Installation instructions
SKS 4.0 Series Flat Collector
IN ROOF MOUNTING
SOLAR THERMAL SYSTEMS
63043975.00-1.SD
63043975.00-1.SD
Solar Collector
For heating engineers
Please read carefully prior
to commissioning and
maintenance

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SKS 4.0 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Buderus SKS 4.0 Series

Summary of Contents for Buderus SKS 4.0 Series

  • Page 1 Installation instructions Solar Collector 63043975.00-1.SD 63043975.00-1.SD SKS 4.0 Series Flat Collector For heating engineers IN ROOF MOUNTING Please read carefully prior to commissioning and SOLAR THERMAL SYSTEMS maintenance...
  • Page 2 — Hand these installation instructions to the customer. — Explain to the customer the function and operation of the related devices. SKS 4.0 Series - In roof mounting -We reserve the right to make any changes due to technical modifications.

  • Page 3: Table Of Contents

    ......42 SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 4: General Information

    BS 6795: Latest version ask your local electrical contractor to check the inclusion of the solar thermal system into the lightning protection system. SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 5: Specifications

    Net weight, portrait version 46 kg Net weight, landscape version 47 kg Permissible operating pressure 10 bar of the collector Tab. 2 Specifications SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 6: Safety

    The installation set is suitable for a max. standard wind or snow load of 3,8 kN/m² and an installation height of max. 20 m. SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 7: Notes Structure

    After completing the installation, always check the secure positioning of the installed set and that of the collectors. SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 8: Before Installation

    USER NOTE Remove broken tiles, shingles or plates in the area of the collectors and replace them. SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 9: Component Description

    Screw 6 × 40 with washer × Item 17: Single-sided clamp × Item 18: Underlay plate, right × Item 19: Pan tile overlay SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.
  • Page 10 Item 1: Corrugated pipe connector × Item 2: Pipe clip 63043966.04-1.SD 63043966.04-1.SD Fig. 4 Two corner protectors with one connection set SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 11: Other Equipment

    Do not store collectors outside without pro- tection from the rain. 63043965.06-1.SD 63043965.06-1.SD Fig. 5 Plastic caps on collector connections SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 12: Technical Documentation

    DHW Cylinder: instructions enclosed with the Item 4: DHW cylinder. 6720613577.00-1.SD 6720613577.00-1.SD Fig. 6 Solar thermal system components and technical documentation SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 13: Determining Space Required On Roof

    Space requirement for portrait installed collectors Tab. 4 Space requirement for landscape installed collectors (incl. facing collectors all around) (incl. facing collectors all around) SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 14: Roof Preparations

    Take appropriate action to prevent ac- cidents when working on roofs. Always wear personal protective clo- thing and safety equipment. SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 15: Determining The Initial Installation Positions

    Height of collector array, incl. facing collector (dim. B) > 80 mm > 80 mm 63043975.02-1.SD 63043975.02-1.SD Fig. 8 Determining the exact position of the collector array SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 16: Fitting Additional Roof Battens

    Length of additional roof battens (here: first lower roof batten with anti-slip protection) Item 1: Clip Item 2: Additional roof battens Item 3: Joining the additional roof battens SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.
  • Page 17 When fitting the roof battens, make sure they are level (use spirit level). 63043975.35-1.SD 63043975.35-1.SD Fig. 12 Levelling the joists SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.
  • Page 18 Fig. 14 Distances between additional roof battens when installing one row (measurements in mm, values in brackets = landscape version) SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.
  • Page 19 Fig. 15 Distances between additional roof battens when installing more than one row (measurements in mm, values in brackets = landscape version) SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 20: Collector Installation

    Use lifting equipment as used by roofing contractors or sufficient suction handles for the installation. USER NOTE Unsecured collectors may fall during handling and installation. SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 21: Preparing To Install The Collectors

    If more than10 ollectors are required then a further AGS pump station is required. 63043966.08-1.SD 63043966.08-1.SD Fig. 19 Two-way pipework connections SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.
  • Page 22 (Fig. 21, Item 1) incl. the corner connector (Fig. 21, Item 3). The sealing tape slowly swells after installation. 63043973.02-1.SD 63043973.02-1.SD Fig. 21 Back of the collector SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 23: Fastening The Collectors

    Do not tighten the screw until the second collector has been pushed up against the double-sided clamp. 63043975.07-1.SD 63043975.07-1.SD Fig. 24 Double-sided clamp on the first collector SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.
  • Page 24 (Fig. 26, Item 1). 63043966.16-1.SD 63043966.16-1.SD Fig. 26 Corrugated pipe connector secured with brackets SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.
  • Page 25 Fasten collectors as with the lower row. SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 26: Collector Sensor Connection

    You must first remove the nut in the sensor bush using the cable gland (Fig. 31, Item 2). SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 27: Header Connection

    Perform the same procedure with the return connection. 63043973.06-1.SD 63043973.06-1.SD Fig. 33 Fitting flow line (with no vent on roof) SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 28: Venting Through Air Vent (Accessory) On Roof

    However with in-roof collectors the airvent must be fitted under the roof. SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.
  • Page 29 Item 1: Double threaded fitting with O-ring Item 2: Air pot Item 3: Connection pipe Item 4: De-airing tile Item 5: Bracket SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 30: Fitting The Connection Set For Two Rows (Accessory)

    63043973.09-1.SD 63043973.09-1.SD (Fig. 39, Item 4) from the connection kit. Fig. 39 Connection set between two collector rows SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 31: Installing The Facing Collectorcollectors

    Item 1), but in the middle of a collector. 63043975.09-1.SD 63043975.09-1.SD Fig. 40 Facing collectors fitted all round the edges SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 32: Lower Facing Collectors

    (arrow). 63043975.38-1.SD 63043975.38-1.SD Fig. 43 Positioning the middle facing collectorcollectors for portrait collectors SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.
  • Page 33 Carefully adjust flashing in the area in front of the roof tile contour (Fig. 46, Item 2). 63043975.11-1.SD 63043975.11-1.SD Fig. 46 Fastening the lower collectors SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 34: Side Facing Collectors

    Item 2) by hand, beginning at the bottom. The profile is clamped to the collector frame. 63043975.16-1.SD 63043975.16-1.SD Fig. 49 Middle cover strip SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 35: Middle Facing Collector (When More Than One Row Is Being Installed)

    63043975.33-1.SD 63043975.33-1.SD Press the upper facing collector down onto the lower Fig. 52 Laying middle-left facing collector in place one. SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 36: Side Facing Collectors On The Upper Row (If Installing More Than One Row)

    (Fig. 54, Item 3). 63043975.15-1.SD 63043975.15-1.SD Fig. 55 Upper left facing collector SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.
  • Page 37 Fasten clip with nail provided. 63043975.36-1.SD 63043975.36-1.SD Fig. 58 Fastening upper facing collectors with clips SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 38: Covering The Roof

    Item 2: Cut pan tile Item 3: Upper facing collector Cut pan tiles to dim. X (Table 5, page 15) and lay. SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 39: Final Activities

    11.2 Insulating the connection and header pipes Insulation of header pipes — For the insulation of internal pipework, use only high temperature resistant insulating materials. SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.

  • Page 40: Quick Reference Guide For Two Collectors

    Fit pan tile overlay and cut pan tiles to size. p. 38 63043975.45-1.SD 63043975.45-1.SD Fig. 62 Fastening and covering two collectors SKS 4.0 Series - In roof mounting - We reserve the right to make any changes due to technical modifications.
