- Page 1 Acer One 8 T9-422L USER’S MANUAL...
- Page 3 Contents 1.Main introduction for tablet 1.1 Diagram for tablet complete machine........2 1.3 Included accessories...............3 2.Quick start 2.1 Key function..................4 2.2 Homepage interface..............4 2.3 Access to application program.............5 2.4 Character input................5 3.Connection Establishment 3.1 WIFI Connection ................7 3.2 Bluetooth Connection..............8 3.3 Call Function ...................9 3.4 3G Connection ................10 4.Connect the device to computer............11 5.
- Page 4 1 .Brief introduction for Tablet PC 1.1Diagram for tablet complete machine 1 .2 Functional diagram...
- Page 5 1.power key 2.Volume- 3.volume+ 4.Front camera 5.SIM/TF Card slot 6&9. Speakers 7.Earphone port 8.Type-C port 10.Back camera 11.Flashlight 1 .3 Except Tablet PC, the following accessories are included: Power adaptor×1 Type-C cable×1 Earphone×1 User's manual×1 Card removal needle×1...
- Page 6 2. uick start 2.1Key function Descriptions for key function: Long press power key to start up. Under starting up state, long press power key to pop Power key up shutdown option. Under starting up state, short press power key to close the screen.
- Page 7 2. 3 Access to application program How to visit application program of tablet: 1. Swipe up on the main screen to enter the application program (As shown in Figure 2-2). 2. Select the application program you want to visit. 3. If you want to exit the program interface, press the return key to the last interface, or press the homepage key to return homepage interface directly.
- Page 8 Select the input method you need to use According to presetting, tablet will display keyboard when you want to input characters. 1. Press menu key in homepage interface, then click settings,and then click system. 2. Click languages&input. 3. All of the input methods already installed on your tablet will be listed in the text setting region.
- Page 9 :Switch input capital and small letters. :Switch number/symbol/graphic input mode. : Switch input language 3.Connection Establishment 3.1WIFI connection 1. On the home page interface, click the Select menu button to pop up Menu Settings; 2. Click Settings, and then click Network&internet; 3.
- Page 10 3.2 Bluetooth Connection Application of Bluetooth (Figure 3-2) 1.click settings and then click connected devices ,open the Bluetooth device. Figure 3-2 2.Click “Pair new device”, and then you can see the available devices ,click the device you want to connected. Figure 3-3...
- Page 11 3.Device name: you can randomly change the name of Bluetooth for your tablet by click Rename this device. Figure 3-4 3.3 Call Function 1. Insert the SIM card in the power-on state 2. After the network logo appears, in the notification bar, you can make or receive calls.
- Page 12 3.4 4G Connection Your tablet can connect to 4G network after inserting SIM card: 1.On the homepage interface, click setting menu; 2.Click Network&internet; 3.Click mobile network to open Mobile data(Figure 3-6); 4.After opening Mobile data, you can browse web . Figure 3-6 5.Or you can also pull down the menu at the top of the main interface to open the 4G network.
- Page 13 Figure 3-7 4.Connect the device to computer 4.1Connect the device to the computer with a Type-C cable,Drop-down menu on the main interface,select “Charging this device via USB”,as shown below:...
- Page 14 Figure 4-1 Select File transfer,and then you can transfer files between the device and the computer. Figure 4-2...
- Page 15 5. Troubleshooting 5.1. Slow initial boot for tablet After system upgrade of tablet, initial boot needs installation of the pre-installed software applications, and for about 2-3 minutes, it runs faster. 5.2. Tablet can not connect to WIFI Ensure that the wireless router providing the network services works properly.
- Page 16 Google, Android, Google Play, Google Maps and other marks are trademarks of Google LLC.
- Page 17 FCC Caution This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
