Installation instructions

SKS 4.0 Series Flat Collector
FLAT ROOF AND WALL MOUNTED
SOLAR THERMAL SYSTEMS
Solar Collector
63043970.01-1.SD
63043970.01-1.SD
For heating engineers
Please read carefully prior
to commissioning and
maintenance

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SKS 4.0 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Buderus SKS 4.0 Series

Summary of Contents for Buderus SKS 4.0 Series

  • Page 1: Installation Instructions

    Installation instructions Solar Collector 63043970.01-1.SD 63043970.01-1.SD SKS 4.0 Series Flat Collector For heating engineers FLAT ROOF AND WALL MOUNTED Please read carefully prior to commissioning and SOLAR THERMAL SYSTEMS maintenance...
  • Page 2 — Hand these installation instructions to the customer. — Explain to the customer the function and operation of the related devices. SKS 4.0 Series - Flat roof and wall mounting -We reserve the right to make any changes due to technical modifications.

  • Page 3: Table Of Contents

    10 Quick reference guide for base anchoring and pressure filling ..41 SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 4: General Information

    SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 5: Specifications

    46 kg Net weight, landscape version 47 kg Permissible operating pressure of the 10 bar collector Tab. 2 Specifications SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 6: Safety

    Install the wall mounting support only on wall structures with sufficient structural strength. If necessary, ask a structural engineer for assistance. SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 7: Notes Structure

    After completing the installation, always check the secure positioning of the installed set and that of the collectors. SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 8: Before Installation

    63043970.05-1.SD Fig. 2 General overview of collector pair — wall mounted installation SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 9: Component Description

    SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.
  • Page 10 Corrugated pipe connector × Item 2: Connector clip 63043966.04-1.SD 63043966.04-1.SD Fig. 5 Two corner protectors with one connection set SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 11: Other Equipment

    Do not store collectors outside without protection from the rain. 63043966.05-1.SD 63043966.05-1.SD Fig. 6 Plastic caps on collector connections SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 12: Technical Documentation

    Angle of incidence of the collector on a flat roof swimming pool Tab. 3 Area of application, angle of incidence range SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.
  • Page 13 Fig. 10 Angle of incidence of the collector on a wall Item 1: Angle of incidence (absolute angle to the horizontal plane) Item 2: Collector angle of inclination SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.
  • Page 14 (Fig. 12, Item 2). 55° 60° 25° 140 mm 63043970.39-1.SD 63043970.39-1.SD Fig. 12 Adjust angle of inclination for portrait collectors SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 15: Determining Space Requirements

    Tab. 4 Dependency of clearance X on the angle of incidence and the minimum altitude of the sun (17°) SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.
  • Page 16 20.98 m Tab. 5 Space requirement for portrait installed collectors Tab. 6 Space requirements for landscape installed collectors SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 17: Installing Flat Roof And Wall Mounting Supports

    Notes identify any variations. 63043970.23-1.SD 63043970.23-1.SD Fig. 18 Landscape flat roof supports for 2 collectors SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 18: Distances Between Collector Braces For On-Site Base Anchoring

    Fig. 20 Basic version for 3 — 10 portrait collectors 1820 1820 63043970.42-1.SD 63043970.42-1.SD Fig. 21 Basic version for 2 landscape collectors SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.
  • Page 19 (Fig. 21, provided that an ad- ditional rail is fitted, page 27). 63043970.14-1.SD 63043970.14-1.SD Fig. 22 Auxiliary braces for 3 portrait collectors 63043970.14-1.SD SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 20: Clearances Between The Collector Braces When Using Loading Trays (Accessory)

    Distances between auxiliary braces 63043970.15-1.SD 63043970.15-1.SD Fig. 23 Basic version for up to 10 portrait collectors (in mm) SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.
  • Page 21 63043970.14-1.SD Fig. 24. 63043970.14-1.SD 63043970.14-1.SD Fig. 25 Version for maximum loads, 3 portrait collectors 63043970.14-1.SD SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 22: Stabilising The Flat Roof Supports

