Delta 422-32-655-0004 Instruction Manual

Pari No. 422·32~655~0004
A
~
Oi3led 1 1~10·93
... CELTA
CUTTING CROWN MOULDING WITH DELTA
FRAME & TRIM SAWS AND COMPOliND MITER SAWS
Cutling the more populi1r 52/38 degree ceiling/wail
angle crown moulding. shown in Fig. 1. is
n
last and easy
operation when uSing
Delta rrame
& Trim Saws and
Compound Miler Saws. when the angle between the waUs
iS90degrees. With Frame & Trim Saws, a built, in mllerslop
at 31,62 degrees fight and left, and a bevel Indicalor at
33.86 degrees is provided. With Compound Miler Saws.
lhe miler angle of 31.62 degrees right and left. and the bevel
angle of 33.86 degrees is provirJed on (he miter and bevel
scales by means of a triangle indicator
If Ihe angle between the walls is other
Ulan
90 degrees or
il you are using 45/45 degree ceiling/wall crown moulding,
as shown in Fig. 2, different miter and bevel seltings of Ihe
blade are necessary
The following chart Illustrates the miter and bevel angle
sellings of the saw blade for bolll 52/38 degree and 45/45
degree crown moulding, when the angle between the walls
range from 67 degrees 10 179 degrees as shown IJYFig. 3
CEILING
Fig,l
Fig 2
Fig. :3
