MST 67A
Pilot's Guide
Honeywell
Mode S Transponder
Effective Date 8/04
006-18301-0000 Rev 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MST 67A and is the answer not in the manual?

Questions and answers

Related Manuals for Honeywell MST 67A

Summary of Contents for Honeywell MST 67A

  • Page 1: System Components

    MST 67A Pilot’s Guide Honeywell Mode S Transponder Effective Date 8/04 006-18301-0000 Rev 1...

  • Page 2: Introduction

    All rights reserved. Reproduction of this publication or any portion thereof by any means without the express written permission of Honeywell International Inc. is prohibited. For further information contact the Manager, Technical Publications; Honeywell; One Technology Center; 23500 West 105th Street; Olathe,...
  • Page 3 Revision History and Instructions Manual MST 67A Pilot’s Guide Revision 1, August 2004 Part Number 006-18301-0000 This revision deletes the RMU 556 from page 2.

  • Page 4: Transpondercontrol Unit; Cta 81A, B, C & D

    Revision History and Instructions Manual MST 67A Pilot’s Guide Revision 0, July 2004 Part Number 006-18301-0000 This is the original version of this publication.

  • Page 5: Table Of Contents

    MST 67A Pilot’s Guide Table of Contents SYSTEM COMPONENTS ....... . .2 INTRODUCTION .

  • Page 6: Section I: Controls And Displays

    MST 67A Pilot’s Guide Controls and Displays FUNCTION SELECTOR CTA 81A/C/D CONTROL UNIT ONLY (SELECTS OPERATING MODE) ALT OFF ALT ON STBY TA/RA TEST Moving the spring loaded knob to TEST position for one second initi- ates a comprehensive self test lasting approximately eight seconds.
  • Page 7 Controls and Displays FUNCTION SELECTOR CTA 81 B CONTROL UNIT ONLY (SELECTS OPERATING MODE) TA TA/RA ATC 1 ON ON ATC 2 STBY STBY TEST TEST The left ATC 1 TEST position (CCW) tests the Mode S Transponder. The right ATC 2 TEST position (CW) tests the ATCRBS transponder only.

  • Page 8: Kfs 578A Transponder Control Unit

    A “Fail” annunciation indicates failure of the selected transponder, antenna or control data. Note: If the KFS 578A is interfaced to a MST 67A Mode S transponder and the MST 67A senses a failure, a failure annunciation will be shown.
  • Page 9 Controls and Displays KFS 578A FUNCTION SELECTOR & ATC CODE SELECT The outer concentric knob on the right selects the transponder mode of operation. PUSH Rotating the function knob (CCW) to the TST posi- tion initiates a comprehensive self test lasting approximately eight seconds.

  • Page 10: Ps 578A Transponder Control Unit

    A “Fail” annunciation indicates failure of the selected transponder, antenna or control data. Note: If the PS 578A is interfaced to a MST 67A Mode S transponder and the MST 67A senses a failure, a failure annunciation will be shown.
  • Page 11 Controls and Displays FID allows entry of an alphanumeric flight identification. Selecting the right inner pushbutton will cycle through the eight characters to be changed. Rotating the right (Pushbutton) inner knob will change the contents of the selected (flashing) character. The inner concentric knob on the left includes an on/off switch.

  • Page 12: Cd 671C Transponder Control Unit

    A “Fail” annunciation indicates fail- ure of the selected transponder, antenna or control data. Note: If the CD 671A is interfaced to a MST 67A Mode S transponder and the MST 67A senses a failure, a failure annunciation will be shown.
  • Page 13 Controls and Displays The Display Window displays the ATC code selection, whether transponder #1 or #2 is active, transponder mode, transponder ident and own aircraft flight level (in TEST) All display annunciations are seen during the control unit self-test. The "R" annunciation is only seen during self-test. "FL" on the control unit is only displayed during self-test and indicates the transponder's encoded altitude.
  • Page 14 MST 67A Pilot’s Guide Controls and Displays SBY places the Mode S Transponder in standby. SBY is annunciat- ed in the display window. Use standby during ground operations. ON activates the selected transponder without altitude reporting. ON is annunciated in the display window.

  • Page 15: Ps 550 Transponder Control Unit

    A “Fail” annunciation indicates failure of the selected transponder, antenna or control data. Note: If the PS 550 is interfaced to a MST 67A Mode S transponder and the MST 67A senses a failure, a failure annunciation will be shown.
  • Page 16 ATC, FL mode, FID and ADC. ATC Mode - Allows entry of the four digit ATC code. Honeywell MST 67A configuration: The right outer knob selects each of the four positions for entry, and the right inner knob selects the content.
  • Page 17 Controls and Displays ALT OFF activates the selected transponder without altitude report- ing. ON is annunciated in the display window. XPDR Activates Mode S transponder with altitude reporting. Effective Date 7/04 006-18301-0000 Rev 0...

  • Page 18: Section Ii: System Considerations

    Some enhanced functionality of the MST 67A is configured at the air- plane level and is not configurable by the pilot. Refer to the MST 67A Installation Manual and the Aircraft Flight Manual for details.

  • Page 19: Section Iii: Appendix

    Appendix SECTION III: APPENDIX THE APPENDIX INCLUDES THE TEST FUNCTION, A GLOSSARY OF TERMS AND RECOMMENDATIONS FOR POST FLIGHT REPORTS. FUNCTIONAL AND AUTOMATIC SELF TEST The Mode S transponder Functional Test determines the operational status of the entire system. The test is initiated by rotating the func- tion selector knob on the Transponder Control Panel to the TEST position.

  • Page 20: Glossary Of Terms

    MST 67A Pilot’s Guide Appendix GLOSSARY OF TERMS ABBREVIATIONS AND DEFINITIONS AFMS Airplane Flight Manual Supplement Above Ground Level Air Traffic Control. A federally operated ground based system that manages aircraft traffic flow. ATCRBS ATC Radar Beacon System. A ground based secondary radar and airborne transponder system used to monitor traffic.
  • Page 21 Appendix ABBREVIATIONS AND DEFINITIONS (CONT’D) Mode A Transponder ATCRBS transponder that replies to ATC interrogations sending identification code but without giving altitude data. Mode C Transponder ATCRBS transponder that replies to ATC interrogations giving identification code or encoded altitude data. Mode S Transponder Transponder that replies to ATC interroga- tions giving an ATCRBS identification code,...
  • Page 22 Honeywell International Inc. One Technology Center 23500 West 105th Street Olathe, Kansas 66061 FAX 913-791-1302 Telephone: (913) 712-0400 Copyright ©2004 Honeywell International Inc. All rights reserved. 006-18301-0000 Rev 1 8/04...
