Paypod
Compact pay station with Bunch Note Feeder (BNF)
TM
When cash recycle issues occur, the SCO (self-checkout) screen shows how to resolve the issue. As an alternative, the
LEDs of the coin recycler and note recycler
can help resolve the issue (page 5).
This user guide shows how to operate the pay station, its cash recyclers, and correct simple errors like coin or note jams with
the yellow operating features. The
user manual
includes more specified information.
Set the power of the pay station on/off
Set the power on
Set the power off
Restart the note recycler
Restart the note recylcer
Restart the coin recycler
Restart the coin recycler when
• you move it fully back in
its initial position after you
pulled its cart out,
• the orange status LEDs
below are green, yel-
low, or red.
(The white LED flashes
green in normal operation.)
Restart if orange LEDs are green, yellow or red
Fill the coin and note recycler
status
1
Select the fill mode of your POS software.
2
Fill coins and notes through the coin input cup and note
insertion slot.
3
Stop the fill mode.
Gain access to the coin recycler
Gain access to the note recycler
max. 20
at once
!
max. 50
at once
User Guide
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Paypod Compact and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CPI Paypod Compact

  • Page 1 User Guide Paypod Compact pay station with Bunch Note Feeder (BNF) Fill the coin and note recycler When cash recycle issues occur, the SCO (self-checkout) screen shows how to resolve the issue. As an alternative, the status LEDs of the coin recycler and note recycler can help resolve the issue (page 5).
  • Page 2 User Guide Paypod Compact pay station with Bunch Note Feeder (BNF) Operate the coin modules Operate the coin cashbox Remove the coin cashbox Reinsert the coin cashbox Relock the cash modules Unlock the cash modules Operate the coin hoppers Restart the coin recycler when you move it fully back in its initial position after you pulled its cart out.
  • Page 3 User Guide Paypod Compact pay station with Bunch Note Feeder (BNF) Operate the note cashbox (unlock, remove, rearm (open and close)) Open the note cashbox Unlock the cash modules Remove the note cashbox Unlock the note cashbox Close the note cashbox (indicator is green) Reinsert the note cashbox and Relock the cash modules...
  • Page 4 User Guide Paypod Compact pay station with Bunch Note Feeder (BNF) Remove a jam Remove a coin jam ..in the Coin validator ... in the transfer chamber ... in the Coin manifold Remove a note jam ..in the Acceptance module ...
  • Page 5 User Guide Paypod Compact pay station with Bunch Note Feeder (BNF) The status LEDs of the coin recycler If the respective status LED on the the coin recycler flashes red or yellow two times, coins are jammed or something else is blocked. Flashing code REmove a jam in the coin validator REmove a jam in the transfer chamber Remove a jam in the cashbox Flashing code REmove a jam in the coin manifold...
