Dundas Jafine 1000502267 Use And Care Manual

Use and Care Guide
Air Diffuser
TOOLS REQUIRED
Utility Knife Phillips screwdriver
Installation
1
TRACING THE HOLE
□ Using the flange (A) collar as a template, trace the hole
opening at the installation location with a pencil.
3
ATTACHING THE AIR DIFFUSER TO A DROP CEILING
□ Pull the locking ring (B) around the flange collar (A) and
insert the air diffuser (C) into the flange (A). Adjust the
airflow as needed.
B
A
C
Safety Information
If you are using a rigid duct with your installation, ensure it is securely fastened to the stud. The diffuser inserts directly into the duct opening. No flange
is required.
Warranty
WHAT IS COVERED
All merchandise is warranted to be free from defects in workmanship and material for one year from the date of purchase. This includes normal wear and
performance failure on items. The manufacturer will replace or repair at their option.
WHAT IS NOT COVERED
This warranty only covers normal wear and performance failure. It does not cover any malfunction, performance failure, or defect arising from the misuse,
abuse, neglect, or modification of the product. Any damage or malfunction inflicted upon the product by the user or other external sources, or any failure to
comply with the warnings and instructions, is not covered.
For further assistance visit www.DundasJafine.com.
HARDWARE REQUIRED (NOT INCLUDED)
Pencil
2
CUTTING THE HOLE
□ Using a utility knife, cut the hole by following the outline,
and insert the flange (A) into the opening, ensuring it is
flush with the wall or ceiling.
A
4
ATTACHING THE AIR DIFFUSER TO A
DRYWALL CEILING
□ Secure the outer facing of the flange (A) to the drywall
using screws. Insert the air diffuser (C) into the flange
(A). Adjust the airflow as needed.
Screws (4)
A
A
C
