- Page 1 Manual of use Installation & Operation PREMIUM EDITION FIREPLACES www.acaminetti-factory.com...
- Page 3 Acaminetti company completes all the costumer requirements, we hav a new vision, to realise the fantasy of costumer with the individual sizes. A.caminetti produce each model with individual sizes. Your fantasy turn into reality ! Your faith to our company, for us is precious, we appriciate it maximal- ly and do our best to make you a satisfied client.
-
Page 4: Table Of Contents
CONTENTS CONTENTS 1.SAFETY 1.SAFETY Risk of burning................04 Risk of burning................04 Safe distance................Safe distance................Putting into operation............05 Putting into operation............06 Open operation................Open operation................Fire in the chimney..............Fire in the chimney..............Supply of combustion air............06 Supply of combustion air............06 Unauthorized technical modifications........ - Page 5 7.GENERAL WARRANTY TERMS Important information..............17 Warranty conditions................ Warranty period................Common wearing................Repair and maintenance.............. Making a claim................. . INTRODUCTION................18 9. CHECKING THE PRODUCT............19 10. TRANSPORT SECURINGS ............20 11. POSITIONING THE FIREPLACE INSERT.........21 12. PIPE OUTLET & AIR INLET.............21 13 CONNECTION TO THE CHIMNEY..........22 14.
-
Page 6: Risk Of Burning
Safety instructions Carefully read these instructions for using the fireplace insert and keep the manual in a safe place. A.caminetti fireplace inserts are certifed according to European standard EN 13229 and carry the CE indication. When assembling the fireplace insert, you must comply with local regulations and instructions applicable to nation- al and European standards. - Page 7 1.2. SPECIAL FIRE SAFETY PRECAUTIONS RELATING TO FLOOR COVERINGS IN THE FIREPLACE VICINITY The figure illustrates a typical installation situation showing a fireplace,and this applies for each fireplace unit. If a log guard (not included) with a height of at least 10 cm is fitted, the minimum distances min.
-
Page 8: Putting Into Operation
- The paint is soft during burning so do not touch it. 1.4. OPEN OPERATION A.caminetti freplace inserts are not designed to be operated with an open door. The fireplace must always be closed with the exception of adding fuel so as to prevent burning wood falling out and combustion gases leaking into the room. -
Page 9: Supply Of Combustion Air
2.2 PERMITTED FUEL it is only permitted to burn only wood in natural condition with the humidity 18% in A.caminetti fireplace inserts. 2.3 TYPES OF WOOD The volume of energy contained in one kilogram of wood is approximately the same for all types of wood. -
Page 10: Storage Of Wood Fuel
2.4. STORAGE OF WOOD FUEL It is recommended to store wood for ideally 2 to 3 years in well ventilated and dry area. optimally, wood is recommended to be stored to the southern part of he house on a grid to provide a fow of air and good ventilation of wood. -
Page 11: Special Precautions For The Fire Protection
1.2b. SPECIAL PRECAUTIONS FOR THE FIRE PROTECTION OF ADJACENT COMPONENTS CONSTRUCTED OF FLAMMABLE MATERIALS 1. A distance of at least 5 cm has to be maintained between built-in furniture (e.g. cupboards) and the fireplace cladding. 1 cm 5 cm 2. A clearance of at least 1 cm is recommended for components with small contact areas (wall, floor or ceiling cladding). -
Page 12: Area Of Direct Radiant Heat
1.2c. FIREPLACE INSERTS - AREA OF DIRECT RADIANT HEAT Distance in the area of direct radiant heat PREMIUM EDITION of the view pane [mm] FIREPLACE INSERTS front side rear CRYSTAL 70 PREMIUM 6-12 kW 1100 – CRYSTAL 90 PREMIUM 1400 6.5-12.5 kW –... -
Page 13: Description Of Control Elements
3. DESCRIPTION OF CONTROL ELEMENTS 3. 1. A.caminetti premium fireplace inserts are produced in one basic versions for opening the door: - liftdoor system FiG. 5a FiG. 5b FiG. 5c handles for opening the door for cleaning handle for opening the door... -
Page 14: Operation Of Fireplace Inserts
4. OPERATION OF FIREPLACE INSERTS 4.1. COMMISSIONING, BURNING PHASE AND REGULATION OF AIR SUPPLY First check that there is no large quantity of ash in the burning chamber. This would cause hot particles to fall from the fireplace insert into the room when adding wood. 1. -
Page 15: Operation In The Transient Period
If you do not want to add more fuel and the dose has burnt out, set the regulation of air to the left to the minimum(-) marked. This will prevent burning air getting into the chamber and will prolong the heat phase. The coal will remain hot in the chamber longer and the heat will not escape through the chimney. -
Page 16: Cleaning And Maintenance
5.1. CLEANING THE GLASS The door of the A.caminetti fireplace insert is produced from high-quality ceramic glass and is fitted with a self-cleaning ceramic glass system. Air supplied into the combustion chamber “rinses” the glass from the inside. Correct regulation of air and by burning dry wood will result in clear glass that won’t need to be cleaned very often. -
Page 17: Removing The Ash
Then place them for 24 hours into a non-flammable vessel out of the reach of children. Your A.caminetti fireplace insert uses the latest and the most effective grid- free method of burning. Remove the ash within regular intervals adapted to the intensity of the heating. -
Page 18: Regular Specialist Maintenance
5.3. REGULAR SPECIALIST MAINTENANCE Once a year, before starting the eating season, the fireplace insert should be inspected by an expert - fireplace technician. This maintenance should include: - Checking and cleaning of the burning chamber for hot-air fireplace insert: - and burnt passages - checking the regulation and air supply system checking the sealing parts and mechanism for opening the door of the fireplace insert... -
Page 19: General Warranty Terms
