A
技术要求：
1.该手册印刷颜色均为黑色 : PANTONE BLACK C
2.纸张规格为A 5
3.如果供应商的排版需要加空白页， 请加在封底之前
B
C
标记
处数 分区
D
编
制
审 核
审 定
批 准
1
1
更改文件号 签 名
校对
性能
排版
日期
欧洲 T3 六套
用户手册通用版
(Midea 标准版 )
日 期
阶 段 标 记
REV. 00
数
量
重
1
共
1
张
2
比 例
80G双胶
1:1
量
佛山市顺德区美的
洗涤电器制造有限公司
第
1
张
2
A
B
C
D
D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTC36610B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Beko DTC36610B

Summary of Contents for Beko DTC36610B

  • Page 1 技术要求： 1.该手册印刷颜色均为黑色 : PANTONE BLACK C 2.纸张规格为A 5 3.如果供应商的排版需要加空白页， 请加在封底之前 欧洲 T3 六套 用户手册通用版 (Midea 标准版 ) 标记 处数 分区 更改文件号 签 名 日 期 阶 段 标 记 比 例 80G双胶 REV. 00 校对 编 制 性能 数 量 重...
  • Page 2 PART Ⅰ : Generic Version DTC36610B Please read this manual carefully before using the dishwasher and Keep this manual for future reference.

  • Page 3: Table Of Contents

    CONTENTS SAFETY INFORMATION PRODUCT OVERVIEW USING YOUR DISHWASHER Loading The Salt Into The Softener MAINTENANCE AND CLEANING External Care Internal Care Caring For The Dishwasher INSTALLATION INSTRUCTION About Power Connection Water Supply And Drain Connection Of Drain Hoses Position The Appliance TROUBLESHOOTING TIPS LOADING THE BASKETS ACCORDING TO EN50242 NOTE:...

  • Page 4: Safety Information

    SAFETY INFORMATION WARNING When using your dishwasher , follow the precautions listed below: Installation and repair can only be carried out by a qualified technician This appliance is intended to be used in household and similar applications such as: staff kitchen areas in shops, offices and other working environments;...

  • Page 5: Earthing Instructions

    mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. (For IEC60335-1 ) Packaging material could be dangerous for children! This appliance is for indoor household use only. To protect against the risk of electrical shock, do not immerse the unit, cord or plug in water or other liquid.
  • Page 6 Do not modify the plug provided with the appliance; If it does not fit the outlet. Have a proper outlet installed by a qualified electrician. Do not abuse, sit on, or stand on the door or dish rack of the dishwasher. Do not operate your dishwasher unless all enclosure panels are properly in place.
  • Page 7 Do not wash plastic items unless they are marked “dishwasher safe” or the equivalent. For unmarked plastic items not so marked, check the manufacturer's recommendations. Use only detergent and rinse agents recommended for use in an automatic dishwasher. Never use soap, laundry detergent, or hand washing detergent in your dishwasher.
  • Page 8 Disposal For disposing of package and the appliance please go to a recycling center. Therefore cut off the power supply cable and make the door closing device unusable. Cardboard packaging is manufactured from recycled paper and should be disposed in the waste paper collection for recycling.

  • Page 9: Product Overview

    PRODUCT OVERVIEW IMPORTANT: To get the best performance from your dishwasher, read all operating instructions before using it for the first time. Spray arm Salt container Filter assembly Dispenser Cup rack Basket Cutlery rack NOTE: Pictures are only for reference, different models may be different. Please prevail in kind.

  • Page 10: Using Your Dishwasher

    USING YOUR DISHWASHER Before using your dishwasher : Inside Outside 1. Set the water softener 2. Loading the Salt Into the Softener 3. Loading the basket 4. Fill the dispenser Please check the section 1 “Water Softener” of PART Ⅱ: Special Version, Please check the section 1 “Water Softener”...
  • Page 11 Please follow the steps below for adding dishwasher salt: 1. Remove the basket and unscrew the reservoir cap. 2. Place the end of the funnel (supplied) into the hole and pour in about 1kg of dishwasher salt. 3. Before first wash, fill the salt container to its maximum limit with water, It is normal for a small amount of water to come out of the salt container.

  • Page 12: Maintenance And Cleaning

    MAINTENANCE AND CLEANING External Care The door and the door seal Clean the door seals regularly with a soft damp cloth to remove food deposits. When the dishwasher is being loaded, food and drink residues may drip onto the sides of the dishwasher door. These surfaces are outside the wash cabinet and are not accessed by water from the spray arm.
  • Page 13 Fine filter Main filter Main filter Open Open Hold the coarse filter and rotate it Lift fine filter up from main filter. anticlockwise to unlock the filter. Lift the filter upwards and out of the dishwasher. Larger food remnants can be Reassemble the filters in the reverse cleaned by rinsing the filter under order of the disassembly, replace the...

