SILYNX CLARUS DUAL User Manual

Headset system
Hide thumbs

Advertisement

Table of Contents

PROTECTION FROM WITHIN ™
CLARUS DUAL
HEADSET SYSTEM
user guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLARUS DUAL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SILYNX CLARUS DUAL

Summary of Contents for SILYNX CLARUS DUAL

  • Page 1 PROTECTION FROM WITHIN ™ CLARUS DUAL HEADSET SYSTEM user guide...
  • Page 2 CLARUS SYSTEM COMPONENTS PROTEGO PRO/STD Headset* Vest Mounted Boom Mic* Dual Comms Radio Cable Splitter Cable * Adaptors* Clarus Control Box Bluetooth Gas Mask Wireless PTT* *Optional Adaptor* Adaptor* User Guide...
  • Page 3 PROTEGO EARBUD COMPONENTS External Microphone Strain Releif Foam tip on ear stem Left / Right Foam Sizes: S/M/L Identifier Retainer Tail Alcohol Pad 75% Ethyl Alcohol Right / Left For Disinfection Use Identifier Wind Guard Holder Cleaning Kit (brush Optional Internal Ear and alcohol pad) Retainers S/M/L Wind Guard...

  • Page 4: Control Box

    CONTROL BOX Front View Back View Primary PTT Secondary PTT MOLLE Hear-Thru Hear-Thru AAA Battery Clip Volume Down Volume Up Chamber...
  • Page 5 IN-EAR HEADSET Boom Mic * MOLLE Vest Clip Protego External Ear PRO* Retainer Foam Tip and Earbud Protego PRO features an optional connection for an external microphone. *Optional MOLLE Clip...

  • Page 6: Getting Started

    GETTING STARTED 1. Connect radio adaptor to control box 2. Connect headset to control box Single Radio Configuration Radio Cable Adaptor Dual Radio Configuration PRIME Primary Radio Adaptor Note: In dual configuration, Secondary Radio Adaptor Dual Comms Splitter Cable PTT A activates the primary radio, while PTT B activates Connect the dual comms splitter cable to the control the secondary radio.

  • Page 7: Mounting The Control Box

    MOUNTING THE CONTROL BOX 2. Insert the clip into the MOLLE 1. Insert two zip ties as shown attachment and ensure it is secured in the illustration. by tightening the zip ties around it.
  • Page 8 INSERTING EARBUDS 1. Select the 2. Position the foam largest ear tip onto the earbud tip that fits stem by sliding it comfortably in into place. your ear. *Optional: Internal Ear Retainer. (see next page). 4. Quickly insert the earbud into your ear canal and hold for a 3.
  • Page 9 INSERTING INTERNAL EAR RETAINER In windy conditions, use the internal ear retainer to reduce wind noise. 1. Select a pair 2. Enclose the earbud with of internal the internal ear retainer, ear retainers ensuring that the ear that are stem extends outward. suitable for 3.
  • Page 10 EXTERNAL MIC CONNECTION The Protego PRO allows you to connect an external microphone to the system. When you plug an external microphone into the earphone jack, it becomes the primary microphone. If the external microphone is removed, the system will revert to its default In-Ear microphone configuration.

  • Page 11: Operation

    OPERATION 1. Connect the radio 2. If your radio or cable adaptor to communication the radio and power device doesn’t it on. The unit is provide power usually powered by to the headset, the radio. In a dual use an AAA comms setup, only battery.
  • Page 12 HEAR-THRU The Clarus allows a range of Hear-Thru sensitivity levels. Press (+) key to Press (-) key to increase Hear-Thru decrease Hear-Thru sensitivity level sensitivity level “Maximum Hear- “Hear-Thru Off” Thru” Note: In HAHO/HALO and strong wind environments, it is = Voice Prompt recommended to decrease the Hear-Thru to the lowest level.
  • Page 13 NET MONITORING Net monitoring relies on signals received from either the primary or secondary radio, or both (when using the optional dual comms adaptor). The system differentiates the signals sent to each ear based on the radio connection(s). One Radio Connected Two Radios Connected Right Left...

  • Page 14: Smartphone Connection

    SMARTPHONE CONNECTION Connected directly to the Clarus: 1. Hold PTT A to transmit your voice to the phone. Your voice PTT A PTT B will only be heard when you press and hold PTT A. 2. Short press PTT B to answer / end calls.
  • Page 15 SMARTPHONE CONNECTION Connected to dual comms splitter: 1. When connected to Primary line hold PTT A to transmit. Short press PTT A to answer / end calls. 2. When connected to Secondary line hold PTT B to transmit. Short press PTT B to answer / end calls.

  • Page 16: Bluetooth Pairing

    BLUETOOTH PAIRING* Multifunction Button Volume Down Button Volume Up Button Silynx’s QDC Connector *The Bluetooth Dongle is an optional Clarus cable adaptor. It can enable encrypted Bluetooth connections to a mobile phone. Use a Clarus AAA battery if no radio power is available.
  • Page 17 MWPTT PAIRING* 1. Power on Clarus. 2. Press either PTT buttons on Clarus 5 times, rapidly, within the first minute of powering on. 3. After the fifth press of the button, wait until you hear a slow, repetitive beeping tone in the headset. This indicates that the Clarus is in pairing mode.
  • Page 18 PROTECTION IS POWER PROPRIETARY NOTICE: This document contains information that is proprietary to Silynx Communications, Inc. It is provided exclusively for operational and support needs and is not intended for procurement activities. Silynx Communications, Inc. retains all rights related to procurement and manufacturing. Any use of this document, either directly or indirectly, requires prior written consent from an authorized representative of Silynx Communications, Inc.
  • Page 20 ® www.silynxcom.com 1.866.325.1731 | info@silynxcom.com | customersupport@silynxcom.com CLARUS DUAL User Guide -DOC-USM000027 - October 2024 ALL RIGHTS RESERVED COPYRIGHT ©...
