Summary of Contents for AEG EK8B18C
- Page 1 EN User Manual | Fridge Freezer EK8B18C aeg.com\register...
- Page 2 INSTALLATION (*mm) W min. 38 1780 1769 (min. 550) max. 22 ≥ 560☺ 692÷708 1038 1784 min. 38 1769 1085 ≥ 200 cm NOISES SSSRRR! BRRR! BLUBB! HISSS! CLICK!
- Page 3 Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................3 2. SAFETY INSTRUCTIONS................5 3. CONTROL PANEL..................7 4. DAILY USE....................11 5.
- Page 4 • Children should be supervised to ensure that they do not play with the appliance. • Children shall not carry out cleaning and user maintenance of the appliance without supervision. • Keep all packaging away from children and dispose of it appropriately.
- Page 5 • When the appliance is empty for long period, switch it off, defrost, clean, dry and leave the door open to prevent mould from developing within the appliance. • Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. •...
- Page 6 mains cable, compressor). Contact the • Do not touch the compressor or the Authorised Service Centre or an condenser. They are hot. electrician to change the electrical • Do not remove or touch items from the components. freezer compartment if your hands are wet •...
- Page 7 • Please note that self-repair or non- • Disconnect the appliance from the mains professional repair can have safety supply. consequences and might void the • Cut off the mains cable and discard it. guarantee. • Remove the door to prevent children and •...
- Page 8 3.5 MultiSwitch Set recommended temperature by switching on ECO function. Refer to "ECO function". This function allows you to convert the The temperature indicators show the set freezer compartment into a fridge. temperature. Before activating the MultiSwitch function The set temperature will be reached remove the frozen food from the freezer within 24 h.
- Page 9 3. The freezer temperature indicator shows This function stops automatically after the temperature of the freezer approximately 6 h. Once the function is off, compartment. the Extra Cool indicator goes out. Press the Extra Cool button to deactivate the Extra Cool function before it automatically The MultiSwitch compartment reaches ends.
- Page 10 3.10 Door open alarm In order to switch the ECOMETER on or off: 1. Activate the Setting mode. The door open alarm indicator turns on with the sound if the fridge door is left open for 5 2. Tap until the display shows min.
- Page 11 • all buttons except for the button Press and hold the ECO button for approx. 3 combination necessary to deactivate the sec to switch off the Sabbath mode. mode Factory settings • sound, except for the High temperature This function restores each setting to the alarm factory default settings.
- Page 12 4.4 Removing GreenZone 2. Place the rear part of the drawer on the rails. 1. Empty the drawer. 2. Pull out the drawer from the fridge extending the rails fully. 3. Push the rails cap and lift up the front of the drawer.
- Page 13 2. Lift up the front of the drawer. Do not place any food products on the humidity control device. To remove the humidity control device: 3. Lift and turn the drawer to pull it out of the appliance. 1. Open the drawer below the glass shelf and pull out the cover.
- Page 14 4.9 CleanAir+ filter In the appliance, there can be a CleanAir+ carbon filter provided by manufacturer. The carbon filter purifies the air from odours in the fridge compartment, improving the storage quality. On delivery, the filter and its plastic housing are in a plastic bag (refer to the "Installing and replacing the CleanAir+ filter"...
- Page 15 Activate the Extra Freeze function at least 24 putting the products in the freezing h before placing the food to be frozen in the compartment. freezer compartment. To store large quantities of food, remove the Store the fresh food evenly distributed in the drawers and place the food directly on the first compartment or drawer from the top.
- Page 16 • The whole freezer compartment is suitable for storage of frozen food products. Type of food Shelf life • Leave enough space around the food to (months) allow air to circulate freely. Poultry 9 - 12 Beef 6 - 12 5.4 Shelf life for freezer Pork 4 - 6...
- Page 17 6.2 Periodic cleaning Clean the equipment regularly: • Clean the inside and accessories with lukewarm water and neutral soap. Rinse and wipe them dry. • Wipe down the door seals regularly. 6.3 Defrosting of the refrigerator 3. Remove the top glass shelf from the Defrosting of the fridge compartment is fridge compartment.
- Page 18 6.6 Period of non-operation When the appliance is not in use for long period, take the following precautions: 1. Disconnect the appliance from electricity supply. 2. Remove all food. 3. Clean the appliance and all accessories. 4. Leave the doors open to prevent Replace the air filter every 6 months.
- Page 19 Problem Possible cause Solution Food placed in the appliance is too Allow food to cool to room tempera‐ warm. ture before storing. The door is not closed correctly. Refer to "Closing the door" section. The Extra Freeze function is switch‐ Refer to "Extra Freeze function"...
- Page 20 Problem Possible cause Solution There are water drops on the glass There is too much moisture inside Wipe the glass shelves with a cloth shelves. the fridge. to remove water drops. Water flows on the floor. The melting water outlet is not con‐ Attach the melting water outlet to nected to the evaporative tray above the evaporative tray.
- Page 21 2. To adjust the door, refer to installation 3. To replace the defective door gaskets, instructions. contact the Authorized Service Centre. 8. TECHNICAL DATA The technical information is situated in the It is also possible to find the same information rating plate on the internal side of the in EPREL using the link https://eprel.ec.europa.eu and the model...
- Page 24 222382131-D-382024...
