- Page 1 OWNER’S MANUAL CQ 1520-RX SEQUENCED POWER CONTROL JUNE 2017...
- Page 2 Since individual applications can be subject to extreme variation Juice Goose makes no representation or guarantee as to the suitability of a CQ product for any generally described application.
-
Page 3: Safety Precautions
CQ-SERIES SEQUENCED POWER CONTROL SYSTEM The Juice Goose CQ Series products are power distribution devices that will control AC power application to multiple pieces of equipment. The primary in- tent of the design of this equipment is to power rack mounted audio or video equipment with electric power current requirements of less than 15 amps, 20 amps or 30 amps depending on the CQ model being considered. - Page 4 DETAIL SPECIFICATIONS CQ 1520-RX DIMENSIONS (H x W x D inches) ..……….……………..…..………...1.72 x 19.00 x 7.00 WEIGHT (lbs) ………………………………………………………....……………..10.0 CIRCUIT BREAKER …………………………………..…………..Back Panel, 20A Thermal POWER INPUT..………..………..…Power Cord, 7 Foot, 12/3 SJTW with NEMA 5/20P VOLTAGE INPUT.……………………………………………...……..………...120 VAC at 60 Hz POWER OUTPUTS..…..Six NEMA 5/20R, Sequenced and One NEMA 5/15R Unswitched...
-
Page 5: Installation
INSTALLATION Mount the CQ 1520-RX to a 19” wide rack with metal mounting rails, designed with 1.75” spacing. Use appropriate rack mounting hardware. Plug the power cord into a grounded outlet. Do not defeat the grounding feature of the power cord. -
Page 6: Remote Switch Connection
REMOTE SWITCH CONNECTION Although a Juice Goose CQ Series product can be remote controlled with a Juice Goose RC-5 accessory or another CQ device, it can also be remote activated with a simple contact closure using a switch or relay. The following instructions are provided to assist with this configuration. -
Page 7: Pin Assignments
CQ Series Signal Cable Connectors Signal Signal Input Output 1 2 3 4 5 6 7 8 8 7 6 5 4 3 2 1 PIN ASSIGNMENTS The chart above shows assigned locations for each of the eight pins on the RJ45 connectors on the CQ Series Signal Input and Output. -
Page 8: Operation
Signal Input for the first CQ device can be con- nected to a contact closure (see Remote Switch Connection). Any latching switch or relay will work. Juice Goose recommends use of a double throw device in order to maintain one of two contact closures at all times. - Page 9 155 volts, the RX circuitry will shut off power to connected equipment. MONITORING The CQ 1520-RX has four LEDs on the chassis to allow real time monitor- ing of the device’s operation. One LED labeled “PROC” indicates the CQ 1520-RX is plugged into ac- ceptable utility power and is functioning.
- Page 10 CQ device and contact your local Juice Goose dealer or Juice Goose directly. SERVICE Should your unit require service, contact Juice Goose to receive a service authorization number. This number will allow us to track your returned unit. Please note that no returns will be accepted without such a number.
- Page 11 RACK MOUNTED POWER DISTRIBUTION - Nineteen inch horizontal power distribution with several optional levels of AC power protection. AC LINE FILTRATION - The Juice Goose RX Series Hybrid Filter tech- nology provides very high levels of protection against damaging power surges and high frequency interference on hot, neutral and ground.
- Page 12 Since 1983...
