Dear Pyranha SprayMaster System New Owner,
We here at Pyranha, Inc. "Thank You" for purchasing the SprayMaster System, and we look
forward to many years of providing you with the comfort and protection to which all of our
customers are accustomed.
In order to serve you best, please complete and mail-in the attached registration within 30
days of purchase, or go to www.pyranhainc.com and register online to ensure that your system will
be covered under our One (1) Year System Top Warranty (pump, timer and motor).
Pyranha, Inc.
Attention: Customer Service
1162 Jordan Ranch Blvd
Brookshire, Texas 77423
Company/Individual Name
Address
Phone Number
Serial #
Where was your SprayMaster System Purchased?
☐ www.pyranhainc.com
SprayMaster ™
Warranty Registration
City
Email
Date This SprayMaster Was Purchased
☐ Store Name
City, State ___________________________________________
Warmest Regards,
The Pyranha Family
State
Zip Code
pg. 0
