- Page 1 U-Bolt Z-Wave Installation and User Guide (V3.0)
-
Page 2: Important Notes
Terms & Policies Before using all ULTRALOQ products, please read all applicable terms, rules, policies and usage provisions found at www.ultraloq.com/company/privacy. By using your ULTRALOQ, you agree to be bound by the ultraloq Privacy Policy. Need Help? For technical documents and more Please visit support.ultraloq.com... -
Page 3: Packing List
Edge of the door Cara de la puerta Borde de la puerta Centerline ” (60 mm) ” (70 mm) Backset Entrada de la cerradura May not be included for some regions User Guide U-Bolt Z-Wave Installation and User Guide (V3.0) - 2 -... - Page 4 Installation Guide Installation Video Please scan this QR code to watch the easy step by step installation video before installing U-Bolt Z-Wave. Or you can also view the webiste directly. www.ultraloq.com/u-bolt-z-wave/guide. 1. Preparing Door Check the door’s dimensions. Step 1 Measure to con rm that the door is between 1 ”~ 1...
- Page 5 2. Installing Bolt and Strike Step 1 Install Bolt into the door. Make sure the UP icon goes up. ” ” Note: Bolt is set for backset initially. It can be adjusted to needed. To adjust it please make sure the bolt is retracted, then, press it, twist and pull it or push it to your desired length.
- Page 6 If your door has a 1 ” (38 mm) bore hole, remove the spacer from the exterior assembly as shown. With No Spacer 4. Installing Interior Assembly Mounting Plate Step 1 Route the cable through the hole on Interior Assembly Mounting Plate.
- Page 7 Screw B 5. Installing Interior Assembly Step 1 Remove the battery cover of the Interior Assembly. Warning: Please do not install the batteries before installing interior assembly, otherwise the keypad may not be powered on. Step 2 Insert the connector of the cable to the socket of the Interior Assembly.
- Page 8 Step 3 vertical Rotate the knob and keep it in a position to stay unlocked. RESET Unlocked Step 4 Attach Interior Assembly to Mounting Plate and tighten Screw C (x2). Screw C RESET 6. Installing the Batteries and adjust the lock orientation This step will teach your lock the orientation of your door and is crucial to lock operation.
- Page 9 U-Bolt Z-Wave in Factory Default Mode User Guide User Guide Video Please watch our easy step by step User Guide video before attempting to use your U-Bolt Z-Wave Smart Lock. Or you can also view the website directly. wwww.ultraloq.com/u-bolt-z-wave/guide - 8 -...
-
Page 10: Product Overview
1. Product Overview 1.1 Exterior Anti-peep Keypad Backup Key Hole ULTRALOQ Button Tri-color LED Indicator Anti-peep Keypad Used to enter the code and unlock from outside. Backup Key Hole Used to insert the key to unlock in emergency situations. ULTRALOQ Button Used to lock from the outside, illuminate the keypad for code entry and con rm previous operation. - Page 11 1.3 Low Battery Alarm There will be low battery alert on the lock and smart home system when battery is low. will flash red ULTRALOQ Button with beeps when the lock is retracted. Please replace batteries. - 10 -...
- Page 12 Step 2 If prompted by your smart home system to add the lock. Operate on lock Enter "Include mode": hold the "ULTRALOQ" button for 3 seconds, hear 2 beeps with flashing blue light,Internal LED Flashing Green light. The lock now enter setup mode.
- Page 13 3.1 Unlock From Outside • User Code Enter 4-8 digit code and press ULTRALOQ Button to unlock . The default code is 3494. Once the device is added to the Z-Wave network, the user code can only be changed via Z-Wave commands.
- Page 14 Needle to push the Reset Button(aocated inside the battery compartment) for 10 seconds until you hear one long beep and two short beeps. Please note all data will be erased if you reset U-Bolt Z-Wave to factory default. 3.5 Replace Batteries...
- Page 15 1. How to reset U-Bolt Z-Wave? Please note all data will be erased if you reset U-Bolt Z-Wave to factory default. Method 1:Remove the lock from your smart home system, but the lock doesn’t reset itself, please use a Reset Needle to...
- Page 16 Keep Your Records DATE ADMIN CODE NAME USER CODE Felix 12345678 - 15 -...
- Page 17 ©2025 Xthings Inc. All rights reserved. ULTRALOQ and ULTRALOQ logo are trademarks of Xthings lnc. or its affiliates registered in the U.S. and other countries and regions. All other trademarks are the property of their respective owners. Xthings Inc. 47703 Fremont Boulevard, Fremont, CA94538...