    3.3 kN 100 m Tab. 8 Values to stabilise one collector With additional rail only Per collector brace SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.
  • Page 23 2 wire ropes (Fig. 28, Item 1). 63043970.20-1.SD 63043970.20-1.SD Fig. 28 Flat roof support with ropes SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 24: Wall Mounting Supports - Installation

    Use 3 screws to fasten each collector brace to the wall (see Tab. 9, Fig. 30, Item 1). SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.
  • Page 25 Installing flat roof and wall mounting supports 63043970.30-1.SD 63043970.30-1.SD Fig. 30 Fastening collector braces to the wall (for 2 collectors, dimensions in mm) SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 26: Installing The Profile Rails

    Tab. 11 Aligning the lower and upper profile rails when using 63043970.45-1.SD 63043970.45-1.SD loading trays Fig. 33 Aligning the profile rails for loading trays SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.
  • Page 27 Item 1: Fixing holes for the anti-slip protection Item 2: Clicking the anti-slip protection into place Item 3: Anti-slip protection SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 28: Collector Installation

    (for easier lifting). USER NOTE Unsecured collectors may fall during hand- ling and installation. SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 29: Preparing To Install The Collectors

    If more than10 collectors are required then a further AGS pump station is required. 63043966.08-1.SD 63043966.08-1.SD Fig. 41 Two-way pipework connections SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 30: Fastening The Collectors

    63043970.31-1.SD 63043970.31-1.SD Fig. 44 Pushing on the single-sided collector clamp SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.
  • Page 31 63043969.02-1.SD 63043969.02-1.SD Fig. 47 Fitting a double-sided collector clamp SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.
  • Page 32 (Fig. 50, Item 1). 63043966.16-1.SD 63043966.16-1.SD Fig. 50 Corrugated pipe connector secured with brackets SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.
  • Page 33 Fig. 52 Single-sided collector clamp (left) breaks away and can be discarded. SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 34: Collector Sensor Connection

    You must first re- move the nut in the sensor bushing using the cable gland (Fig. 54, Item 2). SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 35: Header Connection

    Fasten insulated header to holder on site. Item 1: Hose clamp (on building) Item 2: M8 thread Item 3: Holder SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 36: Venting Through Pressure Filling

    Fig. 57 Fitting flow line (with no vent on roof) Item 1: Connector clip Item 2: Elbow Item 3: Olive Item 4: Nut SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 37: De-Airing Through Air Vent (Accessory) At Highest Point In The System

    Fig. 59 Universal air vent set × Item 9: Gasket × Item 10: Large diameter washer × Item 11: Clamping disc SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 38: Connecting Two Arrays

    Make on-site connection between collector arrays using copper pipe. 63043969.06-1.SD 63043969.06-1.SD Fig. 61 Two collector arrays, one behind the other SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 39: Final Activities

    (accesso- ry), you must close the ball valve after the venting procedure (see pump station in- stallation instructions). SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 40: Insulating The Connection And Header Pipes

    — For the insulation of internal pipework, use only high temperature resistant insulating materials, rated to 150 °C. — Make the insulation bird-proof. SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.

  • Page 41: 10 Quick Reference Guide For Base Anchoring And Pressure Filling

    Insulate header pipes with UV and high p. 40 temperature resistant material. 63043969.07-1.SD 63043969.07-1.SD Fig. 64 Fitting the collector sensor and connection parts SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.
  • Page 42 Notes SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.
  • Page 43 Notes SKS 4.0 Series - Flat roof and wall mounting - We reserve the right to make any changes due to technical modifications.
  • Page 44 Buderus Cotswold Way, Warndon, Worcester WR4 9SW Customer service: 0870 421 5933 Technical support: 0870 421 5944 Fax: 01905 753130 www.buderus.co.uk In the UK and IE, Buderus is a brand name of Bosch Thermotechnology Ltd.