  • Page 14: Caring For The Dishwasher

    Spray arm It is necessary to clean the spray arm regularly for hard water chemicals will clog the spray arm jets and bearings. To clean the spray arm, follow the instructions below: Wash the spray arm in soapy and To remove the spray arm, pull out the spray arm upward.
  • Page 15 Remove the plug Before cleaning or performing maintenance, always remove the plug from the socket. No solvents or abrasive cleaning To clean the exterior and rubber parts of the dishwasher, do not use solvents or abrasive cleaning products. Only use a cloth with warm soapy water. To remove spots or stains from the surface of the interior, use a cloth dampened with water an a little vinegar, or a cleaning product made specifically for dishwashers.

  • Page 16: Installation Instruction

    INSTALLATION INSTRUCTION WARNING Electrical Shock Hazard Disconnect electrical power before installing dishwasher. Failure to do so could result in death or electrical shock. Attention The installation of the pipes and electrical equipments should be done by professionals. About Power Connection WARNING For personal safety: Do not use an extension cord or an adapter...

  • Page 17: Water Supply And Drain

    Water Supply And Drain Cold water connection Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that it is fastened tightly in place. If the water pipes are new or have not been used for an extended period of time, let the water run to make sure ordinary supply hose that the water is clear.

  • Page 18: Connection Of Drain Hoses

    Connection Of Drain Hoses Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into the sink, making sure to avoid bending or crimping it. The height of drain pipe must be less than 600mm. The free end of the hose must not be immersed in water to avoid the back flow of it.

  • Page 19: Position The Appliance

    How to drain excess water from hoses If the sink is 1000 higher from the floor, the excess water in hoses cannot be drained directly into the sink. It will be necessary to drain excess water from hoses into a bowl or suitable container that is held outside and lower than the sink.

  • Page 20: Troubleshooting Tips

    TROUBLESHOOTING TIPS Before Calling For Service Reviewing the charts on the following pages may save you from calling for service. Problem Possible causes Solution Fuse blown, or the Replace fuse or reset circuit breaker. Dishwasher doesn't circuit breaker tripped. Remove any other appliances sharing the start same circuit with the dishwasher.
  • Page 21 Problem Possible Causes What To Do There are rust The affected items Avoid washing items that are not stains on cutlery are not corrosion corrosion resistant in the dishwasher. resistant. A program Always run the quick wash program. was not run after without any crockery in the dishwasher dishwasher salt was and without selecting the Turbo...
  • Page 22 Problem Possible Causes What To Do Combination of soft Use less detergent if you have soft Cloudiness on water and too much water and select a shorter cycle to glassware. detergent. wash the glassware and to get them clean. Aluminium utensils Use a mild abrasive cleaner to Black or grey have rubbed against...

  • Page 23: Loading The Baskets According To En50242

    LOADING THE BASKETS ACCORDING TO EN50242: 1.Basket: Item Item Number Number Cups Dinner plates Medium serving bowl Soup plates Glasses Dessert dishes Saucers Cutlery basket Dish Serving spoons Oval platter...
  • Page 24 Item Number Forks Soup spoons Dessert spoons 4 4 4 Teaspoons Knives Information for comparability tests in accordance with EN 50242 Serving spoons Capacity: 6 place settings Gravy ladles Program: ECO Rinse aid setting: 6 Serving forks Softener setting:...
  • Page 25 PART Ⅱ:S pecial Version DTC36610S Please read this manual carefully before using the dishwasher and Keep this manual for future reference.
  • Page 26 CONTENTS USING YOUR DISHWASHER Control Panel Water Softener Preparing And Loading Dishes Function Of The Rinse Aid And Detergent Filling The Rinse Aid Reservoir Filling The Detergent Dispenser PROGRAM SELECTION Wash Cycle Table Saving Energy Starting A Program Changing The Program Mid-cycle Forget To Add A Dish? ERROR CODES TECHNICAL INFORMATION...
  • Page 27 QUICK USER GUIDE Please read the corresponding content on the instruction manual for detailed operating method. Install the dishwasher (Please check the section 5 “INSTALLATION INSTRUCTION ” PART Ⅰ:Generic Version.) Inside Outside Loading the baskets Removing the larger residue on the cutlery Filling the dispenser Selecting a program and running...