7. GENERAL WARRANTY TERMS 7.1. IMPORTANT INFORMATION A.caminetti products are produced from high-quality materials with a long service life. The whole manufacturing process is the subject of regular inspection to prevent any defects. The installation of this product requires professional knowledge and, therefore, must only be done by qualifed companies aware of the valid legal provisions. -
Page 20: Repair And Maintenance
Wearing of surface treatment: colour change of the varnish surfaces due o thermal stressing or overheating. Wearing of sealing: decreasing the tightness due to the affection of heat, mechanical wearing and hardening of sealing. Wearing of glass: dirtying by soot or remainders of burn materials, colour or other chang- es by the affection of heat. -
Page 21: Checking The Product
9. CHECKING THE PRODUCT. Immediately after receipt of the consignment, check: - that there is no visible damage - that all movable parts and mechanisms are functional - that the consignment is fully complete and contains: - Installation and User Manual - Warranty Certificate IMMEDIATELY NOTIFY YOUR SUPPLIER OF ANY POTENTIAL DEFECTS AND DISCREPANCIES. -
Page 22: Transport Securings
10. TRANSPORT SECURING REMOVAL When receiving the product,first of all remove all covers,like wooden case,cartoon package and plastic coverage carefully. After that,follow the below instructions before installation: 1.Remove all the transport stoppers positioned as in (Fig.no.12) on both sides in Crystal models and in one side n Quattro series with manual tools or electric drill tool. -
Page 23: Positioning The Fireplace Insert
11. POSITIONING THE FIREPLACE INSERT The distance of the fireplace insert from the floor can be regulated by turning the legs . Use the adjustable legs to balance out a height difference of up to 6 cm (only 1 cm for corner inserts).(Fig.no.13) The fireplace insert must then be balanced horizontally. -
Page 24: Connection To The Chimney
13. CONNECTION TO THE CHIMNEY Before connecting the freplace insert to the chimney, check the size and condition of the chimney (according to the dIn 18160 directives and standards). The correct operation of the chimney according to dIn En 13384 must be signed by legal authority. When making the chimney calculations, you must include the parameters of the freplace insert. -
Page 25: Chimney Position
15.1 CHIMNEY POSITIONING chimneyµ 254 mm Minimum chimney height strom colla flashing 3048 mm to nearest roofllne -- Pitched roof � ,.,. "' wall of parapet -- Flat roof ..,. 3048 mm or more less than 3048 mm -- �-/ recommend� location Multi level roofs □... -
Page 26: Condraweight Placement
( A.caminetti) , in the same time you have to take out the condraweight covering which are galvanised metal.Raise up the coverings and pull them out. -
Page 27: Installing The Fireplace Inserts
17. INSTALLING THE FIREPLACE INSERTS - When assembling the consumer appliance, follow all local regula- tions and regulations related to national and European standards. - during the construction, pay special attention to regulations con- cerning fire safety, options for using materials and the size of the ven- tilation grids. - Page 28 1. Wall 14. Protective floor made from fireproof 2. Insulation layer (chimney flue) material 3. Connection / chimney flue 15. Insulation layer (sides) 4. Insulation layer (rear wall) 16. surroundings (of the room) 5. Convection area 17. radiation area 6. Grid for the inflow of convection air 18.
- Page 29 Insulating layers (protection of standard walls) - The forewall (22) and the wall of the building (20) must be protected by an insulating layer (4, 16) with a minimum thickness of 9 cm. - The surrounding (11) does not need to be protected by the insulating layer if the construction is protected so that the surface of the surroundings heats to a maximum of 85°C.
-
Page 30: Permitted Insulating Materials
- In the forward direction, it depends on the height of the bottom of the com- bustion chamber from the floor, it is necessary to add to this height 20 cm; the minimum value is 30 cm. Area outside the radiation - There must be a minimum gap of 5 cm between the wall of the surroundings and items from flammable materials. -
Page 31: Recessing The Insert
19. RECESSING THE INSERT Recessing the insert If the air intake respectively the vent is positioned on the sides, the areas for the left respectively right sides must be the same size to ensure that the When recessing the insert, adjacent walls that are not insert is evenly cooled. -
Page 32: Wall Of Combustible Material Installation
20. WALL OF COMBUSTIBLE MATERIAL INSTALLATION Wall of non-combustible material that Wall of combustible material is not in contact with combustible material and therefore has no minimum thickness requirement. Wall of non-combustible material, made of 100 mm aerated concrete in the Chimney breast xample. - Page 33 SEALING Avtät alin ni g n Area out 600 cm2 Area out 600 cm2 Area out 600 cm2 Area out 600 cm2 Area in 600 cm2 Always observe the safety distances to combustible material required by a steel flue Area out 600 cm2 Area out 600 cm2 Area out 600 cm2 Area out 600 cm2...
- Page 34 EACH MATERIAL IN OUR FIREPLACES ARE STRICTLY CHOOSEN,WE ARE PROUD FOR OUR PARTNERS,PARTNER COMPANIES: SENOTHERM / SCHOCK METALL / SCHOTT ROBAX / CULIMETA / SKAMOL Culimeta is global leading industry supplier in the field of gaskets for fireplaces, as well as the door and window seals for industrial, stove an heating boiler constructions.
-
Page 35: Product Recycling
PRODUCT RECYCLING The recycling of the appliance is the exclusive responsibility of the owner , who must act in compliance with the laws in force in his country regarding safety , respect and protection of the environment . At the end of its useful life , the product must not be disposed of with urban waste . - Page 36 A.caminetti factory National road km2 Korçë-Ersekë,KORÇË-ALBANIA. A.caminetti GmbH Lager AM Industriegleis 6a, 84030 Ergolding / Germany. info@acaminetti-factory.com www.acaminetti-factory.com...
