GT AGP, 6600 GT, 6600 LE, 6600 DDR2, 6600
AMD Radeon:
HD 4770, 2600XT, X1650 XT, X1650 Pro, X1600 XT, X1600 Pro, X1550,
X1300 XT, X1300 Pro, X1300
1.5 mm NVIDIA GeForce:
GT 640
NVIDIA GeForce:
2.3 mm
GTS 450, 250, 240 (OEM), 150 (OEM), GT 340, 330, 320, 130 (OEM),
9800 GTX+, 9800 GTX, 9800 GT, 9600 GT, 9600 GSO 512, 9600 GSO,
8800 GTS 512 (G92), 8800 GTS (G92), 8800 GT, 8800 GS(9600GSO),
7950 GT, 7900 GTX, 7900 GT, 7900 GS, 7800 GTX 512, 7800 GTX, 7800 GT,
6800 Ultra Extreme, 6800 Ultra, 6800 GT, 6800 GS AGP, 6800 GS, 6800 AGP,
6800, 6800 XT AGP, 6800 XT, 6800 LE
AMD Radeon:
HD 7870, 7850, 6970, 6950, 6870, 6850, 6790, 5870, 5850, 5830, 4890, 4870,
4850, 4830, 3870, 3850, X1950 XTX, X1950 XT, X1950 Pro, X1950 GT,
X1900 XTX, X1900 XT, X1900 GT, X1800 XT, X1800 XL, X1800 GTO
3.5 mm NVIDIA GeForce:
GTX 560 Ti, 560 SE, 560, 550 Ti, 460 SE, 460
3.5 mm
NVIDIA GeForce:
GTX 580, 570, 480, 470, 465, 8800 GTX (G80), 8800 GTS (G80)
1.5 mm AMD Radeon:
HD 7770, 6770, 5770
2.3 mm NVIDIA GeForce:
GTX 680, 670
7b
Spacer
Accelero Twin Turbo II
Installation Manual
EN
Spacer (3.5 mm) Mounting Plate
(used for HD 7770, 6770
and 5770 only)
x 1
VGA Bracket
x 1
x 4
D
2
5
x 2
x 2
x 5
E
