Easydive LEO3 WI Quick Start Manual

Main Mode
1. Autofocus (exposure reading) in AF-S | AF-C and shooting mode change. To
change shooting mode, press and hold button 1 until the Red Led lights up (15
sec.). In MF it calls up the Push Focus function.
2. In Video or S&Q Mode, Activate or Stop Video Recording. In Photo Mode:
Mode 1: When you press the button you have autofocus, when you release the
button will take the shot (Default Setting).
Mode 2: When you press the button, you have first autofocus and then shooting.
(if the lens is already in focus, direct shooting).
3. This button starts or ends the Video Recording (REC).
The following keys are active in Manual Mode (M). If you choose another mode, only
the functions that can be set manually will be available.
4. Aperture -
5. Aperture +
6. Shutter Speed -
7. Shutter Speed +
8. ISO -
9. ISO +
Press the Buttons 4,5,6,7,8,9 once to change by one step. Keep pressed to quickly
change the chosen parameter.
10. Switch Mode, allows you to change the function of each button. The mode
switch is indicated by a blue LED switched on.
11. On / Off electronic board. To switch on, press until the red LED of the electronics
is activated. To switch off, push until the camera monitor turns off. The camera will
turn off completely. To turn on the camera, push this button again.
Easydive - Via dell'Industria 13 int 6, 48015 Cervia (RA) - Italy
| α 1 |
Button Panel Leo3Wi
Front
info@easydive.it - +39 0544 962923 | +39 338 9994219
Back