  • Page 28: Using Your Dishwasher

    USING YOUR DISHWASHER Control Panel Operation (Button) Press this button to turn on your dishwasher. Power Press this button to select the appropriate washing program, Program the program indicator will be lit. Press this button to set the delayed hours for washing. You can delay the start of washing up to 24 hours.
  • Page 29 Display Intensive For heaviest soiled crockery, and normally soiled pots, pans, dishes etc.With dried-on food. Normal For normally soiled loads, such as pots, plates, glasses and lightly soiled pans. This is standard program, it is suitable to clean normally Program soiled tableware and it is the most efficient program in indicator terms of its combined energy and water consumption for...

  • Page 30: Water Softener

    Water Softener The water softener must be set manually, using the water hardness dial. The water softener is designed to remove minerals and salts from the water, which would have a detrimental or adverse effect on the operation of the appliance. The more minerals there are, the harder your water is.

  • Page 31: Preparing And Loading Dishes

    Please check the section 3 “Loading The Salt Into The Softener” Please check the section 3 “Loading The Salt Into The Softener” of PART Ⅰ:Generic Version, If your dishwasher lacks salt. of PART Ⅰ:Generic Version, If your dishwasher lacks salt. NOTE: If your model does not have any water softener, you may skip this section.
  • Page 32 Recommendations for loading the dishwasher Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans. It is not necessary to rinse the dishes under running water. For best performance of the dishwasher, follow these loading guidelines. (Features and appearance of baskets and cutlery baskets may vary from your model.) Place objects in the dishwasher in following way:...
  • Page 33 Loading the basket All tableware can't be placed face up, in order to improve the cleaning area and washing performance, it is recommended to place the dirty side towards the spray arm. Please don't let tableware out of basket bottom to make sure not block the moving of the spray arm.

  • Page 34: Function Of The Rinse Aid And Detergent

    Function Of The Rinse Aid And Detergent The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes, which can leave spots and streaks. It also improves drying by allowing water to roll off the dishes. Your dishwasher is designed to use liquid rinse aids. WARNING Only use branded rinse aid for dishwasher.

  • Page 35: Filling The Rinse Aid Reservoir

    Filling The Rinse Aid Reservoir Remove the rinse aid reservoir cap Carefully pour in the rinse aid into by rotating it counterclockwise. the dispenser, whilst avoiding it to overflow. NOTE: Clean up any spilled rinse aid with an absorbent cloth to avoid excessive foaming during the next wash.

  • Page 36: Filling The Detergent Dispenser

    Filling The Detergent Dispenser Push latch to open Press the release latch on the detergent Add detergent into the larger cavity dispenser to open the cover. (A) for main wash. For more heavily soiled wash loads, also add some detergent into the smaller cavity (B) for release during pre-wash.

  • Page 37: Programming The Dishwasher

    PROGRAMMING THE DISHWASHER Wash Cycle Table The table below shows which programs are best for the levels of food residue on them and how much detergent is needed. It also show various information about the programs. )Means: need to fill rinse into the Rinse-Aid Dispenser. Description Energy Water...

  • Page 38: Saving Energy

    Saving Energy 1. Pre-rinsing of tableware items leads to increased water and energy consumption and is not recommended. 2. Washing tableware in a household dishwasher usually consumes less energy and water in the use phase than hand dishwashing when the household dishwasher is used according to the instructions.

  • Page 39: Forget To Add A Dish

    Forget To Add A Dish? A forgotten dish can be added any time before the detergent dispenser opens. If this is the case, follow the instructions below: 1. Press the Start/Pause button to pause the washing. Wait 5 seconds then open the door. Add the forgotten dishes.

  • Page 40: Error Codes

    ERROR CODES If there is a malfunction, the dishwasher will display error codes to identify these: Meanings Codes Possible Causes Faucets is not opened, or water intake is Longer inlet time. restricted, or water pressure is too low. Not reaching required Malfunction of heating element.

  • Page 41: Technical Information

    TECHNICAL INFORMATION W W W H H H 438mm Height (H) 550mm Width (W) 500mm (with the door closed) Depth (D1) 812mm (with the door opened 90°) Depth (D2)
  • Page 42 Product fiche Sheet of household dishwasher according to EU Directive 1016/2010 & 1059/2010: Manufacturer Beko Type / Description DTC36610B Standard place settings Energy efficiency class Annual energy consumption 174kWh Energy consumption of the standard cleaning cycle 0.61 kWh Power consumption of off-mode 0.45 W...
