- Page 1 OPERATING MANUAL TUF-208R (Red Beam) TUF-208G (Green Beam) IMPORTANT! READ BEFORE USING ...
-
Page 2: Table Of Contents
CONTENTS General Safety ....................Page 3 Feature Chart .....................Page 5 Product Overview ..................Page 6 Keypad and LED ..................Page 7 Battery and Power ..................Page 8 Set Up ......................Page 9 Operation ....................Page 10 Accuracy Check ..................Page 13 Specifications ...................Page 16... -
Page 3: General Safety
GENERAL SAFETY Carefully read the safety instructions and product manual before using this product. The person responsible for the instrument must ensure that all users understand and adhere to these instructions. While the laser tool is in operation, ensure not to expose your eyes to the emitting laser beam. - Page 4 • Do not operate the laser in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. This tool may create sparks which may ignite the dust or fumes. • Store an idle laser out of reach of children and other untrained persons. Laser are dangerous in the hands of untrained users.
-
Page 5: Feature Chart
FEATURE COMPARISON CHART TUF-208R TUF-208G ✔ ✔ H Auto-leveling ✔ ✔ Tilt Warning ✔ ✔ Manual Mode ✔ ✔ Calibratin Mode ✔ ✔ V Auto-levelling ✔ ✔ Manual Slope Mode ✔ ✔ Speed Select ✔ ✔ Spot Mode ✔ ✔... -
Page 6: Product Overview
PRODUCT OVERVIEW (1) Alignment Sight (2) Vertical Up Beam Window (3) Glasses Enclosed (4) Keypad (5) Charging Plug (6) Battery knob (7) Vertical Support Dot (8,9)5/8“ insert for tripod mount. -
Page 7: Keypad And Led
KEYPAD AND LEDS Keypad: Power ON/OFF key Tilt Warning ON/OFF key Rotation Speed key Scan Mode key Manual Slope Mode key Slope adjust key Power LED Power and Manual LED Solid GREEN • Out of levelling Compensation Range • Fully charged/Normal Voltage •... -
Page 8: Battery And Power
BATTERY AND POWER Batteries can explode, or leak, and can cause injury or fire, to reduce this risk: • Carefully follow all instructions and warnings on the battery label and package. • Do not dispose of batteries in fire. • Keep batteries out of reach of children. •... -
Page 9: Set Up
SET UP Horizontal position • Place the laser tool down on its base and be sure surface is near level • Press to power on. Vertical position • Place the laser tool down on its side. be sure surface is near level •... -
Page 10: Operation
OPERATION • Before operating the laser tool always be sure to check the laser tool for accuracy. • In Manual Mode, Auto-Levelling is OFF, the accuracy of the beam is not guaranteed to be level. • Laser tool will indicate when it is out of compensation range. If so, reposition laser tool to closer level. - Page 11 Manual Mode for ≧3s to turn ON/OFF Manual Mode. • When powered ON, press and hold • Auto-Levelling is OFF in Manual Mode. • Laser tool can be manually positioned at any angle or slope. • When Manual Mode is turned OFF, laser tool begins Auto-Levelling as done when initially powered ON.
- Page 12 Spot Mode • Press to the stopped (0 rpm) setting • Press to rotate the direction of the spot clockwise • Press to rotate the direction of the spot counterclockwise. • A single press of will rotate the direction by 0,5° •...
-
Page 13: Accuracy Check
ACCURACY CHECK Note • The laser tools are sealed and calibrated at the factory to the accuracies specified. • It is recommended to perform a calibration check prior to its first use and then periodically during future use. • Be sure to allow the laser tool adequate time to Auto-Level (<60s) prior to a calibration check. •... - Page 14 Horizontal check (see Figure C) • Set the laser tool on a tripod 20m away with the “X1” side facing the wall (C1) • Powered ON the laser tool and allow the laser tool to Auto-Level and be sure laser is rotating •...
- Page 15 Vertical check (see Figure E) (Only necessary on models with vertical Auto-Levelling) • Set the laser tool on a stable surface in its vertical position 1m away from a wall that extends ≧2.0m high with the “Y1” side facing that wall.(E1) •...
-
Page 16: Specifications
SPECIFICATIONS TUF-208R TUF-208G Horizontal Rotary Accuracy ±1 mm @10m (20”) Vertical Rotary Accuracy ±1.5 mm @10m (30”) Vertical Up Beam Accuracy ±3.0mm @30m ≧5° Compensation Range Slope Range ±10% Minimum Increment ±0.01% Scan Range 15°,30°,60° Working Range with detector 0.5m ~ 300m Levelling Time ≤20s...
